All about the
Use
of your
Important Safety Instructions ......................2
Features ....................................................4
Installation ................................................5
Door Reversal Instructions ..........................6
Energy Saving Tips .....................................8
www.frigidaire.com USA 1-800-944-9044
&
Care
Wine Cooler
TA B L E O F C O N T E N T S
Temperature Controls .................................9
Proper Use of Wine Cooler ........................11
Care and Cleaning ....................................12
Before You Call ........................................13
Major Appliance Warranty .........................16
www.frigidaire.ca Canada 1-800-265-8352
Advertisement
Related Manuals for Frigidaire FGWC5233TS
Summary of Contents for Frigidaire FGWC5233TS
- Page 1 Important Safety Instructions ......2 Temperature Controls .........9 Features ............4 Proper Use of Wine Cooler ......11 Installation ..........5 Care and Cleaning ........12 Door Reversal Instructions ......6 Before You Call ........13 Energy Saving Tips ........8 Major Appliance Warranty ......16 www.frigidaire.com USA 1-800-944-9044 www.frigidaire.ca Canada 1-800-265-8352...
- Page 2 IMPORTANT SAFETY INSTRUCTIONS Read and Save These Instructions WARNING This Owner’s Guide provides specific operating instructions for your model. Use your Wine Cooler only as instructed in this guide. These instructions For Your Safety are not meant to cover every possible condition Do not store or use gasoline, or other and situation that may occur.
- Page 3 IMPORTANT SAFETY INSTRUCTIONS Electrical Information Child Safety • The wine cooler must be plugged into its • Destroy carton, plastic bags, and any own dedicated 115 Volt, 60 Hz., 15 Amp, exterior wrapping material immediately AC only electrical outlet. The power cord of after the wine cooler is unpacked.
- Page 4 FEATURES IMPORTANT Your model and features may vary slightly from illustrations shown here. Names of Components Handle Control Panel Convertible Shelf Glass Door Bottom Shelf Toe Grille Adjustment Leg Height Adjustable 34 1/4” - 35” (870-890mm) " (870mm)
- Page 5 INSTALLATION Cleaning This Use & Care Guide provides general operating instructions for your model. Use the • Wash any removable parts of the wine appliance only as instructed in this Use & Care cooler interior, and exterior with mild Guide. Before starting the wine cooler, follow detergent and warm water.
- Page 6 DOOR REVERSAL INSTRUCTIONS Reversing the door swing 2. Carefully grasp top of door, tilt it forward slightly to clear hinge, then lift the door The glass door can be opened from left to right up off of bottom hinge and place it on a and vice versa.
- Page 7 DOOR REVERSAL INSTRUCTIONS 7. Unscrew hinge pin from bottom hinge and Button Plugs (3 pcs) transfer to threaded hole on opposite side. (See Figure 7.) Reinstall bottom hinge in left hand corner of cabinet using same three screws removed in Step 6. Plastic Grille Screws...
- Page 8 ENERGY SAVING TIPS • Install the wine cooler in the coolest part of a dry and ventilated room, out of direct sunlight and away from heating ducts or registers. Do not place the wine cooler next to heat- producing appliances such as a range, oven or dishwasher.
- Page 9 TEMPERATURE CONTROLS Operation Panel Display Lighting Temp. Temp. Window Down Power ON/OFF Control • When the appliance is plugged into a power outlet, it powers on automatically. • Touch the power button and hold for five Power ºF/ºC Interchange seconds to turn ON/OFF the appliance. •...
- Page 10 TEMPERATURE CONTROLS Temperature Setting • The temperature setting range is as below. 41°F 42°F 43°F 44°F 45°F ..62°F 63°F 64°F 5°C 6°C 7°C 8°C 9°C ..16°C 17°C 18°C NOTE When the highest/lowest temperature is reached, display will beep. Touch again to increase/ decrease the temperature to desired setting.
- Page 11 PROPER USE OF WINE COOLER The arrangement of Bottles 3. Full Depth Middle Shelves - will support 8 bottles of wine. • Do not let bottles touch the rear panel in order to maintain good air circulation in the cooler. •...
- Page 12 CARE AND CLEANING Cleaning the wine cooler • In a moving vehicle, secure the wine cooler in an upright position to prevent • Before cleaning, turn the temperature movement. Also, protect the outside of the control to OFF, unplug the wine cooler wine cooler with a blanket or similar item.
- Page 13 BEFORE YOU CALL 1-800-944-9044 (United States) Visit our web site at 1-800-265-8352 (Canada) www.frigidaire.com PROBLEM CAUSE CORRECTION WINE COOLER OPERATION Wine Cooler does • Wine cooler is plugged • Use another circuit. If you are not run. into a circuit that has a unsure about the outlet, have it ground fault interrupt.
- Page 14 BEFORE YOU CALL PROBLEM CAUSE CORRECTION WINE COOLER OPERATION (cont’d) Interior Wine • Temperature control is • Turn control to a colder setting. Cooler temperature set too warm. Allow several hours for the is too warm. temperature to stabilize. • Door is opened too •...
- Page 15 BEFORE YOU CALL PROBLEM CAUSE CORRECTION WATER/MOISTURE/FROST OUTSIDE WINE COOLER Moisture forms on • Door may not be seating • Check for proper alignment of door outside of Wine properly, causing the and gasket. Cooler. cold air from inside the wine cooler to meet warm moist air from outside.
- Page 16 Electrolux or an authorized service company. Product features or specifications as described or illustrated are subject to change without notice. Canada 1.800.944.9044 1.800.265.8352 Frigidaire Electrolux Canada Corp. 10200 David Taylor Drive 5855 Terry Fox Way Charlotte, NC 28262...
