- Page 1 Form No. 3467-100 Rev A Flex-Force Power System ® 60V MAX Axial Blower Model No. 51900T—Serial No. 324000001 and Up *3467-100* Register at www.Toro.com. Original Instructions (EN)
- Page 2 You are responsible for operating the product properly and safely. Visit www.Toro.com for more information, including safety tips, training materials, accessory information, help finding a dealer, or to register your product.
- Page 3 Whenever you need service, genuine Toro parts, or additional information, contact an Authorized Service Dealer or Toro Customer Service and have the model and serial numbers of your product ready. Figure 1 identifies the location of the model and serial numbers on the product. Write the numbers in the space provided.
- Page 4 Safety-Alert Symbol The safety-alert symbol (Figure 2) shown in this manual and on the machine identifies important safety messages that you must follow to prevent accidents. g000502 Figure 2 Safety-alert symbol The safety-alert symbol appears above information that alerts you to unsafe actions or situations and is followed by the word DANGER, WARNING, or CAUTION.
- Page 5 Safety WARNING Read all safety warnings, instructions, illustrations and specifications provided with this machine. Failure to follow all instructions listed below may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference. The term “machine” in all the warnings refers to your mains-operated (corded) machine or battery-operated (cordless) machine.
- Page 6 When operating a machine outdoors, use an extension cord suitable for outdoor use. Use of a cord suitable for outdoor use reduces the risk of electric shock. If operating a machine in a damp location is unavoidable, use a residual current device (RCD) protected supply. Use of an RCD reduces the risk of electric shock.
- Page 7 IV. Machine use and care Do not force the machine. Use the correct machine for your application. The correct machine will do the job better and safer at the rate for which it was designed. Do not use the machine if the switch does not turn it on and off. Any machine that cannot be controlled with the switch is dangerous and must be repaired.
- Page 8 V. Battery tool use and care Recharge only with the charger specified by the manufacturer. A charger that is suitable for one type of battery pack may create a risk of fire when used with another battery pack. Use machines only with specifically designated battery packs. Use of any other battery packs may create a risk of injury and fire.
- Page 9 VII. Blower safety Do not use the machine in bad weather conditions, especially when there is a risk of lightning. This decreases the risk of being struck by lightning. Wear eye protection and ear protection. Adequate protective equipment will reduce the risk of personal injury. While operating the machine, always wear non-slip and protective footwear.
- Page 10 Safety and Instructional Decals Safety decals and instructions are easily visible to the operator and are located near any area of potential danger. Replace any decal that is damaged or missing. decal161-7057 161-7057 1. Do not dispose of improperly. decal161-7058 161-7058 1.
- Page 11 Setup Assembling the Blower Install the blower nozzle to the blower tube. g472735 Figure 3 Slide the blower tube onto the blower housing. You may need to press down on the tube latch for the blower tube to lock into place (Figure g472734 Figure 4...
- Page 12 Installing the Shoulder Harness Important: If you are using the string trimmer with a 6.0 Ah or greater battery pack installed, install the shoulder harness (Part No. 139-5334). Do not use the shoulder harness if you are powering the tool with the backpack and backpack tether;...
- Page 13 g484073 Figure 6 1. Harness adjuster 3. D-Ring 2. Harness clip 4. Shoulder harness Adjust the harness by slide the harness adjuster up to decrease the length of the harness, or down to increase the length of the harness. Know how to remove the shoulder harness in an emergency; refer to Removing the Shoulder Harness (page 18).
- Page 14 Product Overview g472736 Figure 7 1. Battery and battery cavity 5. Blower tube latch 2. Turbo boost button 6. Blower tube 3. Speed lock 7. Variable-speed trigger 4. Handle knob...
- Page 15 Store the tool, battery pack, and battery charger in an enclosed clean, dry area. Attachments/Accessories A selection of Toro approved attachments and accessories is available for use with the machine to enhance and expand its capabilities. Contact your Authorized Service Dealer or authorized Toro distributor or go to www.Toro.com for a list of all approved attachments and accessories.
- Page 16 Operation WARNING The blower can throw debris, possibly causing serious personal injury to you or bystanders. • Do not blow hard objects, such as nails or bolts. • Do not operate the blower near bystanders or pets. • Be careful of blowing direction (i.e., blow away from bystanders, windows, automobiles, etc.).
- Page 17 To start the blower, squeeze the variable-speed trigger (Figure Note: Engage the speed lock to keep the machine on without pressing the variable-speed trigger (Figure g472737 Figure 9 1. Speed lock 4. Battery latch 2. Turbo boost button 5. Blower venting areas 3.
- Page 18 Adjusting the Air Speed of the Blower To adjust the air speed as you blow, use the variable-speed trigger (Figure To maintain the current air speed, engage the speed lock (Figure To achieve maximum performance, depress the variable-speed trigger, then press the turbo boost button to turn boost on (Figure To turn boost off, press the turbo boost button again or completely release the variable speed trigger.
- Page 19 Shutting Off the Blower To shut off the blower, disengage the speed lock (if in use) and release the variable-speed trigger (Figure Important: After stopping the blower, do not leave the speed lock engaged with the battery pack in the blower. Whenever you are not using the blower or are transporting the blower to or from the work area, remove the battery pack.
- Page 20 Removing the Blower Tube Press down on the tab latch to separate the blower tube from the blower (Figure 11). g472738 Figure 11 1. Tube latch Removing the Battery from the Blower Press the battery latch to release the battery pack and slide the battery pack out of the blower (Figure 12).
- Page 21 Storage Important: Store the tool, battery pack, and charger only in temperatures that are within the appropriate range; refer to Specifications (page 15). Important: If you are storing the battery pack for the off-season, remove the battery pack from the tool and charge the battery pack until 1 or 2 LED indicators turn green on the battery.
- Page 22 Problem Possible Cause Corrective Action The tool does not start. 1. The battery is not fully 1. Remove and then installed in the tool. replace the battery into the tool, making sure that it is fully installed and latched. 2. The battery pack is not 2.
- Page 23 Notes:...
