- Page 1 WSWMU UNIVERSAL SPEAKER WALL MOUNT INSTRUCTION MANUAL We’ll Make It Stress-Free If you have any questions along the way, just give us a call. P: +31 (0) 495 580 852 • UK: (0) 800 056 2853 • AUS: +61 (0) 7 3299 7000 • US: 1 (800) 359 5520 We’re ready to help!
- Page 3 CAUTION: IMPORTANT SAFETY INSTRUCTIONS — PLEASE READ ENTIRE MANUAL PRIOR TO USE — SAVE THESE INSTRUCTIONS Before getting started, let’s make sure this product is perfect for you! This mount is designed to support most wireless speakers, with similar mounting holes. CAUTION: Avoid potential personal injuries and property damage! •...
- Page 4 Dimensions TV INTERFACE 0.89 22.5 1.05 26.7 2.10 53.3 WALL PLATE TOP VIEW - EXTENDED SIDE VIEW - EXTENDED 27° 3.00 76.1 2X 90° 10.00° 9° **ATTACHED PRODUCT TO DETERMINE ACTUAL SWIVEL** SIDE VIEW - RETRACTED FULLY ASSEMBLED MOUNT TOP VIEW - RETRACTED 1.50 38.2 2.43...
- Page 5 Supplied Parts and Hardware WARNING: This product contains small items that could be a choking hazard if swallowed. Before starting assembly, verify all parts are included and undamaged. If any parts are missing or damaged, do not return the damaged item to your dealer;...
- Page 6 STEP 1A Attach Wall Plate to Wall Drywall Only Installation CAUTION: Avoid potential personal injury or property damage! ● Drywall covering the wall, must not be less than 1/2 in. (12.7 mm) 1 in. (25 mm) Min. 1/2 in. (12.7 mm) 1/4 in.
- Page 7 CAUTION: Avoid potential personal injury or property damage! MUST BE firmly tightened to prevent unwanted movement of the wall plate . Ensure the wall plate is securely fastened to Both screws the wall before continuing on to the next step. Go to STEP 2, PAGE 11.
- Page 8 STEP 1B Attach Wall Plate to Wall Wood Stud Installation CAUTION: Avoid potential personal injury or property damage! ● Drywall covering the wall, must not exceed 5/8 in. (16 mm) ● Minimum wood stud size: nominal 2 x 4 in. (51 x 102 mm) actual 1½ x 3½ in. (38 x 89 mm) ●...
- Page 9 CAUTION: Avoid potential personal injury or property damage! MUST BE firmly tightened to prevent unwanted movement of the wall plate . Ensure the wall plate is securely fastened to Both screws the wall before continuing on to the next step. Go to STEP 2, PAGE 11.
- Page 10 Attach Wall Plate to Wall Solid Concrete or Concrete Block Installation STEP 1C CAUTION: Avoid potential personal injury or property damage! ● Mount the wall plate directly onto the concrete surface (no wall covering) ● Minimum solid concrete thickness: 8 in. (203 mm) ●...
- Page 11 CAUTION: Avoid potential personal injury or property damage! MUST BE firmly tightened to prevent unwanted movement of the wall plate . Ensure the wall plate is securely fastened to Both screws the wall before continuing on to the next step.
- Page 12 STEP 2 Attach Mount to Speaker Speaker may be installed in either the right-side-up position or up-side-down position , depending on height placement.
- Page 13 STEP 3 Mount Assembly to Wall Plate Install cables Slide onto wall plate Slide cap onto mount...
- Page 14 Adjustments TILT SWIVEL...
- Page 15 To Remove...
