Summary of Contents for Ryobi RELTRA20
- Page 1 RELTRA20...
- Page 2 INTENDED USE protected supply. Use of an RCD reduces the risk of electric shock. The line trimmer attachment is approved for use with the following RYOBI powerheads: PERSONAL SAFETY ■ battery-driven powerheads of RLT36BS, R18XBCT10, Stay alert, watch what you are doing and use ■...
- Page 3 preventive safety measures reduce the risk of starting ■ Never service damaged battery packs. Service the power tool accidentally. of battery packs should only be performed by the manufacturer or authorized service providers. ■ Store idle power tools out of the reach of children and do not allow persons unfamiliar with the power GRASS TRIMMER SAFETY WARNINGS tool or these instructions to operate the power tool.
- Page 4 ■ Keep all parts of the body away from the cutter, line ■ To reduce the risk of injury associated with contacting or blade when the machine is operating. Before you moving parts, always power off the product, remove the start the machine, make sure the cutter, line or blade battery pack, and allow both to cool down.
- Page 5 ■ When transporting the product in a vehicle, secure it against movement or falling to prevent injury to persons Do not use metal blade(s) on the or damage to the product. product. TRANSPORTING LITHIUM BATTERIES Transport the battery pack in accordance with local and national provisions and regulations.
- Page 6 RELTRA20 Hanger cap Lower shaft Cutting line String head Bump head Safety guard Cut-off blade Operator's manual Know your product...
- Page 7 Always wear eye, ear, and head Align the screw to the hole on the Insert the tab of the silver bracket into the slot on the safety guard. protection, non-slip heavy-duty safety guard. gloves, and substantial footwear while NOTE: Always install the safety guard operating the product.
- Page 8 Operating the product Replacing the Replacing the Cleaning the p.11 p.13 Storing the product p.14 p.12 cutting line product string head...
- Page 9 OPERATING THE PRODUCT WARNING: Beware of objects thrown by the cutting means. Remove debris like small stones, gravel, and other foreign objects from the work area before starting operation. Wires or string may become entangled with the cutting means. WARNING: Keep hands away from the lock- out trigger and on/off trigger when installing the battery pack to avoid starting the product accidentally.
- Page 10 NOTE: Cut the grass from the right side to the left side for cutting ease and safety. Operation...
- Page 11 REPLACING THE CUTTING LINE 1. Place the product on a level surface. Position the product with the motor side down and the safety guard side up. 2. Rotate the bump head on the string head until the line on the centre of the bump head aligns with the arrows on the outer spool.
- Page 12 REPLACING THE STRING HEAD 1. Place the product on a level surface. Position the product with the motor side down and the grass deflector side up. 2. Insert a lock pin into the slot underneath the string head. Loosen and remove the trimmer head.
- Page 13 CLEANING THE PRODUCT 1. Place the product on a level surface. Position the product with the motor side down and the blade guard side up. WARNING: Do not use water when cleaning the product. WARNING: The small blade fitted to the safety guard is designed to trim the newly extended line to the correct length for safe and optimum performance.
- Page 14 STORING THE PRODUCT NOTE: Clean the product before storing it. 1. Turn the knob counterclockwise to loosen the coupler. Push the lock button and pull out the lower shaft from the upper shaft. 2. Store the product in a cool, dry, and well-ventilated place that is inaccessible to children.
- Page 15 Replacement 2.0 mm trimming line RLTS2 Uncertainty = 1.5 m/s NOTE: Visit your local special orders desk or contact RYOBI Noise emission level (in accordance with IEC 62841-1) customer service for replacement parts. A-weighted sound pressure level at = 87.5 dB(A) operator’s position...
- Page 16 WARNING! The declared vibration total values and the declared noise emission values given in this instruction manual have been measured in accordance with a standardised test and may be used to compare one tool with another. They may be used for a preliminary assessment of exposure.
- Page 20 Techtronic Industries Australia Pty Ltd 31 Gilby Road, Mount Waverley, VIC 3149 Melbourne, Australia Techtronic Industries N.Z. Limited Unit C, 70 Business Parade South, Highbrook, Auckland 2013, New Zealand RYOBI is a trade mark of Ryobi Limited, and is used under license. 961480338-01...
