UAS 684
201500001
Universal Quatro feed system 10,70-12,75 GHz
About this Guide
This document is part of the product. These instructions
describe how to install and connect the feed system UAS
684.
► Read these instructions for use before the initial use of
the antenna set.
► Perform all operating steps described in the manuals
in the specified sequence.
For the most up-to-date version of this document, go to
www.kathrein-ds.com.
Keep these instructions for future reference.
Pass them on to any new owners when
selling or transferring the unit.
Features
■
Universal Quatro feed system with 4 outputs
■
Suitable for Kathrein offset sat antennas, type CAS.. (60, 80, 90, 120 cm Ø)
■
For reception of satellites in the Ku band, such as ASTRA, EUTELSAT and TürkSat
■
Energy saving - only max. 1,4 W power consumption
■
The feed system complies with ASTRA specifications for universal Quatro feed systems
■
Power supply via coax cable
■
Multifeed-suitable due to compact design
■
Full protection of LNB and cable connections in a ventilated housing, protection category IP 54
Scope of Delivery
■
UAS 684
■
4 x F-type plug
■
Azimut-/elevations table
Instructions for use
■
Transport and Storage
► Transport and store the device in its original packaging.
► Make sure there is no water condensation build-up.
Intended Use
► The device described is designed solely for the installation of satellite receiver systems and may only be installed by
trained specialist personnel.
► The UAS 684 feed system may only be mounted to the listed Kathrein sat antennas.
► If it is used in any other way or if the provisions of this document are disregarded, the guarantee and warranty will
become void.
► The manufacturer is not liable for accidents caused by the user on the opened device.
► Unauthorized opening and repair attempts lead to the loss of the warranty claim.
1 / 8
Advertisement
Table of Contents
Related Manuals for Kathrein Universal Quatro UAS 684
Summary of Contents for Kathrein Universal Quatro UAS 684
- Page 1 ► The UAS 684 feed system may only be mounted to the listed Kathrein sat antennas. ► If it is used in any other way or if the provisions of this document are disregarded, the guarantee and warranty will become void.
-
Page 2: Safety Instructions
Safety Instructions The UAS 684 feed system may only be mounted to the listed Kathrein sat antennas. The feed system is subject to the same safety and danger warnings as listed in the instructions for using offset sat antennas. Please follow these instructions at all times, as otherwise you or other people may be exposed to danger (electric shock through overhead lines, risk of falling down, falling parts, thunder- storm etc.). - Page 3 ② then return to “Cable connection”. 2. Mount the supplied F-type plug onto the Kathrein cable types LCD 90, LCD 111 A+, LCD 115 A+, LCD 120 A+ oder LCD 130 A+ and connect to the LNB (see Fig. 4).
- Page 4 2. Tune to wanted satellite (see enclosed azimuth/eleva- Azimut tions table) by turning the antenna around the azimuth axle until max. signal level is obtained (if a Kathrein signal meter MSK... is used), or until best signal strength/quality is reached (see Fig. 7 and „Level opti- Elevation mization“).
- Page 5 Pre-setting the polarisation for compact feed systems in various countries 5 / 8...
-
Page 6: Application Examples
Application examples UAS 582 with Multi-Switch EXR 158 / E S C . E S D . . U A S 6 8 4 H hi gh V hi gh st ria l Te rre H lo w /55 0m 18 V V lo w 1 / 1 2... -
Page 7: Simplified Eu Declaration Of Conformity
Simplified EU Declaration of Conformity Hereby, KATHREIN Digital Systems GmbH declares that the radio equipment type UAS 684, order no.: 201500001 is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: www.kathrein-ds.com... - Page 8 | support@kathrein-ds.com 936500157/b/A4/MK/0123/GB | Subject to change. KATHREIN Digital Systems GmbH Anton-Kathrein-Str. 1–3 83022 Rosenheim Germany Phone +49 731 270 909 70...
