Type 16A Laboratory Concealed Spindle
Stop Tap Swivel Outlet Bench Mounted
Installation and Maintenance Instructions
LCQ110
technical data
Ceramic Disc
Working Pressure Range
Maximum Static Pressure 800 kPa
Maximum Working
Temperature
Enware products are to be installed in accordance with the Plumbing Code of Australia (PCA) and AS/NZS3500.
Installations not complying with PCA and AS/NZS 3500 may void the product and performance warranty provisions.
Reference should also be made to the Australasian Health Facility Guidelines (AHFG), ABCB and Local Government
regulations when considering the choice of, and the installation of these products.
This product must be installed and commissioned by a qualified plumber.
For use with potable water only.
NOTE: Enware Australia advises:
1. Due to ongoing Research and Development, specifications may change without notice.
2. Component specifications may change on some export models.
All measurements are in millimetres.
I00539_16 Feb 2024
1300 369 273 | info@enware.com.au | enware.com.au
Min 50 kPa
Max 500 kPa
85°C (Ceramic Disc)
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Watts ENWARE LCQ110
Summary of Contents for Watts ENWARE LCQ110
- Page 1 Type 16A Laboratory Concealed Spindle Stop Tap Swivel Outlet Bench Mounted Installation and Maintenance Instructions LCQ110 technical data Ceramic Disc Working Pressure Range Min 50 kPa Max 500 kPa Maximum Static Pressure 800 kPa 85°C (Ceramic Disc) Maximum Working Temperature Enware products are to be installed in accordance with the Plumbing Code of Australia (PCA) and AS/NZS3500.
- Page 2 installation • All supply lines must be flushed thoroughly to remove debris prior to the installation of this product, as per AS/NZS 3500.1. Strainers (40 mesh) are recommended if debris is an ongoing problem. • A pressure reduction valve may be required to comply with the recommended maximum supply pressure and/or balanced pressure requirements.
- Page 3 2. Fit the tap frame through the hole. SEE IMAGE 03 Screw backnut from underneath the bench and tighten with a spanner. For a bench with thickness less than 10mm (e.g. stainless steel sinks/ troughs), use the black spacer to cover the anti- rotation pins that protrude past the underside surface.
- Page 4 FITTING INDICATOR BUTTON ONTO HANDLE E nsure the surface of handle is clean and dry, free of dust, moisture and grease. Peel off the indicator button from its backing paper, taking care not to touch the adhesive side. Place the indicator button onto flat section of the handle, and push the button firmly onto handle.
- Page 5 maintenance CLEANING Enware products should be cleaned with a soft damp cloth using only mild liquid detergent or soap and water. Do not use cleaning agents containing a corrosive acid, scouring agent or solvent chemicals. Do not use cream cleaners, as they are abrasive. Use of unsuitable cleaning agents may damage the surface.
- Page 6 troubleshooting PROBLEM CAUSE RECTIFICATION Water leaking from outlet SBA has debris caught in the Remove SBA and inspect. mechanism. Remove debris and clean. Water dripping and does Install an inline strainer. not shut off Tap seat is damaged Refurbish tap seat using a reseating tool.
- Page 7 spare parts Description Part Code SBA Ceramic Disc CSQ380 CS Handle CS378 Indicator Button Hot/Cold Warm MIS595RYB (Adhesive) Vandal Proof Key (for handle) MIS590 CS Top Assembly Bib / Pillar CS390 (handle, SBA) Tube Nozzle SP310 Aerator SP301 Anti-Vandal Aerator with Key SP303 Key for Anti-Vandal Aerator SP304...
- Page 8 - WATTS AUSTRALIA EFFECTIVE FROM 20 November 2023 3. Our responsibilities This Warranty Statement applies to products supplied by Australian Valve (a) In the event that the Supplier is reasonably satisfied that there is a Group Pty Ltd (ACN 068 227 270) (AVG) or Enware Pty Ltd (ACN 662...
