Summary of Contents for FOXFURY SIDESLIDE C-CLAMP
- Page 1 SIDESLIDE C-CLAMP C-CLAMP 940K-010FI | C-CLAMP MINI 940K- 010FI-M PRODUCT MANUAL...
-
Page 2: Table Of Contents
TABLE OF CONTENTS INTRODUCTION Reference Guide Physical Characteristics & Warnings BATTERY Battery Installation and Replacement Battery Life OPERATION Operational Modes INSTALLATION Inserting and Removing the SideSlide from the Holder Installation of SideSlide Adaptor WARRANTY 9–10 CONTACT FOXFURY... -
Page 3: Reference Guide
STRIKE BEZEL ANTI-ROLL HEAD RUBBER SLEEVE LOCKING GROOVE HANDLE TAILCAP TAILCAP LANYARD HOLE POWER/MODE SWITCH HOLDER C-CLAMP ADAPTOR RELEASE LEVER MOUNT FRONT RELEASE LEVER THUMBSCREW OR SETSCREW* (2) *Newer model SideSlide C-Clamp and C-Clamp Mini comes with Setscrews instead of Thumbscrews. -
Page 4: Physical Characteristics & Warnings
PHYSICAL CHARACTERISTICS Please read below before using your SideSlide as it relays beneficial operating and safety information. SIDESLIDE FLASHLIGHT (940– 010FI) Length: 5.5 in (140 mm) DIMENSIONS Head: 1.3 in (33 mm) x 1.3 in (33 mm) Handle Diameter: 1.1 in (28 mm) WEIGHT 5.2 oz (148 g) (without battery) -
Page 5: Battery
Test the light’s performance and function by activating the Power/Mode Switch (located at the end of the Tailcap). LITHIUM BATTERY WARNING FoxFury recommends the use of TacSwan or other high quality protected button top 18650 batteries and the use of Panasonic, Sanyo, Energizer or other high quality CR123 batteries. -
Page 6: Battery Life
BATTERY LIFE SIDESLIDE (940K-010FI) MODE BATTERY LIFE* LUMENS HIGH POWER 2.2 hours LOW POWER 5.3 hours FLASHING 3 hours *Battery life is measured with two (2) 1400 mAh CR123 batteries. It may vary according to mode selected, battery quality and prevailing ambient conditions SIDESLIDE MINI (940K-013) MODE BATTERY LIFE**... -
Page 7: Inserting And Removing The Sideslide From The Holder
INSERTING AND REMOVING THE SIDESLIDE FROM THE HOLDER TO INSERT THE FLASHLIGHT INTO THE HOLDER: Insert the flashlight by pushing it, Tail Cap first, into the beveled opening on the front of the Holder. Once locked, the Release Lever falls into a groove on the handle, securing the flashlight in place. -
Page 8: Installation Of Sideslide Adaptor
The C-Clamp can be mounted on the right or left side of the helmet, above or below the brim (based on user preference). MOUNTING ABOVE THE BRIM (RECOMMENDED BY FOXFURY): TO MOUNT ON THE LEFT SIDE OF A HELMET: Place C-Clamp Adaptor on helmet at desired location and tighten Thumbscrews or Setscrews with provided 3 mm Hex Key . -
Page 9: Warranty And Other Information
18650 Rechargeable Battery , P/N 70-18650T Battery Charger - AA, 18650, P/N 600-155 IPX7 WARNINGS FoxFury , LLC is not responsible for the incorrect use of any FoxFury Meets NFPA Fire Resistant Lighting product. Requirements. Lights are strong enough to... -
Page 10: Contact Foxfury
Email: service@FoxFury .com given only to the original end user of Web: FoxFury .com the accompanying product. If you All FoxFury products are designed in purchased a product from someone Oceanside, CA. All FoxFury products other than an authorized FoxFury... - Page 11 FOXFURY .COM 07/2024...
