- Page 1 AIR CONDITIONER (MULTI TYPE) Installation Manual Indoor Unit Model name: For commercial use High-Wall Type MMK-UP0071HP-AE MMK-UP0091HP-AE MMK-UP0121HP-AE English Installation Manual 1 1 21 2 50 11 8 -1...
- Page 2 Installation Manual Original Instruction Please read this Installation Manual carefully before installing the Air Conditioner. • This Manual describes the installation method of the indoor unit. • For installation of the outdoor unit, follow the Installation Manual attached to the outdoor unit. ADOPTION OF NEW REFRIGERANT This Air Conditioner is a new type which adopts a new refrigerant HFC (R410A) instead of the conventional refrigerant R22 in order to prevent destruction of the ozone layer.
- Page 3 The qualified service person is a person who installs, repairs, maintains, relocates and removes the air conditioners made by Toshiba Carrier Corporation. He or she has been trained to install, repair, maintain, relocate and remove the air conditioners made by Toshiba Carrier Corporation...
- Page 4 Installation Manual Definition of Protective Gear When the air conditioner is to be transported, installed, maintained, repaired or removed, wear protective gloves and ‘Safety’ work clothing. In addition to such normal protective gear, wear the protective gear described below when undertaking the special work detailed in the table below.
- Page 5 Installation Manual Warning indications on the air conditioner unit Warning indication Description WARNING WARNING ELECTRICAL SHOCK HAZARD ELECTRICAL SHOCK HAZARD Disconnect all remote electric power supplies Disconnect all remote electric power supplies before servicing. before servicing. WARNING WARNING Moving parts. Moving parts.
- Page 6 Installation Manual PRECAUTIONS FOR SAFETY • Ensure that all Local, National and International regulations are satisfied. • Read this “PRECAUTIONS FOR SAFETY” carefully before Installation. • The precautions described below include the important items regarding safety. Observe them without fail. •...
- Page 7 Installation Manual • Wear protective gloves and safety work clothing during installation, servicing and removal. • Do not touch the aluminium fin of the unit. You may injure yourself if you do so. If the fin must be touched for some reason, first put on protective gloves and safety work clothing, and then proceed.
- Page 8 Installation Manual • Install the indoor unit at least 2.5 m above the floor level since otherwise the users may injure themselves or receive electric shocks if they poke their fingers or other objects into the indoor unit while the air conditioner is running.
- Page 9 Installation Manual Electrical wiring • Only a qualified installer(*1) or qualified service person(*1) is allowed to carry out the electrical work of the air conditioner. Under no circumstances must this work be done by an unqualified individual since failure to carry out the work properly may result in electric shocks and/or electrical leaks.
- Page 10 Installation Manual • After the work has finished, use an insulation tester set (500V Megger) to check the resistance is 1MΩ or more between the charge section and the non-charge metal section (earth section). If the resistance value is low, a disaster such as a leak or electric shock is caused at user’s side.
- Page 11 Installation Manual CAUTION New refrigerant air conditioner installation • This air conditioner adopts the new HFC refrigerant (R410A) which does not destroy ozone layer. • The characteristics of R410A refrigerant are; easy to absorb water, oxidizing membrane or oil, and its pressure is approx. 1.6 times higher than that of refrigerant R22.
- Page 12 Installation Manual ACCESSORY PARTS Part name Q’ty Shape Usage Installation Manual This manual (Hand over to customers) Owner’s Manual (Hand over to customers) Installation plate Wireless remote controller Battery Remote controller holder Mounting screw Ø4 × 25R Flat head wood screw Ø3.1 × 16R ‒...
- Page 13 Installation Manual SELECTION OF INSTALLATION PLACE WARNING • Install the air conditioner at enough strong place to withstand the weight of the unit. If the strength is not enough, the unit may fall down resulting in injury. CAUTION • Do not install the air conditioner in a location subject to a risk of exposure to a combustible gas.
- Page 14 Installation Manual Installation diagram of Indoor and outdoor units Before installing the For the rear left and left piping Hook wireless remote controller 1. Remove the battery Wall Installation cover. plate 2. Insert 2 new batteries (R03 [AAA] type) following the (+) and (-) Insert the cushion between the positions.
- Page 15 Installation Manual Wireless remote controller • A place where there are no obstacles such as a curtain that may block the signal from the indoor unit. • Do not install the remote controller in a place exposed to direct sunlight or close to a heating source, such as a stove.
- Page 16 Installation Manual CUTTING A HOLE AND MOUNTING INSTALLATION PLATE Cutting a hole When the installation plate is directly mounted on the wall In case of installing the refrigerant pipes from the rear: 1. Securely fit the installation plate onto the wall 1.
- Page 17 Installation Manual PIPING AND DRAIN HOSE INSTALLATION Piping and drain hose forming * Apply heat-insulation for both refrigerant pipe and drain hose surely so that no dew generates inside of the equipment. (Use polyethylene foam for insulating material.) Rear right Rear left Bottom left Left...
- Page 18 Installation Manual How to remove the drains cap Clip the drain cap by needle-nose pliers and pull out. How to fix the drains cap 1) Insert hexagonal wrench (dia. 4 mm) in a centre head. 2) Firmly insert drains cap. Do not apply lubricating oil (refrigerant machine oil) when inserting the drain cap.
- Page 19 Installation Manual In case of bottom right or bottom left piping • After scribing slits of the back body with a knife or a marking-off pin, cut them with a pair of nippers or an equivalent tool. Slit Left-hand connection with piping Bend the connecting pipe so that it is laid within 43 mm above the wall surface.
- Page 20 Installation Manual INDOOR UNIT FIXING DRAINAGE 1. Pass the pipe through the hole in the wall, and 1. Run the drain hose sloped downwards. hook the indoor unit on the installation plate at NOTE the upper hooks. • Hole should be made at a slight downward 2.
- Page 21 Installation Manual REFRIGERANT PIPING Refrigerant Piping Permissible Piping Length and Height Difference 1. Use copper pipe with 0.8 mm or more thickness. (In case pipe size is dia. 15.9, with They vary according to the outdoor unit. 1.0 mm or more.) For details, refer to the Installation Manual 2.
- Page 22 Installation Manual Tightening connection Heat insulation Heat insulation for the pipes should be done CAUTION separately for the liquid side and gas side. Because both of the liquid and gas side pipes • Do not apply excessive torque. Otherwise, the become a low temperature during cooling nut may crack depending on the conditions.
- Page 23 Installation Manual ELECTRICAL CONNECTION WARNING REQUIREMENT • For power supply wiring, strictly conform to 1. Using the specifi ed wires, ensure to connect the Local Regulation in each country. the wires, and fi x wires securely so that the • For wiring of power supply of the outdoor units, external tension to the wires do not affect follow the Installation Manual of each the connecting part of the terminals.
- Page 24 Installation Manual Power supply wire and communication wires specifi cations Power supply wire and communication wires are procured locally. For the power supply specifi cations, follow the table below. Power supply wiring and communication wiring are to be procured locally. For specifi...
- Page 25 Installation Manual <In the case of combining with outdoor units of Super Modular Multi System u series (SMMS-u)> Uv line and Uc line (L2, L3, L4) 0.5 mm² (Up to 500 m) Wire size : (2-core shield wire, non-polarity) 0.75 to 1.25 mm² (Up to 1000 m) Uh line (L1) 0.75 to 1.25 mm²...
- Page 26 Installation Manual <In the case of combining with outdoor units other than Super Modular Multi System u series (SMMS-u)> Control wiring between indoor units, and outdoor unit (L2, L3) (2-core shield wire, non-polarity) 1.25 mm² (Up to 1000 m) Wire size : 2.0 mm²...
- Page 27 Installation Manual Wired remote controller wiring This wiring is not required when using the supplied wireless remote controller. • For wiring remote controllers a 2 core non polarity wire must be used. Wired remote controller wiring, remote controller inter-unit wiring Wire size: 0.5 mm²...
- Page 28 Installation Manual Control wiring between indoor and outdoor units NOTE • A wiring diagram below is an example for connection to SMMS-u series. For connecting to other outdoor unit series, refer to the Installation Manual attached to the outdoor unit to be connected. Wiring example Outdoor Power supply Outdoor Power supply...
- Page 29 Installation Manual Wired remote controller wiring • As the wired remote controller wire has non-polarity, there is no problem if connections to indoor unit terminal blocks A and B are reversed. 4 Wiring diagram Terminal block for remote controller wiring Terminal block of indoor unit Wired remote...
- Page 30 Installation Manual Wiring Connection Power supply terminal block Terminal block for How to connect the power supply wiring communication/remote and control wiring controller wiring The power supply wire and the control wire can be Screw connected without removing the front panel. Terminal cover Earth screw REQUIREMENT...
- Page 31 Installation Manual Wiring connection for fl ow selector unit How to connect the wiring of fl ow selector unit Connect the power supply wire and the communication wire supplied with the fl ow selector unit to the indoor unit. 1. Remove the air inlet grille. Open the air inlet grille upward and pull it toward you.
- Page 32 Installation Manual APPLICABLE CONTROLS A wired remote controller is necessary for this function. This function cannot be operate with a wireless remote controller. Changing of settings of for REQUIREMENT applicable controls • When you use this air conditioner for the first time, it takes approx.
- Page 33 Installation Manual Change of lighting time of fi lter Procedure sign Each time you push button, indoor unit numbers in the control group change cyclically. According to the installation condition, the lighting Select the indoor unit you want to change settings time of the filter sign (Notification of filter cleaning) for.
- Page 34 Installation Manual Adjustment of air direction 1. Using the remote controller switch, change the up/down air direction by moving the horizontal louver. 2. Adjust the right/left air direction by bending the vertical grille inside of the air outlet port with hands.
- Page 35 Installation Manual TEST RUN A wired remote controller is necessary for this function. This function cannot be operate with a wireless remote controller. Before test run In case of wired remote controller • Before turning on the circuit breaker, carry out the following procedure.
- Page 36 Installation Manual In case of wireless remote controller (Forced test operation is performed in a different way.) REQUIREMENT • For the operation procedure, be sure to follow the Owner’s Manual. • Finish the forced cooling operation in a short time because it applies excessive strength to the air conditioner.
- Page 37 Installation Manual TROUBLESHOOTING A wired remote controller is necessary for this function. This function cannot be operate with a wireless remote controller. Confi rmation and check Procedure Every pushing of “TEMP.” button used When a trouble occurred in the air conditioner, to set temperature, the trouble history stored in the check code and the indoor UNIT No.
- Page 38 Installation Manual Check method On the remote controller (Wired remote controller, Central control remote controller) and the interface P.C. Board of the outdoor unit (I/F), a check display LCD (Remote controller) or 7-segment display (on the outdoor interface P.C. Board) to display the operation is provided. Therefore the operation status can be known.
- Page 39 Installation Manual Check code Wireless remote controller Wired Sensor block display of Judging Outdoor unit 7-segment display Check code name remote receiving unit device controller Auxiliary code Operation Timer Ready Flash display 01: Outdoor unit of other line connected Other line connected during automatic 02: Indoor unit of other line address connected...
- Page 40 Installation Manual Check code Wireless remote controller Wired Sensor block display of Judging Outdoor unit 7-segment display Check code name remote receiving unit device controller Auxiliary code Operation Timer Ready Flash display — Low pressure protective operation — Oil level down detective protection 01: TK1 sensor trouble 02: TK2 sensor trouble 03: TK3 sensor trouble...
- Page 41 Installation Manual Check code Wireless remote controller Wired Sensor block display of Judging Outdoor unit 7-segment display Check code name remote receiving unit device controller Auxiliary code Operation Timer Ready Flash display P10 Detected indoor unit address Indoor unit overfl ow trouble Indoor unit Outdoor heat exchanger freezing —...
- Page 42 Installation Manual *1 Inverter quantity information *1 Inverter quantity information (Super Modular Multi System i series (SMMS-i)) (Super Modular Multi System e and u series (SMMS-e, SMMS-u)) Comp. Inverter Comp. Trouble Inverter Inverter Inverter Trouble Comp. 1 Comp. 1 Comp. 2 Comp.
- Page 43 Installation Manual WARNINGS ON REFRIGERANT LEAKAGE Check of Concentration Limit NOTE 2 The room in which the air conditioner is to be The standards for minimum room volume are as installed requires a design that in the event of follows. refrigerant gas leaking out, its concentration will (1) No partition (shaded portion) not exceed a set limit.
- Page 44 Installation Manual CONFIRMATION OF INDOOR UNIT SETUP Prior to delivery to the customer, check the address and setup of the indoor unit, which has been installed in this time and fill the check sheet (Table below). Data of four units can be entered in this check sheet. Copy this sheet according to the No.
- Page 45 MEMO...
- Page 46 MEMO...
- Page 48 144 / 9 Moo 5, Bangkadi Industrial Park, Tivanon Road, Tambol Bangkadi, Amphur Muang, Pathumthani 12000, Thailand 1 12 1 25 0 11 8- 1...
