rM2410
rM2510
FOR YOUR SAFETY
If you smell gas:
1. Open windows.
2. Don't touch electrical switches.
3. Extinguish any open flame.
4. Immediately call your gas supplier.
FOR YOUR SAFETY
Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
!
WARNING
Improper installation, adjustment, altera-
tion, service or maintenance can cause
injury or property damage. Refer to this
manual. For assistance or additional infor-
mation consult a qualified installer, serv-
ice agency or the gas
supplier.
USA
Service Office
Dometic Corporation
2320 Industrial Pkwy.
Elkhart, IN 46516
Phone: 574-294-2511
820459603
©2006 Dometic Corporation
LaGrange, IN 46761
®
Corporate Office
2320 Industrial Parkway Elkhart, IN 46515
For Service Center Assistance
Call: 800-544-4881
installation and
operating instructions
REFRIGERATOR FOR LP-GAS
& ELECTRIC OPERATION
POUR vOTRE SéCURITé
Si vous sentez une odeur de gaz:
1. Ouvrez les fenêtres.
2. Ne touchez à aucun interrupteur.
3. Éteignez toute flamme nue.
4. Avertissez immédiatement votre
fournisseur de gaz.
POUR vOTRE SéCURITé
Ne pas entreposer ni utiliser de l'essence
ni d'autres vapeurs ou liquides inflamma-
bles à proximité de cet appareil ou de tout
autre appareil.
!
AVERTISSEMENT
Une installation, un réglage, une modifi-
cation, une réparation ou un entretien non
conforme aux normes peut entraîner des
blessures ou des dommages matériels.
Lisez attentivement le mode d'emploi
fourni avec l'appareil. Pour obtenir de
l'aide ou des renseignements supplémen-
taires, consultez un installateur ou un
service d'entretien qualifié ou le fournis-
seur de gaz.
®
CANADA
Dometic Corporation
46 Zatonski, Unit 3
Brantford, ON N3T 5L8
CANADA
Phone: 519-720-9578
MO-M 0651
