Chapter 1
Name
Powerline
Ethernet
* Five minutes after the device connected to the powerline adapter is turned off or
inactive, the powerline adapter will automatically switch to Power-Saving Mode.
1 2 2 Physical Interface
Note: TL-PA7017 KIT (European version) is used for demonstration in this guide
Power Plug
The powerline adapter has a Plug that can be connected to any power socket.
Pair Button
Press and hold the button for 1 second to join a powerline network. Go to
Powerline Network by Pairing
Press and hold the button for more than 6 seconds to reset the powerline adapter to
factory defaults.
Ethernet Port
Connect the Ethernet port to your wired devices, such as a computer, a router or a
game console, via an Ethernet cable.
Status
The powerline adapter is successfully connected to a
On
powerline network.
The powerline adapter is not connected to any
Off
powerline network.
On The Ethernet port is connected.
Off The Ethernet port is not connected.
for more information.
Get to Know Your Powerline Adapter
Indication
Power Plug
Pair Button
Ethernet Port
Secure Your
