- Page 1 INSTRUCTION MANUAL BUILT-IN WINE COOLER KMWC100 MODEL: E-mail：support@tittla.com Phone：1(510)228-4672 Read this manual and follow all safety rules and operating instructions before first use of this wine cooler.
-
Page 2: Table Of Contents
TABLE OF CONTENTS IMPORTANT SAFETY INSTRUCTIONS PRODUCT DIAGRAM INSTALLATION INSTRUCTIONS Before Using Your wine cooler To Install Stainless Steel Handle To Install Your wine cooler OPERATION INSTRUCTIONS Controls Recommended temperature settings Storage Door Lock Shelves CARE & MAINTENANCE Cleaning Your wine cooler Power Failure Vacation Time Moving Your wine cooler... -
Page 4: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS Your safety and the safety of others are very important. This wine cooler complies with the applicable safety requirements and is safe for daily use. However, basic safety precautions should always be followed when using an electrical appliance, to reduce the risk of fire, electric shock, and personal injury. - Page 5 Do not use this wine cooler for other than its intended purpose. For indoor, household use only. Move this wine cooler by 2 people. Failure to do so can result in injury. Place this wine cooler in a well-ventilated area with temperatures above 15°C (60°F) and below 32°C (90°F).
-
Page 6: Product Diagram
PRODUCT DIAGRAM Control Panel Leveling Legs Shelves Top Hinge Exhaust Window Glass Door with Handle INSTALLATION INSTRUCTIONS Before Using Your wine cooler Remove the exterior and interior packaging. Check to be sure you have all of the following parts: 6 Shelves 2 Keys Stainless Steel Handle... -
Page 7: To Install Stainless Steel Handle
IMPORTANT: Before connecting this wine cooler to a power source, let it stand upright for approximately 24 hours. This will reduce the possibility of a malfunction in the cooling system from handling during transportation. Clean the interior surface with lukewarm water using a soft cloth. ... - Page 8 legs in and out to stabilize the cooler horizontally. If the legs are not properly adjusted, the cooler may be unstable and result in excess noise or vibration. Locate the wine cooler away from direct sunlight and sources of heat (stove, heater, radiator, etc.).
-
Page 9: Operation Instructions
Do not use a cord that shows cracks or abrasion damage along its length or at either end. If the wine cooler is going to be used in an area that is prone to power surges/outages, it is suggested that you use a power surge protector. The surge protector that you select must have a surge block high enough to protect the wine cooler it is connected to. -
Page 10: Storage
Press once to turn ON the cooler. Press and hold about 3 seconds to turn OFF the cooler Press to increase or press to decrease the temperature in 1 degree Upper zone：5-13℃(40-56℉) Lower zone：13-18℃(55-65℉) increments between Press to begin adjusting the temperature for upper or lower zone Toggles the temperature display between Celsius and Fahrenheit. -
Page 11: Care & Maintenance
To Remove a Sliding Shelf 1. Remove all bottles from the shelf. 2. Pull the shelf out as far as it will go. 3. Adjust the lever on each side of the shelf, as shown below (UP on the left, DOWN on the right) and at the same time, pull the shelf out completely. -
Page 12: Power Failure
Power failure Most power failures are corrected within a few hours and should not affect the temperature of your wine cooler. If the power is off for an extended period of time, proper steps should be taken to protect your contents. Vacation Time Leave the wine cooler operating during vacations of less than three weeks. -
Page 13: Charcoal Filtration System
Charcoal filtration system Your wine is a living object that breathes through the cork of its bottle. In order to preserve the quality and taste of your fine wines, they must be stored at the ideal temperature and ambient conditions. Your cellar is equipped with an active charcoal filtration system to ensure air purity, cooling efficiency, and to maintain an odor free cabinet for the storage of your fine wines. -
Page 14: Troubleshooting Guide
TROUBLESHOOTING GUIDE PROBLEM POSSIBLE CAUSE SOLUTION The wine cooler may not be plugged Ensure the wine cooler has been in, or plug may be loose. plugged in properly. The wine cooler Press to turn on the cooler. The wine cooler is turned off. does not run. - Page 15 PROBLEM POSSIBLE CAUSE SOLUTION Not plugged in. Plug the cooler in. The circuit breaker tripped The light does not Check the breaker and/or fuses. or a blown fuse. work. The light button is “OFF”. Press to turn the light ON. The cooler is not leveled.
- Page 16 15 days upon receipt of the product. 2. Customers are entitled to free repair service from TITTLA for any product proven defective in material or workmanship that results in product failure during normal consumer usage and conditions within the valid warranty period, which is 12 months counting from the date of selling.
