- Page 1 Manual of LED KIT TWLED-4PD2 TWLED-4PD2_LED_KIT_Manual_uk_00_20240830.pdf Version -00, 30.08.2024...
- Page 2 Manual of LED KIT TWLED-4PD2 Table of contents 1. General information ..........................1 2. Identification of the instructions for use ....................1 3. Technical data ............................2 4. Photometric data ........................... 2 5. Scope of delivery ............................ 2 6. Installation ............................. 4 7.
- Page 3 1. General information The Twin Busch LED lighting TWLED-4PD2 has been specially developed for our TW436PD2-G 4-post car park lift. A set consists of 4 flexible and magnetic LED light strips / LED strips, a transformer, power and connection cables, a remote control and the necessary mounting and installation material.
- Page 4 Manual of LED KIT TWLED-4PD2 3. Technical data IP class IP67 Power supply 230 V Energy consumption 229 W Average service life* ca. 50.000 h Ambient temperature -10° C bis +45° C Width x height 15 x 9 mm *When installed correctly with product-compliant thermal management.
- Page 5 Manual of LED KIT TWLED-4PD2 Page | 3 Misprints, errors and changes excepted.
- Page 6 Manual of LED KIT TWLED-4PD2 6. Installation Inspect the outer packaging for external damage or signs of improper handling during transport. Open the packaging carefully and check the contents for completeness. Ensure that all components listed in the scope of delivery are present (see Scope of delivery).
- Page 7 - Magnetically attach the controller and transformer to the column and connect them with the connecting cables. 6. Installation - Connect the TWLED-4PD2 to a standard 230 V socket or directly in the switch box of the lift. Refer to the wiring diagram of the lift for the exact information. Page | 5...
- Page 8 Manual of LED KIT TWLED-4PD2 7. Controlling the remote control 7.1 Connection of remote control and controller 1. Connection of the LED strip lights - Connect the LED strip lights, the controller and the power supply unit. This should be done with the power switched off to ensure safe installation.
- Page 9 Manual of LED KIT TWLED-4PD2 7.2 Operating the light colour The upper buttons are used to control the RGB lighting, in which white light (W) is generated by mixing red (R), green (G) and blue (B). The buttons on the white background in the centre area are intended for controlling the 6000 K white light.
- Page 10 Notes...
- Page 11 Notes...
