Note: Heater above shown with optional Face Trim
Installer: Please take the time to read and understand these instructions prior to installation. Installer
must provide a copy of this manual to the owner.
Owner: Keep this manual in a safe place in order to provide your service technician with the necessary
information.
Warning:
These instructions are intended for qualified personnel, specifically trained and experienced in the
installation and repair of this type of equipment and related system components.
IF NOT INSTALLED, OPERATED AND MAINTAINED IN ACCORDANCE WITH THE
MANUFACTURER'S INSTRUCTIONS, THIS PRODUCT COULD EXPOSE YOU TO
SUBSTANCES IN THE FUEL OR FROM COMBUSTION INCLUDING CARBON
MONOXIDE WHICH CAN CAUSE DEATH OR SERIOUS ILLNESS AND WHICH ARE
KNOWN TO THE STATE OF CALIFORNIA TO CAUSE CANCER, BIRTH DEFECTS
OR REPRODUCTIVE HARM.
For more information go to www.P65WARNINGS.CA.GOV
Infrared Dynamics, Inc © Copyright 2017
Printed in USA
Installation, Operation and & Maintenance Instructions
WARNING: California Proposition 65
Infrared Dynamics, Inc
3830 Prospect Avenue
Yorba Linda, CA 92886
Sunpak S34‐TSR
Outdoor Gas Infrared Patio Heater
NOT FOR USE IN RESIDENTIAL DWELLINGS
Form No 62043 – 8/17
Advertisement
Related Manuals for Alfresco Sunpak S34-TSR
Summary of Contents for Alfresco Sunpak S34-TSR
- Page 1 Sunpak S34‐TSR Outdoor Gas Infrared Patio Heater NOT FOR USE IN RESIDENTIAL DWELLINGS Installation, Operation and & Maintenance Instructions Note: Heater above shown with optional Face Trim Installer: Please take the time to read and understand these instructions prior to installation. Installer must provide a copy of this manual to the owner. Owner: Keep this manual in a safe place in order to provide your service technician with the necessary information.
- Page 2 888-Warm-Glo Sunpak® S34-TSR Infrared Heaters Table of Contents Sunpak heaters work like the sun Warnings projecting radiant heat down to warm your patio and guests. This heater was 2. Basic Operation designed for outdoor installation, 3. Heater Layout and Design however breezes will affect the heating 4.
- Page 3 888-Warm-Glo Sunpak® S34-TSR Infrared Heaters Basic Heater Operation Sunpak S34 TSR is an outdoor gas‐fired infrared heater which is operated with a wireless remote control. The heater can be operated at a High setting with an input of 34,000 BTU/Hr or at a LOW setting of 25,000 BTU/Hr. Each heater comes with wireless operating remote controls that are pre‐programmed for that heater. The number located on the louvered end of the heater corresponds to the number on the remote control. Should the original remote control become lost, additional remote controls can be purchased. However, the heater will need to be re‐ programmed for the new remote control. The Sunpak S34‐TSR should always be started up and operated on the HIGH mode for the first 5 minutes to allow the heater to warm up. Starting up the heater on the LOW mode before the heater is warmed up may cause the heater to shut down prematurely. To correct this situation press the OFF button followed by the ON button and the HI button. Always PRESS the button for at least 1 second to allow proper transmission of the remote signal. Sunpak heaters have a spark ignition and electronic flame safety control. The pilot is only ON while the heater is operating. If the flame safety sensor fails to sense flame at the pilot, the heater will shut down and lockout. This may happen due to low gas pressure or a gusty wind. Should the heater lockout you may be able to hear a faint beeping from the heater control. To restart the heater, first press the OFF button before restarting the heater. Although these heaters are designed for outdoor installation and use, it is important that the wireless remote control(s) be ...
- Page 4 888-Warm-Glo Sunpak® S34-TSR Infrared Heaters Patio Design Consideration Heater Layout and Design Heater placement is critical for effective and efficient ® Sunpak heaters were specifically designed to provide patio heating. If heaters are placed too close together or heated comfort in an outdoor environment. They have been mounted too low, people become uncomfortable.
- Page 5 888-Warm-Glo Sunpak® S34-TSR Infrared Heaters...
- Page 6 888-Warm-Glo Sunpak® S34-TSR Infrared Heaters Warning: Heater must be level in the lengthwise direction. ...
- Page 7 888-Warm-Glo Sunpak® S34-TSR Infrared Heaters Gas Supply Installation/Service Instruction The gas inlet supply pressure and manifold pressure required for Receiving Equipment each heater are listed below. For gas supply line pressures in excess of ½ psi, consult with your gas service provider or the On receipt of equipment it is suggested that a visual inspection be made for external damage to the carton.
- Page 8 888-Warm-Glo Sunpak® S34-TSR Infrared Heaters Gas Piping A minimum pipe size of ½” is required for inlet piping. A ½” leaver handled shut-off gas valve should be installed within 6 feet of the appliance for servicing and as emergency shutoff to the unit.
- Page 9 888-Warm-Glo Sunpak® S34-TSR Infrared Heaters Ventilation Regular Service and Maintenance It is required that areas above the heater be Over time, particularly during long periods of non‐use, properly vented to allow for necessary the heater can accumulate dirt and debris in and combustion air and removal of combustion gases. around the pilot and the burner. Routine maintenance Heaters shall be provided with natural or mechanical means to supply and exhaust at least should be performed at least once a year by a qualified ...
- Page 10 888-Warm-Glo Sunpak® S34-TSR Infrared Heaters Optional Face Trim can be easily installed on all Sunpak models. You must remove the Sunpak Face Trim to connect power to the heater. The Sunpak Face Trim is secured with four (4) screws, two (2) located along each side of the heater. Basic Wiring Sunpak S34‐TSR requires 7.5 VDC for its controls. In most cases you will be running low voltage wire from the Power Adapter plugged into a 120 VAC outlet. The Power Adapter is not water proof and must be weather protected. The extension wire can be run 50 feet with 18 GA and must have suitable outdoor insulation. In order to add the extension wire you must: 1. Remove the Face Trim 2. Disconnect the Power Adapter from the control module. 3. Attach the slide connector to the extension wire. 4. Connect one end of the extension wire cable to the module and the other end to the Power Adapter WARNING: Do not attach the Extension Cable directly to the 120 VAC Outlet. NOTE: Male and Female connections are supplied in the extension kit supplied with each heater ...
- Page 11 888-Warm-Glo Sunpak® S34-TSR Infrared Heaters...
- Page 12 888-Warm-Glo Sunpak® S34-TSR Infrared Heaters...
- Page 13 888-Warm-Glo Sunpak® S34-TSR Infrared Heaters Basic TSR Trouble Shooting Problem Possible Causes How to Fix References No red indicator light on remote Replace batteries in remote control device Basic Operation - Page 3 No Spark to pilot ...
- Page 14 888-Warm-Glo Sunpak® S34-TSR Infrared Heaters Trouble Shooting Remote Controls Error Code: Reason Solution Module has four “beeps” every one Warns user that the pilot Adjust the sensor electrode to 3/16” second flame sensor detects a pilot for the pilot hood and 3/8” from the flame already present when spark electrode. Make sure the ignition sequence is electrode is within the flame zone. initiated. This fault will also occur if pilot flame sensor on main control module is shorted to ground Correct Mounting Angle – Page 4 Four beeps every two seconds Warns users the module’s Provide Proper Ventilation – Page 9 internal temperature has Allow heater to cool down before exceeded 170⁰ F. (77⁰ C.) pressing <Off> then <ON> One beep every four seconds Flame Safety Circuit has Press OFF button to reset then ON to locked out restart heater Each Sunpak TSR comes with wireless controls pre‐programmed for individual heaters. If you have a problem with the remotes, please review the following: 1. Make sure there is power to the unit through the 7.5 VDC plug‐in power adapter.
- Page 15 888-Warm-Glo Sunpak® S34-TSR Infrared Heaters 3. Press and release the learn button on the heater control. Press the <ON> button on the wireless device within 10 seconds. Make sure the remote’s red indicator light went on while pressing the remote. 4. The heater should now recognize the wireless device. a. Press the <OFF> button on the wireless device b. Press the <ON> button c. Press the <HI> button d. Leave heater on HI for first 5 minutes If the heater does not light, repeat procedure 4. It is likely that there is still air in the gas line. If the heater fails to light or fails to stay lit after several tries, it may be necessary to purge the air from the gas line using safe practices. NOTE: Only 3 remote controls can be programed into the heater at one time. It may necessary to clear the memory if a new device does not program properly. To clear the memory, hold the learn button in for over 10 seconds. A series of beeps will indicate memory is cleared. Sunpak Pilot The two electrodes near the pilot provide for flame ignition and sensing. It is important that these electrodes be positioned properly.
- Page 16 888-Warm-Glo Sunpak® S34-TSR Infrared Heaters Limited Warranty THIS WARRANTY IS APPLICABLE TO THE ORIGINAL OWNER ONLY, in accordance with the warranty terms and conditions specified below. Infrared Dynamics (the warrantor) will furnish at our option the ORIGINAL OWNER, 1) a replacement Infrared Dynamics’...
