MODEL/MODELO TT415Y24008 User Manual Manual del usuario NEW! Follow along with your smartphone to make assembly even easier! 877-472-4296 www.medalsports.com...
Page 2
ASSEMBLY EXPERIENCE Step 1: Scan the QR code below and download the free BILT app. Step 2: Once in the BILT app, Scan the QR code below again to get MD SPORTS products and find the models you need. Step 3: Begin the easy assembly of this product by using the BILT 3D-guided interactive...
Page 3
WE ARE READY ESTAMOS LISTOS TO HELP AYUDA DO NOT RETURN TO STORE NO DEVOLVERLO A LA TIENDA Please Contact Por favor Contactar MD SPORTS Customer Service Servicio al Cliente Toll Free Llamada Gratuita 877-472-4296 Mon.-Fri., Lunes a Viernes, 9:00 a.m. to 5:00 p.m. EST 9:00 a.m.
Page 4
Esto eliminará la suciedad, el sudor y otros remove dirt, sweat, and other debris that can build up desechos que pueden acumularse con el tiempo y over time and damage the materials. dañar los materiales. TT415Y24008 (Continued on the next page) (Continúe en la siguiente página) www.medalsports.com...
Page 5
Delantal lateral Block Spacers bloques de madera (1.06m) (1.06m) (1.04m) (1.04m) ACCESSORIES ACCESORIOS Table Tennis Paleta de tenis Table Tennis Bola de tenis Paddle de mesa Ball de mesa TT415Y24008 (Continued on the next page) (Continúe en la siguiente página) www.medalsports.com...
Page 6
If any parts are missing, call our muestran en la lista de piezas. Si falta alguna pieza, customer service. llame a nuestro servicio al cliente. TT415Y24008 (Continued on the next page) (Continúe en la siguiente página) www.medalsports.com...
Page 7
English Español ASSEMBLY MONTAJE FIG. 1 FIG. 2 Level (Not included) Nivel (No incluido) Wall / Pared Tighten / Apriete TT415Y24008 (Continued on the next page) (Continúe en la siguiente página) www.medalsports.com...
Page 8
English Español ASSEMBLY MONTAJE FIG. 3 Pre-installed Pre-installed Pre-installed FIG. 4 Pre-installed Pre-installed Pre-installed Pre-installed Pre-installed TT415Y24008 (Continued on the next page) (Continúe en la siguiente página) www.medalsports.com...
Page 9
English Español ASSEMBLY MONTAJE Tighten / Apriete FIG. 5 Tighten / Apriete FIG. 6 TT415Y24008 (Continued on the next page) (Continúe en la siguiente página) www.medalsports.com...
Page 10
Nota: El tubo de conexión con el soporte de tope (7) se conecta a la pata interior (6) desde el exterior y a la pata exterior (4) desde el interior. TT415Y24008 (Continued on the next page) (Continúe en la siguiente página) www.medalsports.com...
Page 11
(3) from the inside. Nota: El tubo de conexión (8) se conecta al pie interior (5) desde el exterior, y la pata exterior (3) desde el interior. TT415Y24008 (Continued on the next page) (Continúe en la siguiente página) www.medalsports.com...
Page 12
FIG. 10 CONSEJO REPEAT THESE STEPS (FIG.1 - 10) FOR THE REPITA DICHOS PASOS (FIG.1 - 10) PARA OTHER HALF OF THE TABLE. LA OTRA MITAD DE MESA. TT415Y24008 (Continued on the next page) (Continúe en la siguiente página) www.medalsports.com...
Page 13
FIG. 12 Pre-installed Note: Both logo panels should be inverted Pre-installed when assembling. Nota: Ambos paneles del logo deben estar invertidos al ensamblar. TT415Y24008 (Continued on the next page) (Continúe en la siguiente página) www.medalsports.com...
Page 14
DO NOT lean too much weight on the wheels Lift the table. while lifting the table. Levanta la mesa. NO apoye mucho peso sobre las ruedas al levantar la mesa. TT415Y24008 (Continued on the next page) (Continúe en la siguiente página) www.medalsports.com...
Page 15
floor. Nota: Tire las patas hacia afuera desde la parte superior de la mesa y baje la mitad de la mesa al suelo. TT415Y24008 (Continued on the next page) (Continúe en la siguiente página) www.medalsports.com...
Page 16
English Español ASSEMBLY MONTAJE FIG. 15 TT415Y24008 (Continued on the next page) (Continúe en la siguiente página) www.medalsports.com...
Page 17
Cuando la mesa esta en posicion de almacenamiento, safety strap to prevent the sides from falling. siempre usar la correa de seguridad para prevenir que la mesa se caiga. TT415Y24008 (Continued on the next page) (Continúe en la siguiente página) www.medalsports.com...
Page 18
Al abrir la mesa, asegúrese de abrir PRIMERO el lado con with the net. la red. Step 2: Unlock the table locks. Paso 2: Desbloque los bloques de mesa. TT415Y24008 (Continued on the next page) (Continúe en la siguiente página) www.medalsports.com...
Page 19
Step 3: Pull the legs out from the table top and lower the table half to the floor. Paso 3: Tire las patas hacia afuera desde la parte superior de la mesa y baje la mitad de la mesa al suelo. TT415Y24008 (The last page) (La ultima página) www.medalsports.com...
