FabLite Tension Fabric FL-TF-30-05
FL-TF-30-05
FabLite 30ft displays have unique stylistic features and shapes, are portable
and easy to assemble. The aluminum tube frame features snap-buttons and/ or
spigot connections and zipper pillowcase fabric graphics. All displays come in
portable, wheeled transit cases. Simply pull the pillowcase fabric graphic(s)
over the frame and zip.
features and benefits:
- Premium aluminum tube frames with snap
button/ spigot assembly
- Serpentine shaped frame
- Easy to store and ship
- Quick to set up
- Weighted feet for added stability
dimensions:
Hardware
Assembled unit:
350"w x 92"h x 48"d
8890mm(w) x 2337mm(h) x 1219mm(d)
Approximate weight with cases:
135 lbs / 61.2 kgs
Shipping
Packing case(s):
2 OCE Cases
Shipping dimensions:
OCE: Expandable case length(l) may vary
40''-66"l x 18"h x 18"d
1016mm-1677mm(l) x 458mm(h) x 458mm(d)
Approximate total shipping weight
(includes cases & graphics):
168 lbs / 76.2 kgs
- Zipper pillowcase fabric graphic
- Lifetime limited hardware warranty against
manufacturer defects
