- Page 1 LC532VC9HK Extractor hood EN User manual and installation instructions 登陆西门子家电官网注册您的家电产品，尽享专业服务。 Siemens Home Appliances...
- Page 2 en Safety Table of contents 1.3 Restriction on user group This appliance may be used by children aged INFORMATION FOR USE 15 or over and by people who have reduced physical, sensory or mental abilities or inad- Safety .............. 2 equate experience and/or knowledge, Avoiding material damage........ 3 provided that they are supervised or have been instructed on how to use the appliance...
- Page 3 Avoiding material damage en Hot oil or grease ignites very quickly. WARNING ‒ Risk of electric shock! ▶ Always supervise hot oil and fat. An ingress of moisture can cause an electric ▶ Never extinguish burning oil or fat with wa- shock. ter. Switch off the cooking zone. Extinguish ▶...
- Page 4 en Environmental protection and saving energy Environmental protection and saving energy 3 Environmental protection and saving energy 3.1 Disposing of packaging The packaging materials are environmentally compat- ible and can be recycled. Sort the individual components by type and dispose ▶ of them separately. 3.2 Saving energy If you follow these instructions, your appliance will use less power.
- Page 5 4.1 Appliance Controls You can find an overview of the parts of your appliance Deflector panel here. Oil cup 4.2 Technical Data Product model LC532VC9HK Power supply 220 V~ / 50 Hz Total appliance rated 284 W power input Motor rated power input 280 W Lamp rated power input 2 W x 2...
- Page 6 en Cleaning and servicing After starting self-cleaning, do not walk away to prevent Stop self-cleaning accidents. Touch during self-cleaning operation. The cumulative operating time of the appliance is re- Starting self-cleaning set. Touch ，self-cleaning will operate 30 minutes. ▶ lights off. a Au audible sounds，...
- Page 7 Troubleshooting en Remove the filter with a screwdriver. 6.4 Cleaning deflector panel and filter Gently push the panel inward to disengage the hook at the front from the lock of the appliance, hold the panel and slowly turn it downwards. Place the panel and filter in hot detergent water and soak for no more than ten minutes.
- Page 8 en Customer Service Fault Cause and troubleshooting Lighting does not The lamp is defective. work. Call ▶ → "Customer Service", Page 8. The suction power is Kitchen air ventilation. not strong. Close the windows smaller. ▶ The extraction resistance is high. Select the highest fan setting. ▶...
- Page 9 Installation instructions en ▶ If the appliance or the power cord is dam- Grease deposits in the grease filter may catch aged, immediately unplug the power cord fire. or switch off the fuse in the fuse box. ▶ The specified safety clearances must be ▶...
- Page 10 en Installation instructions 10.3 Ceiling cut-out Name Quantity Instructions for installation and use 1 pc For the installation of the cooker hood, please carefully check the appliance and cabinet dimensions, unit: mm. Pipe socket and seal 1 set Hanging plate 1 pc Decorative cover 1 set 50mm...
- Page 11 Installation instructions en 10.4 Appliance and cabinet dimensions For the installation and subsequent maintenance of the cooker hood, please carefully check the appliance and cab- inet dimensions, unit: mm. Symbol Name Requirement Installation wall The diameter of the wall hole is recommended to be 150 mm. If the wall hole is too small, it will affect the smoke exhaust effect.
- Page 12 en Installation instructions Measure and mark the positions of the hood WARNING ‒ Risk of electric shock! hanging screws, safety limit screws, and decorative It must always be possible to disconnect the appliance cover hanging screws. from the electricity supply. The appliance must only be Note: The decorative cover hanger is used to fix the connected to a protective contact socket that has been auxiliary decorative cover.
- Page 13 Installation instructions en Refer to the installation diagram. If the hanger is x1: Installing the deflector panel 45mm in step 4 of installation diagram, please ig- Hook the hook at the rear of the panel to the lock of nore this step. If the hanger is x2: 62mm in step 4 the appliance.
- Page 14 en Installation instructions Connect the exhaust pipe to the pipe socket and se- Connecting the appliance to the electricity cure it with ST3x14 screws. supply Insert the mains plug of the appliance's power cable in a socket nearby. Check the mains plug is inserted properly. a The appliance is now ready for use.
- Page 16 EN Manufactured by BSH Hausgeräte GmbH under the trademark licence of Siemens AG BSH Hausgeräte GmbH Carl-Wery-Straße 34 81739 München, GERMANY siemens-home.bsh-group.com *8001319364* 8001319364 (040927) 01...
