EBU00066

Speed limiter

The speed limiter keeps the throttle from
fully opening, even when the throttle lever
is pushed to the maximum. Screwing in
the adjuster limits the maximum engine
power available and decreases the maxi-
mum speed of the ATV.
1. Locknut
1
2
2. Adjusting bolt
POTENTIAL HAZARD
Improper adjustment of the speed limit-
er and throttle.
WHAT CAN HAPPEN
The throttle cable could be damaged.
Improper throttle operation could re-
sult. You could lose control, have an ac-
cident or be injured.
HOW TO AVOID THE HAZARD
Do not turn the speed adjuster out more
than 12 mm (0.47 in). Always make sure
the throttle lever free play is adjusted to
3 ~ 5 mm (0.11 ~ 0.20 in). See page 8-34.
4-10
WARNING
