Sharp ES-FW1014SB User Manual

Sharp ES-FW1014SB User Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
EN
Washing Machine / User Manual
ES-FW1014SB

Advertisement

loading
Need help?

Need help?

Do you have a question about the ES-FW1014SB and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sharp ES-FW1014SB

Summary of Contents for Sharp ES-FW1014SB

  • Page 1 Washing Machine / User Manual ES-FW1014SB...
  • Page 2 Thank you for choosing this product. This User Manual contains important safety information and instructions on the operation and maintenance of your appliance. Please take the time to read this User Manual before using your appliance and keep this book for future reference. Icon Type Meaning...
  • Page 3 CONTENTS 1. SAFETY INSTRUCTIONS ....................1 1.1 General Safety Warnings ....................2 1.2 During Use ........................7 1.3 Packaging and Environment...................8 1.4 Savings Information ......................8 2. TECHNICAL SPECIFICATIONS ..................9 2.1 General Appearance.......................9 2.2 Technical Specifications ....................9 3. INSTALLATION .......................10 3.1 Removing the Transit Bolts...................10 3.2 Adjusting the Feet / Adjusting Adjustable Stays............10 3.3 Electrical Connection ....................10 3.4 Water Inlet Hose Connection ..................
  • Page 4 1. SAFETY INSTRUCTIONS Operating voltage / frequency (220-240) V~/50Hz Total current (A) Water pressure (Mpa) Maximum 1 Mpa / Minimum 0. 1Mpa Total power (W) 2200 Maximum washing capacity (dry laundry) (kg) • Do not install your machine on a carpet or such grounds that would prevent the ventilation of its base.
  • Page 5 NOTE: For a softcopy of this user manual, please contact the following address: “washingmachine@standardtest. info”. In your e-mail, please provide the model name and serial number (20 digits) which you can find on the appliance door. Read this user manual carefully. Your machine is for domestic use only.
  • Page 6 exposed to air for a long period of time. Only put softener or detergent in the drawer at the beginning of each wash. • Unplug your Washing Machine and switch off the water supply if the Washing Machine is left unused for a long time.
  • Page 7 your machine. • Please follow the manufacturers’ instructions regarding the use of fabric conditioner or any similar products that you intend to use in your Washing Machine. • Make sure that the door of your Washing Machine is not restricted and can be opened fully. Install your machine in a location that can be fully ventilated and preferably has constant air circulation.
  • Page 8 water while your Washing Machine is running. The high temperatures involved pose a burn risk. RISK OF DEATH FROM ELECTRICAL CURRENT • Do not connect your Washing Machine to the mains electricity supply using an extension lead. • Do not insert a damaged plug into a socket. •...
  • Page 9 your machine. • Never use products that contain solvents in your machine. • Please ensure that garments loaded into your Washing Machine are free from foreign objects such as nails, needles, lighters and coins. Risk of fire and explosion Risk of falling and injury •...
  • Page 10 1.2 During Use • Keep pets away from your machine. • Please check the packaging of your machine before installation and the outer surface of the machine once the packaging has been removed. Do not operate the machine if it appears damaged or if the packaging has been opened.
  • Page 11 NOTE: Specifications for the machine may vary depending on the product purchased. Replacement of drive belt, only by authorized service. Only original spare belt must use. 1.3 Packaging and Environment Removal of packaging materials Packaging materials protect your machine from any damage that might occur during transportation.
  • Page 12 2. TECHNICAL SPECIFICATIONS 2.2 Technical Specifications Operating voltage / (220-240) frequency V~/50Hz (V/Hz) Total current Maximum: Water 1 Mpa pressure Minimum : (Mpa) 0.1 Mpa Total power 2200 Maximum dry laundry capacity (kg) Spinning revolution 1400 (rev / min) Programme number 2.1 General Appearance Dimensions...
  • Page 13 3. INSTALLATION 3.2 Adjusting the Feet / Adjusting Adjustable Stays 3.1 Removing the Transit Bolts 1. Do not install your machine on a surface (such as carpet) that would prevent ventilation at the base. • To ensure silent and vibration-free operation of your machine, install it on a firm surface.
  • Page 14 240V, 50 mains supply. and cold) depending on the machine specifications. The white capped hose • The mains cord of your washing should be connected to cold water inlet machine is equipped with an earthed and red capped hose to the hot water plug.
  • Page 15 supply using the supplied new fill hose. Old 4.1 Detergent Drawer (*) hoses must not be reused. 3.5 Water Discharge Connection • Connect the water drain hose to a standpipe or to the outlet elbow of a household sink, using additional equipment.
  • Page 16 4.2 Sections 4.3 Program Dial Main wash detergent compartment: This compartment is for liquid or powder • To select the desired programme, turn detergents or limescale remover. The fluid the programme dial either clockwise or detergent level plate will be supplied inside anti-clockwise until the marker on the your machine.
  • Page 17 5. USING YOUR curtains or place them in a washing net or bag. WASHING MACHINE 6. Reverse textiles such as pants, knitwear, t-shirts and sweat shirts. 5.1 Preparing Your Laundry 7. Wash socks, handkerchiefs and other small items in a washing net. Can be Normal Do not bleach...
  • Page 18 information on load capacities. • The amount of the detergent required will increase with higher washing loads. The following table shows approximate weights of typical laundry items: • Put softener in the middle compartment of the detergent drawer. Do not exceed LAUNDRY TYPE WEIGHT (gr) the MAX level.
  • Page 19 (*) Model Dependant • Press the delay key until you reach the time after which you want the machine 5.7 Auxiliary Functions to start the washing cycle. • If you have skipped the delay time you would like to set, you can keep pressing the delay key until you reach that time again.
  • Page 20 warm rinse before the selected programme and will add new washing steps for selected washing program. This will soak 3. Stain selection the laundry with warm water to soften the mix stains before the selected washing programme starts. For any other stain selection, similar stain removal solutions are available.
  • Page 21 5. Spin speed selection 6.1 Prewash auxiliary function You can use the speed setting key to set the spin speed for your laundry. When You can use this auxiliary function to you select a new program, the selected perform pre-wash before the main wash program’s maximum spin speed will be cycle for your highly soiled laundry.
  • Page 22 6.3 Steam Assist auxiliary function 7. Eco/Quick Wash auxiliary function Eco washing auxiliary function: Owing to the steam system ironing has If you select this auxiliary function, your become quick and as easy. The steam used machine will slightly extend the duration dream washing penetrates and loosens the of the washing program.
  • Page 23 temperature setting, spin speed and other the electronic display disappears. auxiliary functions. Note: Door remains unlocked in case when child lock is active and electricity is Start/Pause button cut off 5.9 If you want to pause/cancel a running program or add laundry: •...
  • Page 24 5.10 Program End Your machine will automatically stop when the selected program ends. • “End” will appear on the electronic display. • You can open the door and take out the laundry. After taking out the laundry, leave the door open so that the inside of the machine can dry.
  • Page 25 6. PROGRAMME TABLE Programme Laundry type / Descriptions Very dirty, cotton and flax textiles. (****) COTTON *60 - 90 10,0 (Underwear, linen, tablecloth, towel (maximum 5,0 kg), bedclothes, etc.) Dirty cotton and flax textiles. (Underwear, ECO 40-60 *40 - 60 10,0 linen, tablecloth, towel (maximum 5,0 kg), bedclothes, etc.)
  • Page 26 NOTE: PROGRAMME DURATION MAY CHANGE ACCORDING TO THE AMOUNT OF LAUNDRY, TAP WATER, AMBIENT TEMPERATURE AND SELECTED ADDITIONAL FUNCTIONS. (*) Washing water temperature of the programme is the factory default. (**) If your machine has the rapid wash auxiliary function, you can enable the quick wash option on the display panel and load the machine with 2 kg or less laundry to wash it in 30 minutes.
  • Page 27 • The most efficient programmes in terms of energy consumption are generally those that perform at lower temperatures and longer duration. • Loading the household washing machine up to the capacity indicated by the manufacturer for the respective programmes will contribute to energy and water savings.
  • Page 28 6.1 Important Informations • Use detergents, softeners and other additives suitable for automatic washing machines only. Excessive foam has occurred and automatic foam absorption system has been activated due to too much detergent usage. • We recommend that periodic cleaning for washing machine every 2 months. For periodic cleaning please use Drum Clean programme.
  • Page 29 7. CLEANING AND 7.2 Water Inlet Filters Water inlet filters prevent dirt and foreign MAINTENANCE materials from entering your machine. We recommend that these filters are cleaned when your machine is unable to receive 7.1 Warning sufficient water, although your water supply is on and the tap is open.
  • Page 30 7.3 Pump Filter 6. Close the filter cover. WARNING: The water in the pump may be hot, wait until it has cooled down before carrying out any cleaning or maintenance. (*) Specifications may vary depending on the machine purchased. 7.4 Detergent Drawer The use of detergent may cause residual build up in the detergent drawer over time.
  • Page 31 8. Body / Drum 1. Body Use a mild, non-abrasive cleaning agent, or soap and water, to clean the external • casing. Wipe dry with a soft cloth. • Rinse with a brush and lots of water. 2. Drum • Collect the residues inside the detergent Do not leave metallic objects such as drawer slot so that they don’t fall inside...
  • Page 32 9. TROUBLESHOOTING Repair of your machine should be carried out by an authorised service company. If your machine requires repair or if you cannot solve an issue with the information provided below, then you should: • Unplug your machine from the mains power supply. •...
  • Page 33 FAULT POSSIBLE CAUSE TROUBLESHOOTING Increase the amount of detergent following the Hard water. manufacturer’s instructions. Unsatisfactory washing result. Your laundry is too tightly packed Check that your laundry is spread out. together in the drum. As soon as the machine is loaded The end of water drain hose is too low Check that the drain hose is at a suitable height.
  • Page 34 ..................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................
  • Page 35 ..................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................
  • Page 36 The minimum period which must supply the spare parts for the household washing machine is 10 years. 52475768...
