Summary of Contents for Inkbird ITH-11-B
- Page 1 ITH-11-B Temperature-Humidity Sensor with IBS-M2S-B WiFi Gateway User Manual...
- Page 2 Please keep this manual properly for reference. You can also scan the QR code below to visit our official website for product instruc- tions. For any usage issues, please feel free to contact us at support@inkbird.com.
- Page 3 Wenn Sie eine Bedienungsanleitung in deutscher Sprache benötigen, scannen Sie bitte den QR-Code und besuchen Sie unsere Website, um sie zu erhalten und ein Video über die Verwendung des Produkts zu sehen. Se avete bisogno di un manuale di istruzioni in italiano, scansionate il codice QR e visitate il nostro sito web per ottenerlo e vedere un video su come utilizzare il prodotto.
- Page 4 Warm tips To quickly jump to a specific chapter page, click on the relevant text on the contents page. You can also use the thumbnail or document outline in the top left corner to quickly find a specific page.
- Page 5 CONTENTS ..........Overview Important Notes/Warnings ......Technical Specifications ..........Product Diagram FCC Requirement ............Key Definitions IC Warning ....... Customer Service APP Installation & Connection...
- Page 6 Technical Specifications IBS-M2S-B WiFi Gateway(receiver): Input Voltage: AC 100~240V 50/60Hz Longest Bluetooth Transmission Distance: up to 262 feet without interference (Interference will limit transmission) Number of ITH-11-B Sensors Supported: up to 10 sensors at the same time...
- Page 7 ITH-11-B BLE sensor (transmitter): Power：2*AAA/3.0V(batteries included) Battery life：9 months Temperature Measurement Range：-40℃～60℃ (-40℉~140℉) Temperature Display Accuracy：0.1℃ (0.1℉) Temperature Measurement Accuracy：±0.2℃ (±0.36℉) Humidity Measurement Range：0％～99％ Humidity Measurement Accuracy：±2％ Humidity Display Accuracy：1％ Temperature-Humidity Sampling Period：3 sec Waterproof Rating：IP65 Warranty: 1 Year...
- Page 8 Product Diagram IBS-M2S-B WiFi Gateway RESET...
- Page 9 ITH-11-B Bluetooth Sensor Please open the back cover to remove the insulation strip and make sure the batteries are inserted correctly, as indicated by the "+" and "-" signs. Then replace the back cover.
- Page 10 Key Definitions IBS-M2S-B WiFi Gateway WiFi Indicator WiFi Button Press and hold the WiFi button for 5 seconds to reset the WiFi pairing. Once reset, follow the pairing steps to reconnect to the WiFi network. Reset Button Press and hold the RESET button for 5 seconds to unbind all sensors.
- Page 11 APP Installation & Connection 5.1 Search the INKBIRD App from Google Play or App Store to get it for free, or you can scan the QR code below to download it directly.
- Page 12 3.The device supports a 2.4GHz Wi-Fi router only. 4.APP Location Permission Requirement: We need to obtain your location information to discover and add nearby devices. INKBIRD promises to keep your location information strictly confidential. And your location informa- tion will only be used for the location function of the App and will not be collected, used, or disclosed to any third party.
- Page 13 5.3 How to Connect Open the INKBIRD app and click “+” on the top right corner to add a device. Then, follow the app instructions to complete the WiFi connection. Note that the device should be as close as possible to the smartphone and router during the connection process.
- Page 14 B: Add the ITH-11-B Bluetooth sensor via the INKBIRD app and then bind the gateway in the app settings page of the ITH-11-B. See below for specific binding steps. Connection Method 1： a)Firstly, plug in the IBS-M2S-B WiFi Gateway and start it up correctly.
- Page 15 Step1 Step2 Device found unconnected Device that is connected The gateway has found the sub-device. Click to add it.
- Page 16 Photo scene of sub-device Battery level of sub-device Current temperature of sub-device Current humidity of sub-device Sub-device model and name Step3...
- Page 17 ITH-11-B Bluetooth sensor, switch it on and place it as close to your smartphone as possible. b)Secondly, open the INKBIRD app and click "+" on the top right corner to add the ITH-11-B Bluetooth sensor.
- Page 18 Step1 Step2 Binding option on the setting page; click to enter the binding page. Select the gateway to bind to and click Confirm to connect.
- Page 19 Photo scene of sub-device Battery level of sub-device Current temperature of sub-device Current humidity of sub-device Sub-device model and name Step3...
- Page 20 Important Notes/Warnings a)Pay attention to the safe use of electronic products and keep children away. b)Please do not disassemble the product if you are not a professional. c)Be sure that the sensor is not covered with dust as dust may lead to inaccurate measurements.
- Page 21 ITH-11-B Bluetooth sensor is out of power. ITH-11-B b. The ITH-11-B Bluetooth sensor is too far away from the gateway or Bluetooth sensor there are obstacles between them. Move the sensor as close as is offline.
- Page 22 FCC Requirement Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
- Page 23 generates, uses, and can radiate radio frequency energy, and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more...
- Page 24 This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20cm between the radiator & your body. This transmitter must not be co-located or operating in conjunc- tion with any other antenna or transmitter.
- Page 25 (2)This device must accept any interference, including interference that may cause undesired operation of the device. L'émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux CNR d'Innovation, Sciences et Développement économique Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : 1)L'appareil ne doit pas produire de brouillage; 2)L'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement. The device meets the exemption from the routine evaluation limits in section 2.5 of RSS 102 andcompliance with RSS-102 RF exposure, users can obtain Canadian information on RF exposure and compliance.
- Page 26 Le dispositif rencontre l'exemption des limites courantes d'évaluation dans la section 2.5 de RSS 102 etla conformité à l'exposition de RSS-102 rf, utilisateurs peut obtenir l'information canadienne surl'expo- sition et la conformité de rf. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. This equipment should be installed and operated with a minimum distance of 20 centimeters between the radiator and your body. Cet émetteur ne doit pas être Co-placé ou ne fonctionnant en même temps qu'aucune autre antenne ouémetteur. Cet équipement devrait être installé et actionné avec une distance minimum de 20 centimètres entre le radiateur et votre corps. ...
- Page 27 This item carries a 1-year warranty against defects in either components or workmanship. During this period, products that prove to be defective will, at the discretion of INKBIRD, be either repaired or replaced without charge. For any problems in use, please feel free to contact us at...
- Page 28 Shenzhen Inkbird Technology Co.,Ltd. support@inkbird.com Consignor: Shenzhen Inkbird Technology Co., Ltd. Office Address: Room 1803, Guowei Building, No.68 Guowei Road, Xianhu Community, Liantang, Luohu District, Shenzhen, China Manufacturer: Shenzhen Inkbird Technology Co., Ltd. Factory Address: 6th Floor, Building 713, Pengji Liantang Industrial Area, No.2 Pengxing Road, Luohu District,...
