Summary of Contents for Zip Water HydroTap G5 C100
Page 1
Installation instructions HydroTap G5 ® Model : C100, C40 Command Centres 810004 v3.00 08.24 G5 C COMM Online install instructions...
Page 2
INSTALLATION INSTRUCTIONS Table of contents Using these instructions ....................3 Explanation of symbols ............................3 Safety instructions ..............................3 Section 1 IMPORTANT SAFETY INSTRUCTIONS ..............3 Warnings and regulatory information ................5 Technical data ........................6 Supplied parts checklist ....................7 Installation checklist ......................8 Before installation ......................
Page 3
Using these instructions Explanation of symbols Button/ WARNING DANGER DANGER DANGER Read the coin battery WARNING Electric shock Hot surface Flammable instructions Safety instructions Read and use the instructions and safety information supplied with individual kit components for a safe installation. Section 1 IMPORTANT SAFETY INSTRUCTIONS Compliance In Australia electrical installation must comply with AS/NZS3000.
Page 4
IMPORTANT SAFETY INSTRUCTIONS of the Command Centre is marked on the packaging. Do not lift the Command Centre by the front cover or any of its connections. Airflow The Zip HydroTap operates within the ambient temperature range 5ºC - 35ºC. Proper air circulation must be provided.
Page 5
WARNINGS AND REGULATORY INFORMATION • For continued safety of this appliance it must be installed, operated and maintained in accordance with the manufacturer’s instructions. • The Zip HydroTap must be earthed, earthing is provided via the supplied power cord. The resistance of the earth connection to each exposed metal part must be less than 1Ω. Use the power cable supplied.
Page 6
Technical data Technical data table Dimensions Power rating kW Power rating kW Weight Model W x D x H (mm) 220-240V 50Hz 220V 60Hz (kg) Command Centre only Chilled models C100 0.34 0.37 280 x 499 x 333 24.2 0.16 0.19 280 x 499 x 333 24.2...
Page 7
Supplied parts checklist C40, C100 models HydroTap Parts supplied in the kit C100, C40 HydroTap tap, pipes, tubes hoses and fittings Vented Mixer Tap, hoses, fittings & instructions Mains Mixer Tap, hoses, Optional fittings & instructions Command Centre ...
Page 8
Installation checklist • Check if there is adequate space to install all of the components. • Note Not all fittings are supplied with the appliance kit. Isolation valves are not supplied. • Check the mains water pressure is within min / max requirements. •...
Page 9
Before installation • Review of all the technical specifications. • Ensure the under counter cupboard floor can support the product weight when full of water (allow an extra 3-8kg when full). • Sufficient space in the cupboard to install the Command Centre and other components in accordance with these installation instructions.
Page 10
General product features Thank you for purchasing a Zip HydroTap G5. Please read and follow these instructions carefully to ensure safe and trouble free operation. If help and advice is required, contact your local service provider. What is the Zip HydroTap G5 ? This Zip HydroTap G5 is an electronically controlled, filtered, boiling, chilled and sparkling (functionality is dependant upon model purchased) drinking water system for the kitchen.
Page 11
Section 2 Ventilation Read and use the instructions and safety information supplied with individual kit components for a safe installation. Clearance envelope & airflow The integrated vent aperture must be cut out of the cupboard floor & mounting plate fitted. The vent provides a safe exhaust for the refrigerant gas in the unlikely event of a leak.
Page 12
Section 2 Ventilation C40, C100 ventilation options Vent grilles & plates cut-outs Option 1: Ventilation arrangement using large cupboard with For integrated vent cut-out, check min. 40mm overhang Directing warm air straight into the room. size relative to your product. Must be installed For Command Centre width 280mm C l e...
Page 13
Section 2 Ventilation C40, C100 ventilation options, continued Option 3: Ventilation arrangement if using a large cupboard with less than 40mm, or no overhang. Directing warm air into the kick space & out through a vent grille. Must be installed Must be installed C l e a r a...
Page 14
Section 3 Ancillary Installations - Install Rail installation (UK only) Description • The install rails can be used to safely connect a wide range of water appliances to the mains water supply. The install rails include an isolation valve, double check valves, tamper proof pressure reducing valve pre- set to 0.3 MPa and a flood preventer with reset.
Page 15
Section 3 Ancillary Installations - Connect to the water supply Connect the braided hose to the mains water supply Valves and fittings must be sealed with PTFE tape if compression seals are not included. Note correct strainer orientation. Note Mixer tap installations also use a ‘Tee piece’ as part of the water supply plumbing connections, see the Tap installation instructions supplied with the Mixer Tap to connect the water supply if using the mixer tap option.
Page 16
Section 4 Command Centre installation Generic installation arrangement instructions Read these instructions together with those supplied with individual components before commencing Command Centre installation,they apply to all installation arrangements. • Install the mains water braided hoses to the Command Centre before locating in place.
Page 17
Section 4 Command Centre installation John Guest pipe and fittings Take care to use correctly, see below : Insert Remove 2. Pull pipe 1. Cut pipe clean & square 1. Press collet 2. Push pipe to down end stop Mains power cable Do not connect to the mains socket until commissioning Connect Command Centre to HydroTap.
Page 18
Section 4 Command Centre installation C40, C100 models, general layout Command Centre Mains electrical power connector Tap - Command Centre USB Mains water supply Mains braided hose - Command Centre manifold Mains braided hose - Command Centre Water supply connection For UK, use install rail 810004 v3.00 08.24 G5 C COMM Online install instructions...
Page 19
Section 4 Command Centre installation C40, C100 models with Celsius mixer tap, general layout Command Centre Mains electrical power connector Tap - Command Centre USB Mains water supply Mains braided hose - Command Centre manifold Mains braided hose - Command Centre Water supply connection For UK, use install rail 810004 v3.00 08.24 G5 C COMM Online install instructions...
Page 20
BC res Section 4 Command Centre installation check USB C40, C100 HydroTap G5 models position MAINS MIXER MIXER BOILING BYPASS VENT BYPASS CHILLED Command Centre connections OUTLET Braided hose HydroTap B res comm Connections key Fit foam insulation (supplied) to MAINS MIXER MIXER...
Page 21
BC res Section 4 Command Centre installation check USB C40, C100 Chilled and mixed hot & cold models position MAINS MIXER MIXER BOILING BYPASS VENT BYPASS CHILLED OUTLET Command Centre connections Braided hose HydroTap B res comm Connections key Fit foam insulation (supplied) to MAINS MIXER MIXER...
Page 22
Section 5 Commissioning Commissioning using the HydroTap Clean can The HydroTap Clean process HydroTap Clean is a first to market cleaning process for HydroTap systems comprised of the HydroTap Clean solution, dosing adaptor and smart firmware. The HydroTap Clean process is automated and gently cleans the chilled and sparkling water paths during the commissioning of a new HydroTap Command Centre.
Page 23
Section 5 Commissioning Select the language • Touch the appropriate button to select the language and units of LANGUAGE 10:50 choice. • Touch the back arrow to go back to previous menu. • In the previous menu, touch the arrow to begin the commissioning process.
Page 24
Section 5 Commissioning Set the date, time & drain away options • Touch the date and time, use "-" or "+" to make adjustments. When DATE & TIME 10:50 ready, touch the arrow to continue. 2021 24 hr Time • Select 'Sink / Container' or 'Font' depending on the model , see DRAIN AWAY OPTION 9:26 below.
Page 25
Section 5 Commissioning FILTER FLUSH 12:12 PM FILTER HAS BEEN FLUSHED! Turn the flush line STOP COCK VALVE back to the OFF position Your filter has now been flushed and is ready to use. You will need to check the life span of the filter in filter settings •...
Page 26
Section 5 Commissioning Cleaning preparation HYDROTAP CLEAN PREPARATION 12:12 PM • Read the on screen information. Step 1. Insert cloth below filter. Step 2. Remove filter and refit dust cap. • Place a cloth under the filter. • Remove the filter, refit the dust cap, and set aside in a clean environment.
Page 27
Section 5 Commissioning Filter head and HydroTap Clean adapter (1) • Screw the HydroTap Clean can (2) into the adapter (already installed into the filter head). HydroTap Clean can (2) • Confirm installation of the HydroTap Clean can by selecting YES HYDROTAP CLEAN PREPARATION 12:12 PM on the screen.
Page 28
Section 5 Commissioning • This screen is shown after completion of the cleaning process. 12:12 PM RE-INSTALL FILTER If the below steps have not been completed. Follow the instructions below. Step 1. Ensure cloth is below HydroTap Clean can (2). Step 2.
Page 29
Section 5 Commissioning Tank flush • Read the on screen information and instructions. TANK FLUSH 12:12 PM • Touch the green arrow to run. Fresh water will be flushed through the tank/s multipe times as shown by the cycle counter/s. Enabling ‘Auto Dispense’...
Page 30
Section 6 Service and Trouble shooting Service items • Filters should be replaced at six month intervals for Commercial HydroTaps, and 12 month intervals for Residential HydroTaps. • CO2 regulator washers should be replaced annually. Trouble shooting table Fault Fault name Fault trigger code Power Board Fault...
Page 31
Section 7 Operation and Maintenance Please refer to the User Guide for all operational and maintenance features of the HydroTap. The User Guide is located in the HydroTap Command Centre filter door. Zip offers a fully-inclusive HydroCare Service Plan to take care of all routine maintenance, including filter replacements, sanitisation, electrical safety inspections as well as general maintenance of your HydroTap.
Page 32
Section 8 End of life disposal Waste electrical and electronic equipment The symbol above means that according to United Kingdom and European Union member countries laws and regulations, your product and /or its battery shall be disposed of separately from household waste. When this product reaches its end of life, take it to a collection point designated by local authorities.
Page 33
WMKA00099 WMKA21821 AS 3498 AU02691 WMTS-105 Zip Water Zip Water UK 67 - 77 Allingham Street, Trafalgar House, Condell Park, NSW 2200 Rash’s Green, Dereham, Postal: Locked Bag 80, Norfolk, NR19 1JG Bankstown 1885 0345 6 005 005 Australia sales@zipindustries.co.uk (+612) 9796 3100 www.zipwater.co.uk...
