Installer: Please take the time to read and understand these instructions prior to installation. Installer
must provide a copy of this manual to the owner.
Owner: Keep this manual in a safe place in order to provide your service technician with the
necessary information.
Warning:
These instructions are intended for qualified personnel, specifically trained and experienced in the
installation and repair of this type of equipment and related system components.
IF NOT INSTALLED, OPERATED AND MAINTAINED IN ACCORDANCE WITH THE
MANUFACTURER'S INSTRUCTIONS, THIS PRODUCT COULD EXPOSE YOU TO
SUBSTANCES IN THE FUEL OR FROM COMBUSTION INCLUDING CARBON
MONOXIDE WHICH CAN CAUSE DEATH OR SERIOUS ILLNESS AND WHICH
ARE KNOWN TO THE STATE OF CALIFORNIA TO CAUSE CANCER, BIRTH
DEFECTS OR REPRODUCTIVE HARM.
For more information go to www.P65WARNINGS.CA.GOV
Infrared Dynamics, Inc © Copyright 2017
Printed in USA
Installation, Operation and & Maintenance Instructions
WARNING: California Proposition 65
Infrared Dynamics, Inc
3830 Prospect Avenue
Yorba Linda, CA 92886
Sunpak S34‐TSH
Outdoor Gas Infrared Patio Heater
NOT FOR USE IN RESIDENTIAL DWELLINGS
NOTE: Heater above shown with optional Face Trim
Form No 32047 – 8/17
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Alfresco Sunpak S34-TSH
Summary of Contents for Alfresco Sunpak S34-TSH
- Page 1 Sunpak S34‐TSH Outdoor Gas Infrared Patio Heater NOT FOR USE IN RESIDENTIAL DWELLINGS Installation, Operation and & Maintenance Instructions NOTE: Heater above shown with optional Face Trim Installer: Please take the time to read and understand these instructions prior to installation. Installer must provide a copy of this manual to the owner. Owner: Keep this manual in a safe place in order to provide your service technician with the necessary information.
- Page 2 Alfresco-Heating.com 888-Warm-Glo Sunpak® S34-TSH Infrared Heaters Table of Contents Sunpak heaters work like the sun Warnings projecting radiant heat down to warm your patio and guests. This heater was 2. Basic Operation designed for outdoor installation; 3. Heater Layout and Design however, breezes will affect the heating 4.
- Page 3 Alfresco-Heating.com 888-Warm-Glo Sunpak® S34-TSH Infrared Heaters Basic Heater Operation Sunpak S34‐TSH ® is a two‐stage outdoor gas‐fired infrared heater which is operated with a wired switch. The heater can be operated at a HIGH setting with an input of 34,000 BTU/Hr or at a LOW setting of 25,000 BTU/HR. These heaters require a 24 VAC power source. The fact that these heaters are hardwired to a three‐way switch makes the S34‐TSH well suited for commercial installations. There are no batteries or remote‐control devices to be misplaced. The robust lighted switch makes it easy to see whether the heater is ON. Switch is prewired specifically for the Model S34‐TSH. Switch is made for 24 VAC only. NOTE: Sunpak Heater shown with optional Face Trim The Sunpak S34‐TSH should always be started up and operated on the High mode for the first 5 minutes to allow ® the heater to warm up. Starting up the heater on the LOW mode before the heater is warmed up may cause the heater to shut down prematurely. To correct this situation, press the OFF followed by HIGH. Sunpak ® heaters have a spark ignition and electronic flame safety control. The pilot is only ON while the heater is operating. If the flame safety sensor fails to sense flame at the pilot, the heater will shut down and lockout. This may happen due to low gas pressure or a gusty wind. To restart the heater, first set the switch to OFF before restarting the heater. Although these heaters are designed for outdoor installation and use, it is important that switches, transformers or other operating controls be protected ...
- Page 4 Alfresco-Heating.com 888-Warm-Glo Sunpak® S34-TSH Infrared Heaters Patio Design Consideration Heater Layout and Design Heater placement is critical for effective and efficient ® Sunpak heaters were specifically designed to provide patio heating. If heaters are placed too close together or heated comfort in an outdoor environment. They have been mounted too low, people become uncomfortable.
- Page 5 Alfresco-Heating.com 888-Warm-Glo Sunpak® S34-TSH Infrared Heaters...
- Page 6 Alfresco-Heating.com 888-Warm-Glo Sunpak® S34-TSH Infrared Heaters Warning: Heater must be level in the lengthwise direction. ...
- Page 7 Alfresco-Heating.com 888-Warm-Glo Sunpak® Infrared Heaters Gas Supply Installation/Service Instructions The gas inlet supply pressure and manifold pressures required Receiving Equipment for each heater are listed below. For gas supply line pressures in excess of ½ PSI, consult with your gas service provider or the On receipt of equipment it is suggested that a visual inspection be made for external damage to the carton.
- Page 8 Electrical Heaters subject to vibration shall be provided with 1. Sunpak S34-TSH Heaters need 24 VAC to operate. vibration isolating hangers. A special lighted switch is provided which also Suitable materials for hanging infrared heaters are steel requires 24 VAC.
- Page 9 Alfresco-Heating.com 888-Warm-Glo Sunpak® Infrared Heaters Ventilation Regular Service and Maintenance It is required that areas above the heater be Over time, particularly during long periods of non‐ properly vented to allow for necessary combustion use, the heater can accumulate dirt and debris in air and removal of combustion gases. and around the pilot and the burner. Routine Heaters shall be provided with natural or maintenance should be performed at least once a ...
- Page 10 Alfresco-Heating.com 888-Warm-Glo Sunpak® Infrared Heaters Optional Face Trim can be easily installed on all Sunpak models You must remove the Sunpak Face Trim to connect power to the heater. The Sunpak Face Trim is secured with four (4) screws, two (2) located along each side of the heater. ...
- Page 11 Alfresco-Heating.com 888-Warm-Glo Sunpak® Infrared Heaters...
- Page 12 Alfresco-Heating.com 888-Warm-Glo Sunpak® Infrared Heaters...
- Page 13 Alfresco-Heating.com 888-Warm-Glo Sunpak® Infrared Heaters...
- Page 14 Alfresco-Heating.com 888-Warm-Glo Sunpak® Infrared Heaters Basic TSH Trouble Shooting Problem Possible Causes How to Fix References Verify power to switch No Spark to pilot No blue indicator light on switch Replace Switch Electrical – Page 8 Switch is On No power to the heater ...
- Page 15 Alfresco-Heating.com 888-Warm-Glo Sunpak® Infrared Heaters Limited Warranty THIS WARRANTY IS APPLICABLE TO THE ORIGINAL OWNER ONLY, in accordance with the warranty terms and conditions specified below. Infrared Dynamics (the warrantor) will furnish at our option the ORIGINAL OWNER, 1) a replacement Infrared Dynamics’ heater or 2) a replacement part for any component part which fails before one year when for residential use.
