Nova 8351-R How To Install

INSTALL YOUR
RAISED TOILET SEAT WITH
ARMS
Item # 8351/8351-R
Capacity not to exceed 300 lb
Pre-Installation Instructions
1
Make sure the toilet is clean and sanitized. Lift
up toilet seat and lid.
NOTE: You may also need to remove the entire
seat and lid from the toilet (varies depending
on the size of the toilet).
Installation Instructions
1
To install arms, depress the brass push buttons
and insert the arms into the telescoping tubes
on the bottom of the seat. Push inward until
brass buttons engage and lock into the toilet
seat. Arms should lean forward, away from rear
of toilet.
There are two width adjustments to choose
from. Choose the adjustment that feels most
comfortable to the user.
2
Set the Raised Toilet Seat onto the
toilet. Ensure inner portion of the
anchor insert of the Raised Toilet
Seat is placed inside the toilet
bowl and sets against the back of
the toilet rim.
4
Tighten the clamp on the unit by
turning the gray knob in the front
clockwise until securely locked
onto the toilet.
NOTE: DO NOT overtighten the
knob. This may result in the plas-
tic clamp breaking.
HOW TO
WHAT'S IN THE BOX
a. (1) Raised Toilet Seat Assembly
b. (2) Arms
3
The square clamp on the bottom
of the Raised Toilet Seat should
be facing toward the inside of the
toilet's front rim. The clamp may
have to be loosened, by turning
the gray knob counterclockwise,
to fit inside the toilet.
5
Pull up on the Raised Toilet Seat
to make sure it is securely locked
onto the toilet. Always apply even
pressure around the Raised Toilet
Seat. To remove arms depress the
brass push buttons and pull the
arms away from the toilet seat.
NO tools required.
Quick installation.
Easy to follow
step-by-step
instructions
a.
b.
Revised: August 15, 2018
