- Page 1 AS-26 DVI to HDMI over CAT5e Mini-Extender User Manual Ascale Enterprise Co., Ltd. www.ascale.com.tw ...
-
Page 2: Safety And Notice
Safety and Notice The AS‐26 DVI to HDMI over CAT5e Mini‐Extender has been tested for conformance to safety regulations and requirements, and has been certified for international use. However, like all electronic equipments, the AS‐26 should be used with care. Please read and follow the safety instructions to protect yourself form possible injury and to minimize the risk of damage to the unit. Follow all instructions and warnings marked on this unit. Do not attempt to service this unit yourself, except where explained in this manual. Provide proper ventilation and air circulation and do not use near water. Keep objects that might damage the device and assure that the placement of this unit is on a stable surface. Use only the power adapter and power cords and connection cables designed for this unit. Do not use liquid or aerosol cleaners to clean this unit. Always unplug the power to the device before cleaning. - Page 3 Introduction The AS‐26 DVI to HDMI over CAT5e Mini‐Extender extends the DVI to HDMI transmission distance up to 40m (130ft) under HD resolution 720p or 1080i. With AS‐26, users can transmit high quality digital video of PC applications through one cost effective CAT‐5/5e to the remote HDMI display or projector, instead of using short and expensive DVI‐HDMI cables. With embedded EDID inside the extender, your PC will continue to send the digital video even when the HDMI display is not connected. The AS‐26 includes a transmitting unit (AS‐26‐TX) and a receiving unit (AS‐26‐RX). The transmitting unit is connected to your PC DVI output and the receiving unit is connected to the HDMI display or projector. While successfully connected, the two LED lights on each RJ‐45 connector will blink. The transmission distance between the transmitting and receiving units can be up to 40m (130ft) under HD (720p/1080i) or 25m (80ft) under Full HD (1080p). With compact size and requiring no power, AS‐26 is the most cost effective choice for bringing your impressive digital video to the remote HDTV. DVI PC HDMI display/projector CAT‐5e cable AS‐26‐TX AS‐26‐RX ...
-
Page 4: Package Contents
Features DVI 1.1 compliant HDMI 1.2 compliant Handy DVI‐D to RJ‐45 and HDMI to RJ‐45 adapters with programmable EDID feature Extend the transmission distance from the DVI sources up to 40m (130ft) under HD (720p or 1080i) or 25m (80ft) under Full HD (1080p) Easy to install No power required Compact size Package Contents 1x AS‐26‐TX (TX: transmitting unit) 1x AS‐26‐RX (RX: receiving unit) 1x User Manual Technical Specifications Video Bandwidth: 1.65 Gbps (DVI 1.1 / HDMI 1.2) Input TMDS signal: 1.2 volts (peak‐to‐peak) Input DDC signal: 5 volts (peak‐to‐peak) DVI‐D Connector (digital only) RJ‐45 Connector: 2 indication LEDs Dimensions: TX = 50mm x 40mm x 20mm (2”x1.6”x0.8”) (L x W x H) RX = 45mm x 25mm x 20mm (1.8”x1”x0.8”) (L x W x H) Weight: 80g (2.8oz) ... -
Page 5: Hardware Installation
Hardware Installation 1. Connect your transmitting unit AS‐26‐TX to your DVI PC source. 2. Connect your receiving unit AS‐26‐RX to your remote HDMI display or projector. 3. Make sure your CAT‐5/5e/6 cable is tightly connected and not loose. 4. Enjoy your high quality PC video on the screen. Notice If you need to modify EDID content in AS‐26, you can use EDID Reader/Writer to update DVI EDID information. All the transmission distances are measured using Belden CAT‐5e 125MHz and ASTRODESIGN Video Signal Generator VG‐859C. To reduce the interference among the unshielded twisted pairs of wires in CAT‐5/5e/6 cable, you can use shielded CAT‐5/5e/6 cables to improve EMI problems, which is worsen in the long transmission. Because the quality of the CAT‐5/5e/6 cables has the major effects in how long transmission distance will be made and how good is the received display, the actual transmission length is subject to your CAT‐5/5e/6 cables. For resolution greater than 1280x1024, a CAT‐6 cable is recommended. ...
