O O W W N N E E R R ' ' S S M M A A N N U U A A L L
O O p p e e r r a a t t i i o o n n
M M a a i i n n t t e e n n a a n n c c e e
S S p p e e c c i i f f i i c c a a t t i i o o n n s s
All information in this Owner's Manual is current at the time of publica-
tion. However, HYUNDAI reserves the right to make changes at any time
so that our policy of continual product improvement may be carried out.
This manual applies to all models of this vehicle and includes
descriptions and explanations of optional as well as standard equip-
ment. As a result, you may find material in this manual that does not
apply to your specific vehicle.
