- Page 1 Oven, 60cm, Multi-Function, Self-cleaning with Air Fry HWO60S20TTPB5 and HWO60S18TTB5 USER GUIDE NZ AU...
- Page 3 CONTENTS Safety and warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Product overview .
- Page 5 SAFETY AND WARNINGS WARNING! Electric Shock Hazard Failure to follow this advice may result in electric shock or death. • Do not cook on a broken or cracked cooktop . If the cooktop surface should break or crack, switch the appliance off immediately at the mains power supply (wall switch) and contact a qualified technician .
- Page 6 SAFETY AND WARNINGS WARNING! Hot Surface Hazard Failure to follow this advice could result in burns and scalds. • Do not touch surface units or areas near units . Surface units maybe hot even though they are dark in colour . •...
- Page 7 SAFETY AND WARNINGS READ AND SAVE THIS GUIDE Only use the oven for its intended purpose, that is only for the cooking of foods: any other use, for example as a heat source, is considered improper and therefore dangerous. The manufacturer cannot be held responsible for any damage resulting from improper, incorrect or unreasonable usage.
- Page 8 SAFETY AND WARNINGS Do not install the product in open environments exposed to atmospheric agents. This appliance is designed to be used at altitude lower than 2000m. It is recommended to wear protective gloves during installation to avoid cut injuries. Electrical warnings The socket must be suitable for the load indicated on the tag and must have ground contact connected and in operation.
- Page 9 SAFETY AND WARNINGS Use and maintenance Wash all accessories before first use with a solution of hot water and washing up liquid. The dripping pan collects the residues that drip during cooking. When you place the grid or air fry tray on the side racks, make sure that the shorter section of the side (between the stop and the extremity) is directed towards the interior of the oven.
- Page 10 PRODUCT OVERVIEW FEATURES AND ACCESSORIES Control panel Oven door Shelf positions Side racks Racks Baking tray Roast dish Airfry tray Fan cover...
- Page 11 CONTROL PANEL OVEN COOKING FUNCTIONS PROGRAMS Press and hold to turn oven POWER ON/OFF Lock the controls to prevent accidental use . Press and hold to turn CHILD LOCK ON/OFF While locked, all controls are disabled except for TOUCHSCREEN DISPLAY Use to navigate cooking functions, features and settings .
- Page 12 MAIN MENU The main menu is displayed on the screen . Scroll horizontally to access the programs . HOME ICON MENU ITEM DESCRIPTION OVEN FUNCTIONS Access traditional oven functions for baking and grilling . SPECIAL PROGRAMS Choose a specialised cooking program to suit your cooking requirements .
- Page 13 FIRST USE Preparing your oven Before using your oven for the first time, remove and wash all accessories, and clean the inside of the oven with a damp, soft cloth and mild detergent . Wipe the outside with a damp, soft cloth . Dry with a clean cloth . Run the empty oven at maximum temperature for 60 minutes to remove the newness smell .
- Page 14 FIRST USE Setting the display brightness Select from the BRIGHTNESS menu . SETTINGS Adjust level as desired and press to confirm . Setting the alert volume level Select from the SOUNDS SETTINGS menu . Adjust level as desired and press to confirm .
- Page 15 USING THE OVEN Preheating the oven Ensure you remove all accessories from the oven before using functions that have a preheating stage . OVEN COOKING FUNCTIONS PROGRAMS Setting a cooking function 1. Select FUNCTIONS SPECIAL PROGRAMS EVERYDAY from the home COOKING screen .
- Page 16 USING THE OVEN Fast preheating combines fan and FAST PREHEAT heating elements to heat the oven faster and save energy . Not available with all functions . Press to skip preheat and start cooking . Setting the timer Press to access the timer, then scroll vertically to set a duration .
- Page 17 USING THE OVEN Delay Start lets you schedule cooking to start at a later time . Not available with DELAY START MAXI GRILL functions . FAN GRILL Setting Delay Start 1. Set a cooking function and cooking duration, then press select DELAY START.
- Page 18 OVEN FUNCTIONS DEFAULT SUGGESTED TEMP°C / ICON FUNCTION SHELF PREHEAT COOKING SUGGESTIONS TEMP°C POSITION RANGE 190°C Ideal for cooking meat, fish or L3/4 vegetables . 150– 220°C Ideal for cakes, breads, biscuits, 200°C Yes/Fast Bake L2/3 quiches on one level using both upper preheat 30–250°C and lower level heating .
- Page 19 SPECIAL PROGRAMS DEFAULT SUGGESTED TEMP°C / ICON FUNCTION SHELF PREHEAT COOKING SUGGESTIONS TEMP°C POSITION RANGE Ideal for leavening pizza and Proof 40°C bread dough . Ideal for cooking different 200°C Multishelf Yes/Fast L1+L3+L5 dishes of a full meal at the same cooking preheat 150–250°C...
- Page 20 COOKING PROGRAMS Everyday cooking These programmed recipe functions allow you to cook a variety of recipes without preheating the oven . You can adjust cooking duration and temperature within the ranges listed in the table . If further cooking is required after using these functions, we recommend using a standard cooking function instead of resetting an everyday cooking function .
- Page 21 COOKING PROGRAMS Stuffed vegetables Baked potatoes Vegetables 500–1200g Vegetables au gratin Roasted potatoes Butter biscuits 1 to 4 trays Frozen croissants 1 to 4 trays Fruit tart 1 to 2 trays Mille-Feuille 1 to 2 trays Muffins 1 to 3 trays Sweet bakery Sponge cakes 1 to 2 trays...
- Page 22 CARE AND CLEANING General recommendations We recommend cleaning the oven after each use . Wait for the oven to cool before cleaning . Do not line the oven walls with aluminium foil or single-use protection as these may damage the enamel interior .
- Page 23 CARE AND CLEANING Hydro clean This function uses steam to clean light levels of residue from the oven interior in a quick and eco-friendly way . Always use distilled or drinkable water . 1. Go to the menu and CLEANING select HYDROCLEAN Press...
- Page 24 CARE AND CLEANING Cleaning the accessories We recommend you clean and dry the accessories thoroughly after every use . If required, soak them for 30 minutes in a mixture of hot water and mild detergent before cleaning . Cleaning the side racks 1.
- Page 25 CARE AND CLEANING Removing the door The door can be removed for greater access when cleaning the oven . 1. Open the door fully and use a screwdriver to rotate the hinge locks outwards, then carefully lift the door off and place it on a soft, level surface .
- Page 26 CARE AND CLEANING Removing and cleaning the door glass 1. Shut the door halfway, then press the buttons on both sides of the door at the same time to release the cover on top of the door . 2. Carefully remove the inner and middle panes and wipe clean with a soft, damp cloth and mild detergent .
- Page 27 REPLACING THE LIGHTS Always disconnect the oven from the power supply before replacing the lights . Replacing the back light 1. Turn the protective light cover clockwise to remove it . 2. Unscrew the light bulb to remove it . Replace with a new bulb and refit the protective cover .
- Page 28 TROUBLESHOOTING PROBLEM POSSIBLE CAUSES WHAT TO DO ER__ There is an error . If the oven is switched on, switched it off and wait is showing several minutes before powering it on again . If the on the display error has disappeared, you can continue to use the oven .
- Page 29 . You must produce both warranty card and proof of purchase in the event of a warranty repair being required . When you purchase any new Haier Product you automatically receive a two year Manufacturer's Warranty covering parts and labour for servicing .
- Page 30 MANUFACTURER'S WARRANTY Note: This Warranty is an extra benefit and does not affect your legal rights and applies only to product purchased in New Zealand and Australia . Please keep this Warranty Card in a safe place . For Australian customers: Our goods come with guarantees that cannot be excluded under the Australian Consumer Law .
- Page 31 CUSTOMER SERVICE We recommend our Haier Customer Service and the use of original spare parts . If you have a problem with your appliance, please first check TROUBLESHOOTING . If you cannot find a solution there, please contact: Your local dealer The Service &...
- Page 32 WWW .HAIER .COM .AU WWW .HAIER .CO .NZ 432407A 70067493 11 .24...
