SERVICE PARTS
74013T-4ND
74026T-4ND
1242786**
1209778**
1209777
1196248
1209774
74026T-4ND:836664
**Color code must be specified when ordering.
1285742-AN2-B
Single Lever Basin Mixer
Single Lever Tall Basin Mixer
833438
3008523
1054593
870817
74013T-4ND:1280659
74026T-4ND:1280658
1281228
1220841
1209787
74013T-4ND:836549
1228834
TAUT
INSTALLATION INSTRUCTIONS
BEFORE YOU BEGIN
All information is based on the latest product information available at the time of publication. Kohler Co. reserves
the right to make changes in product characteristics, packaging, or availability at any time without notice.
Please leave these instructions for the consumer. They contain important information.
NOTES:
1. Flush the water supply pipes thoroughly to remove debris.
2. An inline water filter must be used with this product.
3. If possible, install this basin mixer before installing the basin.
4. Inspect the supply tubing for damage and leakage. Replace and maintain as necessary.
5. Observe local plumbing codes.
6. Shut off the water supplies to the fitting.
7. All installations should comply with the relevant requirements of AS/NZS 3500 and AS/NZS 6400.
ROUGH-IN DIMENSIONS
4
1285742-AN2-B
74013T-4ND
Single Lever Basin Mixer
74026T-4ND
Single Lever Tall Basin Mixer
20°
120
Ø33~Ø36
G1/2˝
TAUT
74026T-4ND
1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Kohler TAUT 74013T-4ND
Summary of Contents for Kohler TAUT 74013T-4ND
- Page 1 Single Lever Tall Basin Mixer BEFORE YOU BEGIN 1242786** All information is based on the latest product information available at the time of publication. Kohler Co. reserves the right to make changes in product characteristics, packaging, or availability at any time without notice. 833438 1209778** Please leave these instructions for the consumer.
- Page 2 Many cleaners may contain chemicals, such as ammonia, chlorine, toilet cleaner etc, which could adversely affect the finish and are not recommended for cleaning. 74013T-4ND Do not use abrasive cleaners or solvents on Kohler faucets and fittings. INSTALLATION Install the mounting stud(2) onto the faucet body base(3).
