READ THIS MANUAL CAREFULLY!
It contains important safety information.
LIRE ATTENTIVEMENT CE MANUEL!
Il comprend d'importantes informations de sécurité.
¡LEA ESTE MANUAL ATENTAMENTE!
Contiene indicaciones importantes acerca de la seguridad.
MANUEL DU PROPRIÉTAIRE
MANUAL DEL PROPIETARIO
YFM700FWBD/YFM700FWB
OWNER'S MANUAL
YFM70KPAL
B5K-F8199-62

Advertisement

Table of Contents
loading

Related Manuals for Yamaha KODIAK 2019

Summary of Contents for Yamaha KODIAK 2019

  • Page 1 READ THIS MANUAL CAREFULLY! It contains important safety information. LIRE ATTENTIVEMENT CE MANUEL! Il comprend d’importantes informations de sécurité. ¡LEA ESTE MANUAL ATENTAMENTE! Contiene indicaciones importantes acerca de la seguridad. OWNER’S MANUAL MANUEL DU PROPRIÉTAIRE MANUAL DEL PROPIETARIO YFM700FWBD/YFM700FWB YFM70KPAL B5K-F8199-62...
  • Page 2 Original instructions Notice originale Manual original PRINTED IN USA 2019.05-0.6×1 CR (E,F,S)
  • Page 3 READ THIS MANUAL CAREFULLY! It contains important safety information. OWNER’S MANUAL YFM700FWBD/YFM700FWB YFM70KPAL WARNING This ATV should not be ridden by anyone under 16 years of age. B5K-F8199-62-E0...
  • Page 4 Read this manual carefully before operating this vehicle. This manual should stay with this ve- hicle if it is sold. EC Declaration of Conformity conforming to Directive 2006/42/EC We, YAMAHA MOTOR CO., LTD. 2500 Shingai, Iwata, Japan, declare in sole responsibility, that the product YFM700FWBD :B5KJ (JY4AMK9W0K0500211–)
  • Page 5 Congratulations on your purchase of the Yamaha YFM700FWBD / YFM700FWB / YFM70KPAL. This ATV represents the result of many years of Yamaha experience in the production of fine sporting, touring, and pacesetting racing machines. With the purchase of this Yamaha, you can now appreciate the high degree of craftsmanship and reliability that have made Yamaha a leader in these fields.
  • Page 6 EBU17331 IMPORTANT MANUAL INFORMATION EBU17344 FAILURE TO FOLLOW THE WARNINGS CONTAINED IN THIS MANUAL CAN RESULT IN SERIOUS IN- JURY OR DEATH. Particularly important information is distinguished in this manual by the following notations: This is the safety alert symbol. It is used to alert you to potential per- sonal injury hazards.
  • Page 7 Please check your local riding laws and regulations before operating this ATV. EBU17411 YFM700FWBD / YFM700FWB / YFM70KPAL OWNER’S MANUAL ©2020 by Yamaha Motor Co., Ltd. 1st edition, April 2019 All rights reserved. Any reprinting or unauthorized use without the written permission of Yamaha Motor Co., Ltd.

  • Page 8: Table Of Contents

    EBU17421 TABLE OF CONTENTS VEHICLE IDENTIFICATION ......1-1 Brake pedal and rear brake lever ..... 5-19 Identification numbers ........1-1 Drive select lever ........5-20 Fuel tank cap ..........5-21 LOCATION OF THE WARNING AND Fuel ............5-22 SPECIFICATION LABELS ......2-1 Seat ............5-23 Storage compartment.......
  • Page 9 OPERATION ........... 7-1 Periodic maintenance chart: Emission Starting the engine........7-1 control system .......... 9-3 Operating the drive select lever and Periodic maintenance chart: General driving in reverse........7-2 maintenance and lubrication ....9-5 Engine break-in ........... 7-4 Removing and installing panels....9-9 Parking ............
  • Page 10 Checking and lubricating the front and INDEX ............13-1 rear brake levers ........9-49 Checking and lubricating the brake pedal ............9-50 Checking the wheel hub bearings.....9-50 Checking the stabilizer bushes ....9-51 Lubricating the rear knuckle pivots...9-51 Lubricating the steering shaft ....9-52 Battery............9-53 Replacing a fuse ........9-56 Replacing a headlight bulb .......9-59...

  • Page 11: Vehicle Identification

    EBU38860 VEHICLE IDENTIFICATION EBU28205 Identification numbers Record the vehicle identification number and model label information in the spaces provided below. VEHICLE IDENTIFICATION NUMBER: MODEL LABEL INFORMATION: 1. Vehicle identification number (front left side) EBU26053 Model label The model label is affixed at the location shown. EBU26032 Vehicle identification number The vehicle identification number is stamped into...
  • Page 12 1. Model label Your specific model can be identified by checking the model type code found on the model label. * * * * - * * * 1. Model type code 2. Production code 3. Color code...

  • Page 13: Location Of The Warning And Specification Labels

    Read and understand all of the labels on your ATV. These labels contain important information for safe and proper operation. Never remove any labels from your ATV. If a label becomes difficult to read or comes off, request a re- placement label from your Yamaha dealer.
  • Page 14 For Europe...
  • Page 15 < 50 kg ( 110 lbs) B16-F817R-00 < 90 kg YAMAHA 1P0-F816P-20 ( 198 lbs) B16-F817R-10 < 5880 N < 600 kgf < 1322 lbf < 147 N < 15 kgf < 33 lbf 37S-F817S-00 35.0 kPa 30.0 kPa 50.0 kPa 50.0 kPa...
  • Page 16 6 B6KA YFM700FWB 2019 36.0 kW YAMAHA MOTOR CO., LTD. 313 kg 2500 SHINGAI, IWATA, JAPAN B6K-F155A-30 B4F-F817K-00 6 B5KJ YFM700FWBD 2019 36.0 kW YAMAHA MOTOR CO., LTD. 318 kg 2500 SHINGAI, IWATA, JAPAN B5K-F155A-60 6 B5KN / B5KS / B5KV...
  • Page 17 < 4 kg ( 9 lbs) B4F-F817R-10 YAMAHA 1P0-F816R-00...
  • Page 18 Familiarize yourself with the following pictograms and read the explanatory text, then make sure to check the pictograms that apply to your model. Read the Owner’s manual. NEVER use on paved roads. ALWAYS use an approved helmet and NEVER carry passengers. protective gear.
  • Page 19 (Weight on the trailer tongue.) Model Name **** ****** Overloading can cause loss of control. *** kW YAMAHA MOTOR CO., LTD. Loss of control can result in severe injury or Max. Power *** kg 2500 SHINGAI, IWATA, JAPAN death.
  • Page 20 For Oceania...
  • Page 21 WARNING LOAD LIMIT NEVER ride as a passenger. 50 kg (110 lbs) Passengers can cause YAMAHA B16-F4877-A0 a loss of control, resulting in SEVERE INJURY or DEATH. YAMAHA MAXIMUM LOADING LIMIT LOAD LIMIT PULLING LOAD: 5880 N (600 kgf) 1322 lbf...
  • Page 22 Maximum Vehicle Load : 240 kg, (530 lbs) Includes weight of operator, cargo and accessories UNDER (and if applicable, trailer tongue weight). YAMAHA B16-F816M-00 Operating this ATV if you are under the age of 16 increases your chance of severe injury or death.
  • Page 23 WARNING LOAD LIMIT Improper ATV use can result in SEVERE INJURY or DEATH. 4 kg (9 lbs) YAMAHA B4F-F4877-A0 ALWAYS USE NEVER USE NEVER CARRY NEVER USE AN APPROVED ON PUBLIC PASSENGERS WITH DRUGS HELMET AND ROADS OR ALCOHOL PROTECTIVE...

  • Page 24: Safety Information

    EBU17432 SAFETY INFORMATION SAFETY INFORMATION  Never allow a child under age 16 to operate an EBU27255 ATV without adult supervision, and never allow AN ATV IS NOT A TOY AND CAN BE HAZARD- continued use of an ATV by a child if he or she OUS TO OPERATE.
  • Page 25  Never operate at speeds too fast for your skills  Never operate the ATV on hills too steep for the or the riding conditions. Always go at a speed ATV or for your abilities. Practice on smaller hills that is proper for the terrain, visibility, operating before attempting larger hills.
  • Page 26  Never operate an ATV in fast flowing water or in technique described in this manual on level ground. Avoid crossing the side of a steep hill if water deeper than that recommended in this possible. manual. Remember that wet brakes may have ...
  • Page 27  Never maintain an ATV without proper knowl- vehicle. If the vehicle is in safe operating con- edge. Contact an authorized ATV dealer to in- dition and you can safely operate it, restart it form you on basic ATV maintenance. Certain and ride gently back to camp or other known maintenance can only be carried out by certified location where you can receive medical at-...
  • Page 28 While you may find aftermarket products similar in of the operator and may limit control ability, design and quality to genuine Yamaha accesso- therefore, such accessories are not recom- ries, recognize that some aftermarket accessories mended.
  • Page 29  Do not run engine in poorly ventilated or par- gerous loss of lights or engine power. Also, the battery tends to discharge more quickly if elec- tially enclosed areas such as barns, garages, trical accessories are added. or carports. ...

  • Page 30: Description

    EBU17681 DESCRIPTION EBU17691 EBU17701 Left view Right view 1. Radiator cap 1. Rear shock absorber 2. Battery 2. Fuel tank cap 3. Fuses 3. Tool kit 4. Air filter 4. Storage compartment 5. Spark arrester 5. Spark plug 6. Rear brake light switch 6.

  • Page 31: Controls And Instruments

    YFM700FWBD / YFM70KPAL EBU17715 Controls and instruments 6 7 8 9 10 11 YFM700FWB 2 3 4 5 8 9 10 11 1. Drive select lever 2. Rear brake lever 3. Handlebar switches 1. Drive select lever 4. Horn switch 2.

  • Page 32: Instrument And Control Functions

    EBU17739 INSTRUMENT AND CONTROL FUNCTIONS EBU29913 EBU26699 Main switch Indicator lights and warning lights YFM700FWB 1 2 3 4 5 6 1. Main switch 1. Fuel level warning light “ ” “ ” (on) 2. Engine trouble warning light “ ”...
  • Page 33 YFM700FWBD / YFM70KPAL EBU17992 Low-range indicator light “ ” (YFM700FWBD / YFM70KPAL) This indicator light comes on when the transmis- sion is in the low-range position. EBU17982 High-range indicator light “ ” (YFM700FWBD / YFM70KPAL) This indicator light comes on when the transmis- sion is in the high-range position.
  • Page 34 “ ” (on), or the engine to idle for about 10 minutes. If the if the warning light remains on, have a Yamaha warning light does not go off, stop the engine and dealer check the vehicle.
  • Page 35 “ ” (on), or if the warning When the key is turned to “ ” (on), the warning light remains on, have a Yamaha dealer check the light will come on in purple. vehicle. EBU29933 YFM700FWB Fuel level warning light “...
  • Page 36 The electrical circuit of the warning light can be the ATV starts moving. checked by turning the key to “ ” (on). If the warning light does not come on, have a Yamaha Four-wheel drive icon “ ” (YFM700FWBD / dealer check the electrical circuit. YFM70KPAL) This icon comes on when the drivetrain is set to ...

  • Page 37: Multi-Function Display (Yfm700Fwbd / Yfm70Kpal)

    ferential gear is completely locked or unlocked. The multi-function display is equipped with the Turn the handlebar or start moving to help the dif- following:  speedometer ferential lock to engage or disengage.  odometer  tripmeters EBU38113  clock Multi-function display (YFM700FWBD / ...
  • Page 38 Odometer and tripmeters Push the “SELECT” button to switch between the odometer “ODO”, the tripmeters “TRIP A” and “TRIP B”, and the service tripmeter “ ” in the following order: ODO → TRIP A → TRIP B → → ODO To reset a tripmeter, set the display to the tripme- ter you want to reset, then push the “RESET”...
  • Page 39 Clock, hour meter, voltage display and coolant CLOCK → HOUR → VOLT → → CLOCK temperature display To set the clock 1. Set the display to the clock. 2. Push both the “SELECT” button and “RE- SET” button for 2 seconds. The hour digits will start flashing.
  • Page 40  The coolant temperature display can be set to circuit or the battery may be faulty. If this oc- “°C” or “°F”. To switch the temperature units, curs, have a Yamaha dealer check or repair the turn the key to “ ” (off), then while holding the vehicle.
  • Page 41 If the electrical circuit for the fuel gauge is not working correctly, all display segments will flash Fuel gauge repeatedly. Have a Yamaha dealer check the vehi- cle. Brightness control mode 1. Fuel gauge The fuel gauge indicates the amount of fuel in the fuel tank.
  • Page 42 2. Push the “RESET” button to set the bright- If the display indicates an error code, note the ness level. code number and have a Yamaha dealer check 3. Push the “SELECT” button to confirm the se- the vehicle. lected brightness level and exit the brightness...

  • Page 43: Handlebar Switches

    YFM700FWBD / YFM70KPAL EBU18068 Handlebar switches YFM700FWB 1. Light switch “ /OFF” 2. Start switch “ ” 3. Engine stop switch “ ” 1. Light switch “ /OFF” 4. Override switch “OVERRIDE” 2. Engine stop switch “ ” 5. Horn switch “ ”...
  • Page 44 YFM700FWBD / YFM70KPAL EBU18102 Start switch “ ” Push this switch to crank the engine with the start- er. See the starting instructions on page 7-1 prior to starting the engine. EBU34123 LOCK Light switch “ /OFF” Set this switch to “ ”...
  • Page 45 Top speed is normally limited when operating in indicate a malfunction in the electrical system. In differential gear lock. If conditions require more this case, take the ATV to a Yamaha dealer at the engine power when riding forward, push and hold first opportunity.
  • Page 46 EBU2660A EBU30467 On-Command drive switch “2WD/4WD” On-Command drive switch “4WD/LOCK” (YFM700FWBD / YFM70KPAL) (YFM700FWBD / YFM70KPAL) Stop the ATV and push this switch to change from Stop the ATV and push this switch to change from two-wheel drive to four-wheel drive or vice versa. standard four-wheel drive to four-wheel drive with Select the appropriate drive according to the ter- the differential locked.
  • Page 47  When the icon and indicator light are flashing, expectedly. This could distract the operator and increase the risk of losing control and turning the handlebar back and forth will help causing an accident. the differential gear lock to engage or disen- gage.

  • Page 48: Drive Lever "2Wd/4Wd" (Yfm700Fwb)

     “2WD” (two-wheel drive): Power is supplied to control and have an accident if you cannot make a sharp enough turn for the speed you the rear wheels only, giving a smooth ride and are traveling. fuel economy.  “4WD” (four-wheel drive): Power is supplied to the front and rear wheels, giving increased trac- EBU37201 Drive lever “2WD/4WD”...

  • Page 49: Throttle Lever

    EBU18286 EBU18325 Throttle lever Speed limiter 1. Locknut 1. Throttle lever 2. Adjusting screw 3. No more than 12 mm (0.47 in) Push the throttle lever to increase engine speed. Spring tension returns the lever to the rest position The speed limiter keeps the throttle from fully when released.

  • Page 50: Front Brake Lever

    the adjusting screw in direction (b). Do not The front brake lever is located on the right han- turn the adjusting screw out more than 12 dlebar. To apply the front brake, pull the brake le- mm (0.47 in) or the throttle cable could be ver toward the handlebar grip.

  • Page 51: Drive Select Lever

    EBU18614 Drive select lever 1. Rear brake lever The brake pedal is located on the right side of the 1. Drive select lever ATV and the rear brake lever is located on the left The drive select lever is used to shift the transmis- handlebar.

  • Page 52: Fuel Tank Cap

    of sparks, open flames, or other sources of EBU37980 Fuel tank cap ignition such as the pilot lights of water heat- ers and clothes dryers. 2. Do not overfill the fuel tank. When refueling, be sure to insert the pump nozzle into the fuel tank filler hole.

  • Page 53: Fuel

    3. Wipe up any spilled fuel immediately. Recommended fuel: NOTICE: Immediately wipe off spilled fuel Regular unleaded gasoline only with a clean, dry, soft cloth, since fuel may Fuel tank capacity: deteriorate painted surfaces or plastic 18 L (4.8 US gal, 4.0 Imp.gal) parts.

  • Page 54: Seat

    About the recommended fuel EBU34141 Seat If knocking or pinging occurs, try a different brand or higher octane gasoline. To remove the seat For Europe, use RON 95 octane or higher. For Oceania, use RON 91 octane or higher. Gasoline containing ethanol can be used if the ethanol content does not exceed 10% (E10).

  • Page 55: Storage Compartment

    To install the seat EBU34152 Storage compartment ECB02320 NOTICE Do not store metal or sharply edged objects, like tools, in the storage compartment. If they must be stored, wrap them in appropriate cushion material to prevent damaging the stor- age compartment. The storage compartment is located in front of the seat.

  • Page 56: Front Carrier

    A drain plug is fitted at the bottom of the storage compartment. If any water collects in the storage compartment, remove the drain plug, drain the water, and then install the drain plug. 1. Storage compartment When storing any documents in the storage com- partment, be sure to wrap them in a plastic bag so that they will not get wet.

  • Page 57: Rear Carrier

    Uneven adjustment can cause poor handling and loss of stability, which could lead to an ac- A special wrench can be obtained at a Yamaha cident. dealer to make this adjustment.

  • Page 58: Trailer Hitch

    2 (YFM700FWBD, YFM70KPAL) Maximum (hard): 5 (YFM700FWBD, YFM70KPAL) EBU28972 Trailer hitch This ATV is equipped with a 5 cm (2 in) trailer hitch receiver. Trailer towing equipment can be obtained at a Yamaha dealer. (See page 7-6 for precaution in- formation.) 5-27...

  • Page 59: Auxiliary Dc Jack

    EBU19186 Auxiliary DC jack 1. Trailer hitch receiver 1. Auxiliary DC jack cap 2. Auxiliary DC jack Auxiliary DC jack system capacity: 10.0 A (120 W) ECB03760 NOTICE Do not use any single electrical accessory or combination of accessories that require more than the stated capacity at any one time.
  • Page 60 ECB00122 NOTICE When using a winch or other electrical accesso-  If accessories are used with the engine off or ries, the power taken from the DC jack must be re- with the headlights on, the battery may dis- duced accordingly. charge to the point that the engine will not start.

  • Page 61: Pre-Operation Checks

    Do not operate the vehicle if you find any problem. If a problem cannot be corrected by the procedures provided in this manual, have the vehicle inspected by a Yamaha dealer. Before using this vehicle, check the following points:...
  • Page 62 ITEM ROUTINE PAGE • Check operation. If soft or spongy, have Yamaha dealer bleed hy- draulic system. • Check brake pads for wear, and replace if necessary. Front brake 6-3, 9-42, 9-43, 9-44 • Check brake fluid level in reservoir, and add specified brake fluid to specified level if necessary.

  • Page 63: Fuel

    Add oil as necessary. (See page 9-19.)  Check that there is no free play in the front EBU19591 brake lever. If there is free play, have a Yamaha Final gear oil dealer check the brake system. Make sure that the final gear oil is at the specified ...

  • Page 64: Throttle Lever

    If there is any leakage, the brake system should be checked by a Yamaha dealer. Brake operation Test the brakes at slow speed after starting out to make sure they are working properly.
  • Page 65 control or rollover. Tire pressure below the mi- nimum specified could also cause the tire to With cargo or trailer: dislodge from the rim under severe driving Front: (Recommended) conditions. [EWB04120] 50.0 kPa (0.500 kgf/cm², 7.3 psi) Rear: (Recommended) OPERATING TIRE PRESSURE (cold): 50.0 kPa (0.500 kgf/cm², 7.3 psi) For Oceania Front: (Minimum)
  • Page 66 250 kPa (2.5 kgf/cm², 36 psi) This ATV is equipped with tubeless tires and tire Rear air valves. After extensive tests, only the tires list- 250 kPa (2.5 kgf/cm², 36 psi) ed below are approved for this model by Yamaha.

  • Page 67: Chassis Fasteners

    Aftermarket tires and rims The tires and rims that came with your ATV were designed to match the performance capabilities and to provide the best combination of handling, braking, and comfort. Other tires, rims, sizes, and combinations may not be appropriate. EBU19841 Chassis fasteners Make sure that all nuts, bolts and screws are...

  • Page 68: Operation

    See the “Engine break-in” section on page 7-4 the ATV. If there is a control or function you do not prior to operating the engine for the first time. understand, ask your Yamaha dealer. EWB00632 To start the engine WARNING 1.

  • Page 69: Operating The Drive Select Lever And Driving In Reverse

    ECB03330 on. If the indicator light does not come on, NOTICE have a Yamaha dealer check the electrical Do not shift without coming to a complete stop circuit. and waiting for the engine to return to normal 3.
  • Page 70 reverse, make sure there are no people or ob- stacles behind you. When it is safe to proceed, go slowly. 1. Bring the ATV to a complete stop. 2. Apply the brake pedal. 3. Shift from neutral to reverse or from reverse to park and vice versa by moving the drive se- lect lever along the shift guide.

  • Page 71: Engine Break-In

    Vary the speed of the ATV regularly. Do not oper- should come on. If the indicator light does not ate it at one set throttle position. come on, have a Yamaha dealer check the elec- trical circuit. 120–240 km (75–150 mi) or 10–20 hours ...

  • Page 72: Parking On A Slope

    Yamaha for use on your ATV. Many companies with no connection to Yamaha manufacture parts and accessories or offer other modifications for Yamaha vehicles. Yamaha is not in a position to test the products that these aftermarket compa- nies produce. Therefore, Yamaha can neither en-...
  • Page 73 Yamaha or modifications not specifically bulky object attached to the handlebars which recommended by Yamaha, even if sold and in- could make steering difficult, an accessory that stalled by a Yamaha dealer. limits your ability to move around on the seat, or one that limits your view.
  • Page 74  Never exceed the weight limits shown. An over- the weight on the hitch. If you are carrying cargo loaded ATV can be unstable. and towing a trailer, include the tongue weight in the maximum ATV load limit.  Load cargo on the carriers as close to the center MAXIMUM LOADING LIMIT ATV loading limit (total weight of rider, car- of the ATV as possible.

  • Page 75: Riding Your Atv

    EBU21142 RIDING YOUR ATV...

  • Page 76: Getting To Know Your Atv

    RIDE WITH CARE AND GOOD JUDGMENT EBU34291 Get training if you are inexperienced. GETTING TO KNOW YOUR ATV EWB01382 This ATV is mainly for utility use, but may also be WARNING used for recreation. This section, Riding your ATV,  Do not operate this ATV or allow anyone else provides general ATV riding instructions for recre- to operate it without proper instruction.
  • Page 77 the time to learn the basic techniques well before This ATV is designed to carry the operator and attempting more difficult maneuvers. Become fa- cargo only – passengers prohibited. miliar with this ATV at slow speeds first, even if you The long seat is to allow the operator to shift posi- are an experienced operator.
  • Page 78 Apparel Always wear the following to reduce risk of injury in an accident:  Approved motorcycle helmet that fits properly  Eye protection (goggles, helmet face shield, or protective eyewear)  Over-the-ankle boots, gloves, long-sleeved shirt or jacket, and long pants An approved helmet and other personal protective equipment can reduce the severity of injuries in an accident.
  • Page 79 1. Protective clothing Pre-operation checks 2. Goggles Always inspect your ATV each time you use it to 3. Gloves make sure the ATV is in safe operating condition. 4. Boots 5. Helmet Perform the pre-operation checks listed on page 6-1. Always follow the inspection and mainte- Do not operate after or while consuming alco- nance procedures and schedules described in the hol or drugs.
  • Page 80  Do not exceed the maximum loading limits fully opening, even when the throttle lever is pushed to the maximum. Turning in the adjusting for the vehicle (see “MAXIMUM LOADING screw limits the maximum engine power available LIMIT” in this section or vehicle labeling). ...
  • Page 81 During operation MAXIMUM LOADING LIMIT Always keep your feet on the footboards during ATV loading limit (total weight of cargo, rid- operation; otherwise, they may contact the rear er, accessories, and tongue): wheels. WARNING! Removing even one hand or 240.0 kg (530 lb) foot can reduce your ability to control the ATV Front carrier: or could cause you to lose your balance and...
  • Page 82 ATV should during operation or after leaving the ATV, do not be genuine Yamaha or equivalent components let brush, grass and other materials collect under designed for use on this ATV and should be in- the vehicle, near the muffler or exhaust pipe, or stalled and used according to instructions.

  • Page 83: Be Careful Where You Ride

    To prevent burns, avoid touching the exhaust sys- BE CAREFUL WHERE YOU RIDE tem. Park the ATV in a place where pedestrians or This ATV is designed for use on unpaved surfaces children are not likely to touch it. only. WARNING! Paved surfaces may seriously affect handling and control of the ATV, and may cause the ATV to go out of control.
  • Page 84 know your country’s laws and regulations before ful when operating on unfamiliar terrain. Al- you ride on unpaved public streets or roads. Do ways be alert to changing terrain conditions not ride on any paved public street, road or motor- when operating the ATV.
  • Page 85 terrain could cause loss of traction or ATV con- trol, which could result in an accident, includ- ing an overturn. [EWB01542] Do not ride in areas posted “no trespassing”. Do not ride on private property without getting permission. When riding in an area where you might not easily be seen, such as desert terrain, mount a caution flag on the ATV.

  • Page 86: Turning Your Atv

    Select a large, flat, unpaved area to become famil- ECB00252 NOTICE iar with your ATV. Make sure that this area is free of obstacles and other riders. You should practice Do not shift from low-range to high-range or control of the throttle, brakes, shifting procedures, vice versa without coming to a complete stop.

  • Page 87: Climbing Uphill

    As you approach a curve, slow down and begin to may continue to go straight. If the ATV doesn’t turn the handlebars in the desired direction. As turn, come to a stop and then practice the proce- you do so, put your weight on the footboard to the dure again.
  • Page 88  Never operate the ATV on hills too steep for the ATV or for your abilities. The ATV can overturn more easily on extremely steep hills than on level surfaces or small hills.  Always check the terrain carefully before you start up any hill.
  • Page 89 Do not attempt to climb hills until you have mas- If you are climbing a hill and you find that you have tered basic maneuvers on flat ground. Always not properly judged your ability to make it to the check the terrain carefully before attempting any top, you should turn the ATV around while you still hill.

  • Page 90: Riding Downhill

     Always check the terrain carefully before you straight uphill. Turn the ATV around and remount, following the procedure described in the Owner’s start down any hill.  Never operate the ATV on hills too steep for Manual. WARNING! Stalling, rolling backwards or improperly dismounting while climbing a hill the ATV or for your abilities.

  • Page 91: Crossing A Slope

    Use caution while descending a hill with loose or slippery surfaces. Braking ability and traction may be adversely affected by these surfaces. Improper braking may also cause a loss of traction. When this ATV is in “4WD”, all wheels (front and rear) are interconnected by the drive train.

  • Page 92: Crossing Through Shallow Water

     Shift your weight to the uphill side of the ATV.  Never attempt to turn the ATV around on any hill until you have mastered the turning tech- nique as described in the Owner’s Manual on level ground. Be very careful when turning on any hill.
  • Page 93 The ATV can be used to cross slow moving, shal- braking ability. WARNING! Wet brakes may have low water of up to a maximum of 35 cm (14 in) in reduced stopping ability, which could cause depth. Before entering the water, choose your loss of control.

  • Page 94: Riding Over Rough Terrain

    1. Air filter case check hose 1. V-belt case drain plug RIDING OVER ROUGH TERRAIN EWB01652 WARNING Riding improperly over obstacles could cause loss of control or a collision. Before operating in a new area, check for obstacles. Never at- tempt to ride over large obstacles, such as lar- ge rocks or fallen trees.

  • Page 95: Sliding And Skidding

    accident. Be sure to keep your feet firmly mounted To reduce the tendency for the front wheels to on the footboards at all times. Avoid jumping the slide in loose or slippery conditions, positioning ATV as loss of control and damage to the ATV may your weight over the front wheels will sometimes result.

  • Page 96: What To Do If

    WHAT TO DO...  If your ATV doesn’t turn when you want it to: Bring the ATV to a stop and practice the turning maneuvers again. Be sure you are putting your weight on the footboard to the outside of the turn.
  • Page 97  If your ATV is traversing a sloping surface: Be sure to ride with your weight positioned to- wards the uphill side of the ATV to maintain proper balance. If the ATV starts to tip, steer down the hill (if there are no obstacles in your way) to regain balance.

  • Page 98: Periodic Maintenance And Adjustment

    The intervals given in the periodic maintenance vice or while using the vehicle. If you are not fa- charts should be considered as a general guide miliar with vehicle service, have a Yamaha under normal riding conditions. However, DE- dealer perform the service.

  • Page 99: Owner's Manual And Tool Kit

    Make sure to protect the Owner’s Manual If you do not have the tools or experience required by putting it in the plastic bag, then by placing the for a particular job, have a Yamaha dealer perform bag in the document pouch. it for you.

  • Page 100: Periodic Maintenance Chart: Emission Control System

     For odometer or hour meter-equipped vehicles, follow the month maintenance interval if the ATV isn’t ridden for the stated distance or engine operating hours.  Items marked with an asterisk should be performed by a Yamaha dealer as they require special tools, data and technical skills.
  • Page 101 INITIAL EVERY month Whichev- CHECK OR MAINTENANCE ITEM er comes 1300 2500 2500 5000 km (mi) first (150) (800) (1600) (1600) (3200) hours √ √ √ Spark arrester • Clean. • Check the air cut-off valve, reed valve, and hose Air induction sys- √...

  • Page 102: Periodic Maintenance Chart: General Maintenance And Lubrication

     For odometer or hour meter-equipped vehicles, follow the month maintenance interval if the ATV isn’t ridden for the stated distance or engine operating hours.  Items marked with an asterisk should be performed by a Yamaha dealer as they require special tools, data and technical skills.
  • Page 103 INITIAL EVERY month Whichev- CHECK OR MAINTENANCE ITEM er comes 1300 2500 2500 5000 km (mi) first (150) (800) (1600) (1600) (3200) hours • Check for cracks or other damage, and replace if √ √ √ √ necessary. Brake hoses •...
  • Page 104 INITIAL EVERY month Whichev- CHECK OR MAINTENANCE ITEM er comes 1300 2500 2500 5000 km (mi) first (150) (800) (1600) (1600) (3200) hours √ √ √ Steering shaft • Lubricate with lithium-soap-based grease. • Check operation and repair or replace if dam- √...
  • Page 105 INITIAL EVERY month Whichev- CHECK OR MAINTENANCE ITEM er comes 1300 2500 2500 5000 km (mi) first (150) (800) (1600) (1600) (3200) hours Moving parts and √ √ √ √ • Lubricate. cables • Check operation. • Check throttle lever free play, and adjust if neces- √...

  • Page 106: Removing And Installing Panels

    EBU23091 Removing and installing panels The panels shown need to be removed to perform some of the maintenance jobs described in this chapter. Refer to this section each time a panel needs to be removed and installed. 1. Panel E 2.
  • Page 107 Panel B To remove the panel 1. Remove panel A. 2. Remove the front carrier by removing the bolts. 1. Panel A To install the panel Place the panel in the original position. 1. Front carrier 2. Carrier bolt (upper) 9-10...
  • Page 108 1. Carrier bolt (under the fenders) 1. Panel B 2. Carrier bolt (lower) 2. Quick fastener 3. Remove the quick fasteners, and then pull the To install the panel panel upward to remove it. 1. Place the panel in the original position, and then install the quick fasteners.
  • Page 109 Panel C To remove the panel 1. Remove the seat. (See page 5-23.) 2. Remove panel A. 3. Remove the hoses from panel C. 2. Install the front carrier by installing the bolts and tightening them to the specified torques. Tightening torques: Carrier bolt (upper): 34 N·m (3.4 kgf·m, 25 lb·ft)
  • Page 110 1. Bolt 1. Screw 2. Quick fastener To install the panel 5. Remove the screws under the storage com- 1. Place the panel in the original position. partment lid, and then pull the panel upward to remove it. To ease removal of panel C, shift the drive select lever into the reverse position.
  • Page 111 2. Install the screws, quick fasteners, bolts, and hoses. Make sure that the hoses are properly connected and routed, and are not pinched. 3. Install panel A. 4. Install the seat. Panels D and E To remove a panel 1. Panel D 1.
  • Page 112 To install a panel Panels F and G 1. Place the panel in the original position, and To remove a panel then install the bolt. 1. Remove the panel bolts, footboard bolt, and footboard nut. 1. Panel F 2. Footboard nut 3.
  • Page 113 1. Panel G 2. Footboard nut 3. Footboard bolt 4. Panel bolt 5. Projection 2. Pull the panel downward while pushing the projection. To install a panel 1. Place the panel in the original position. 2. Install the bolts and nut, and then tighten them to the specified torques.

  • Page 114: Checking The Spark Plug

    Tightening torques: Panel bolt: 4.0 N·m (0.40 kgf·m, 3.0 lb·ft) Footboard nut: 4.0 N·m (0.40 kgf·m, 3.0 lb·ft) EBU38131 Checking the spark plug The spark plug is an important engine component, which is easy to check. Since heat and deposits will cause any spark plug to slowly erode, the 1.
  • Page 115 If the spark plug shows a distinctly different color, the engine could be operating improperly. Do not attempt to diagnose such problems yourself. In- stead, have a Yamaha dealer check the vehicle. 1. Spark plug gap 2. Check the spark plug for electrode erosion...

  • Page 116: Engine Oil And Oil Filter Cartridge

    Tightening torque: Spark plug: If the engine was started before checking the oil 13 N·m (1.3 kgf·m, 9.6 lb·ft) level, warm up the engine, and then wait at least 10 minutes until the oil settles for an accurate reading. If a torque wrench is not available when installing 3.
  • Page 117 1. Engine oil dipstick 1. Maximum level mark 2. Minimum level mark 5. Insert the dipstick completely into the oil filler 6. If the engine oil is at or below the minimum hole, and then remove it again to check the oil level mark, add sufficient oil of the recom- level.
  • Page 118 1. Oil filter cartridge 2. Oil filter wrench An oil filter wrench is available at a nearby Yamaha 1. Engine oil drain bolt dealer. 2. Gasket 8.
  • Page 119 1. O-ring 1. Torque wrench Tightening torque: Oil filter cartridge: Make sure that the O-ring is properly seated. 17 N·m (1.7 kgf·m, 13 lb·ft) 9. Install the new oil filter cartridge with an oil fil- 10. Install panel F. ter wrench, and then tighten it to the specified 11.

  • Page 120: Why Yamalube

    Be sure to wipe off spilled oil on any parts after the Why Yamalube engine and exhaust system have cooled down. YAMALUBE oil is a Genuine YAMAHA Part born of the engineers’ passion and belief that engine oil is ECB00301 an important liquid engine component.

  • Page 121: Final Gear Oil

    1. Final gear oil age before each ride. If any leakage is found, have 2. Gasket a Yamaha dealer check and repair the ATV. In ad- 3. Final gear oil level check bolt dition, the final gear oil level must be checked and 4.
  • Page 122 To change the final gear oil 1. Park the ATV on a level surface. 2. Place an oil pan under the final gear case to collect the used oil. 3. Remove the final gear oil filler bolt, the final gear oil level check bolt, the final gear oil drain bolt and their gasket to drain the oil from the final gear case.

  • Page 123: Differential Gear Oil

    The differential gear case must be checked for oil leakage before each ride. If any leakage is found, 1. Final gear oil have a Yamaha dealer check and repair the ATV. 2. Gasket In addition, the differential gear oil level must be 3.
  • Page 124 To check the differential gear oil level 5. Install the oil filler bolt and its gasket, and then 1. Park the ATV on a level surface. tighten the bolt to the specified torque. 2. Remove the differential gear oil filler bolt and Tightening torque: its gasket, and then check the oil level in the Differential gear oil filler bolt:...

  • Page 125: Coolant

    4. Install the drain bolt and its new gasket, and Recommended differential gear oil: then tighten the bolt to the specified torque. See page 11-1. Tightening torque: 6. Check the oil filler bolt gasket for damage, Differential gear oil drain bolt: and replace it if necessary.
  • Page 126 1.99 L (2.10 US qt, 1.75 Imp.qt) The coolant should be between the minimum and If genuine Yamaha coolant is not available, use an maximum level marks. ethylene glycol antifreeze containing corrosion in- hibitors for aluminum engines and mix with dis- tilled water at a 1:1 ratio.
  • Page 127 0.24 L (0.25 US qt, 0.21 Imp.qt) a Yamaha dealer check the antifreeze con- tent of the coolant as soon as possible, otherwise the effectiveness of the coolant will be reduced.
  • Page 128 EBU34213 To change the coolant EWB01891 WARNING Wait for the engine and radiator to cool before removing the radiator cap. You could be burned by hot fluid and steam blown out under pressure. Always place a thick rag over the cap when opening.
  • Page 129 1. Radiator cap 1. Coolant drain bolt 2. Gasket 5. Place a container under the engine, and then remove the coolant drain bolt and its gasket. (Use a trough or a similar object as shown to prevent coolant from spilling on the engine guard.) 1.
  • Page 130 6. Place a container under the coolant reservoir Tightening torque: to collect the used coolant. Coolant drain bolt: 7. Remove the coolant reservoir cap. 10 N·m (1.0 kgf·m, 7.4 lb·ft) 8. Disconnect the coolant reservoir hose on the coolant reservoir side, and then drain the 11.
  • Page 131 15. When coolant begins to flow out of the bolt 18. Loosen the cylinder head air bleed bolt, with- hole, tighten the water pump air bleed bolt to out removing it, to allow all of the air to es- the specified torque. cape from the air bleed bolt hole.
  • Page 132 24. Start the engine, and then check for coolant leakage. If any leakage is found, have a Yamaha dealer 1. Footboard nut check the cooling system. 2. Footboard bolt A 3.

  • Page 133: Cleaning The Air Filter Element

    EBU34233 Cleaning the air filter element The air filter element should be cleaned at the in- tervals specified in the periodic maintenance and lubrication chart. Clean or replace the air filter ele- ment more frequently if you ride in unusually wet or dusty areas.
  • Page 134 2. Remove the seat. (See page 5-23.) 3. Remove the air filter case cover by unhooking the air filter case cover holders. 1. Air filter element 5. Pull off the air filter element lock plate, and then remove the sponge material from the air 1.
  • Page 135 2. Sponge material damaged. 3. Air filter element lock plate 9. Apply Yamaha foam air filter oil or other qual- 6. Wash the sponge material gently but thor- ity foam air filter oil to the sponge material. oughly in solvent. WARNING! Always use parts cleaning solvent.

  • Page 136: Cleaning The Spark Arrester

    case. Never operate the engine with the air filter element removed. Doing so would al- low unfiltered air to enter the engine, caus- ing rapid engine wear and possible engine damage. Additionally, the fuel injection system would be affected resulting in poor engine performance and possible over- heating.

  • Page 137: V-Belt Case Drain Plug

    V-belt case, remove the V-belt case drain plug to drain the water from the case. If water drains from the V-belt case after removing the plug, have a Yamaha dealer check the ATV as the water may affect other engine parts. 9-40...

  • Page 138: Adjusting The Throttle Lever Free Play

    The valve clearance changes with use, resulting in improper air-fuel mixture and/or engine noise. To prevent this from occurring, the valve clearance must be adjusted by a Yamaha dealer at the inter- vals specified in the periodic maintenance chart. 1. Rubber cover 2.

  • Page 139: Checking The Front Brake Pads And Rear Brake Friction Plates

    The rear brake friction plates must be checked that the wear indicator groove has almost disap- and, if necessary, replaced by a Yamaha dealer at peared, have a Yamaha dealer replace the brake the intervals specified in the periodic maintenance pads as a set.

  • Page 140: Checking The Brake Fluid Level

    Therefore, be sure to check the brake pads for wear and the brake system for leakage. If the brake fluid level suddenly goes down, have a Yamaha dealer check the brake sys- tem before further riding. EWB02721 WARNING Improper maintenance can result in loss of braking ability.

  • Page 141: Changing The Brake Fluid

    There should be no free play at the brake lever  Oil seals: Replace every two years. end. If there is free play, have a Yamaha dealer in-  Brake hoses: Replace every four years. spect the brake system.
  • Page 142 Adjusting the brake lever free play Measure the brake lever free play as shown. 1. Locknut 2. Brake lever free play adjusting bolt 1. Brake lever free play 2. To increase the brake lever free play, turn the brake lever free play adjusting bolt in direction Brake lever free play: (a).
  • Page 143 1. Brake cable adjuster locknut 1. Brake pedal free play 2. Brake lever free play adjusting nut 3. Rubber cover Brake pedal free play: 12.0–17.0 mm (0.47–0.67 in) 5. Loosen the brake cable adjuster locknut. 6. To increase the brake lever free play, turn the If the free play is incorrect, adjust it as follows.

  • Page 144: Axle Boots

    Check the axle boots for tears or damage. If any damage is found, have them replaced by a Yamaha dealer. 1. Brake pedal free play adjusting nut 2. Locknut 3. To increase the brake pedal free play, turn the brake pedal free play adjusting nut in direc- tion (a).

  • Page 145: Brake Light Switches

    If a cable is damaged or does not move lows, but the front brake light switch should be ad- smoothly, have a Yamaha dealer check or replace justed by a Yamaha dealer. Turn the rear brake light switch adjusting nut while holding the brake light switch in place.

  • Page 146: Rear Brake Levers

    EWB02582 Recommended lubricants: WARNING Front brake lever:  Inspect cables frequently and replace if Silicone grease damaged. Corrosion can result when the ca- Rear brake lever: ble sheaths become damaged, and cables Lithium-soap-based grease can also become frayed or kinked, which could restrict the operation of controls and Front brake lever lead to an accident or injury.

  • Page 147: Checking And Lubricating The Brake Pedal

    Yamaha dealer check the wheel hub bearings. To access the brake pedal pivot, remove panel G.

  • Page 148: Checking The Stabilizer Bushes

    The rear knuckle pivots must be lubricated at the or damage at the intervals specified in the periodic intervals specified in the periodic maintenance maintenance and lubrication chart. and lubrication chart. Have a Yamaha dealer replace the stabilizer bush- es if necessary. Recommended lubricant: Lithium-soap-based grease 9-51...

  • Page 149: Lubricating The Steering Shaft

    For parts equipped with a grease nipple, use a grease gun. EBU25096 Lubricating the steering shaft The steering shaft must be lubricated by a Yamaha dealer at the intervals specified in the pe- riodic maintenance chart. Recommended lubricant: Lithium-soap-based grease 9-52...

  • Page 150: Battery

     It is recommended to have the battery serviced KEEP OUT OF REACH OF CHILDREN. by a Yamaha dealer. To remove the battery 1. Remove panel A. (See page 9-9.) 2. Remove the front carrier by removing the bolts.
  • Page 151 3. Remove the battery holding plate by remov- ing the nuts. 4. Disconnect the negative battery lead first, then the positive battery lead by removing their bolt. NOTICE: When removing the bat- tery, the main switch must be off, and the negative lead must be disconnected be- fore the positive lead.
  • Page 152 ECB00622 ECB00942 NOTICE NOTICE  Always keep the battery charged. Storing the Never attempt to open the battery or remove the battery cell seals, as this would permanent- battery in a discharged state for an extended ly damage the battery. period of time will cause permanent battery damage.

  • Page 153: Replacing A Fuse

    5. Install the panel.  Make sure the positive and negative battery leads are installed as shown.  Fully charge the battery before installing it. EBU30525 Replacing a fuse 1. Positive battery lead (red) 2. Negative battery lead (black) 3. Install the battery holding plate by installing the nuts.
  • Page 154 YFM700FWB YFM700FWBD / YFM70KPAL 1. Headlight fuse 1. Headlight fuse 2. Signaling system fuse 2. Radiator fan motor fuse 3. Radiator fan motor fuse 3. Signaling system fuse 4. Ignition fuse 4. Ignition fuse 5. Auxiliary DC jack fuse 5. Four-wheel-drive motor fuse 6.
  • Page 155 Fuel injection system fuse: 15.0 A EPS fuse: 40.0 A (YFM700FWBD, YFM70KPAL) 4. Turn on the main switch and start the engine. 5. If the fuse immediately blows again, have a Yamaha dealer check the vehicle. 6. Install the panel. 9-58...

  • Page 156: Replacing A Headlight Bulb

    EBU34223 Replacing a headlight bulb If a headlight bulb burns out, replace it with the specified bulb as follows. Left and right headlight bulbs 1. Remove the cover at the rear of the headlight by pulling it off. 1. Bulb cover 3.
  • Page 157 4. Remove the burnt-out bulb. 7. Install the bulb cover and the cover at the rear 5. Place a new bulb into position. NOTICE: Do of the headlight. NOTICE: Make sure the not touch the glass part of the bulb. Oil bulb cover is securely fitted over the sock- from your fingers or other contamination et and seated properly.
  • Page 158 4. Remove the burnt-out bulb. 5. Place a new bulb into position. NOTICE: Do not touch the glass part of the bulb. Oil from your fingers or other contamination will adversely affect the transparency of the glass, luminosity of the bulb, and bulb life.

  • Page 159: Adjusting A Headlight Beam

    9. Adjust the handlebar-mounted light beam if necessary. EBU25553 Adjusting a headlight beam ECB00691 NOTICE It is advisable to have a Yamaha dealer make this adjustment. To raise a headlight beam, turn the headlight beam adjusting screw in direction (a). 9-62...

  • Page 160: Replacing The Brake/Tail Light Bulb

    YFM700FWBD / YFM70KPAL 1. Brake/tail light bulb holder 1. Handlebar-mounted light beam adjusting screw 2. Remove the burnt-out bulb by pushing it in EBU25615 and turning it counterclockwise. Replacing the brake/tail light bulb If the brake/tail light bulb burns out, replace it as follows.

  • Page 161: Removing A Wheel

    3. Insert a new bulb into the bulb holder, push it EBU36243 Installing a wheel in, and then turn it clockwise until it stops. 1. Install the wheel with the arrow mark pointing 4. Install the bulb holder (together with the bulb) in the forward rotating direction of the wheel, by turning it clockwise.

  • Page 162: Troubleshooting

    The following troubleshooting charts represent quick and easy procedures for checking these vi- tal systems yourself. However, should your ATV require any repair, take it to a Yamaha dealer, whose skilled technicians have the necessary 1. Tapered nut tools, experience, and know-how to service the 2.

  • Page 163: Troubleshooting Charts

    Remove the spark plug and check the electrodes. The engine does not start. Have a Yamaha dealer check the ATV. Check the compression. 4. Compression The engine does not start. There is compression.
  • Page 164 Start the engine. If the engine overheats again, have a The coolant level Yamaha dealer check and repair the cooling system. is OK.  Tap water can be used in an emergency. Change to the recommended coolant as soon as possible.

  • Page 165: Cleaning And Storage

    EBU25861 CLEANING AND STORAGE and deterioration of wheel bearings, EBU25882 Cleaning brakes, transmission seals and electrical Frequent, thorough cleaning of your ATV will not devices. Many expensive repair bills have only enhance its appearance but will improve its resulted from improper high-pressure de- general performance and extend the useful life of tergent applications such as those avail- many components.

  • Page 166: Storage

    4. Perform the following steps to protect the en- EBU27264 Storage gine from internal corrosion. a. Remove the spark plug cap and spark Short-term plug. Always store your ATV in a cool, dry place and, if b. Pour a teaspoonful of engine oil into the necessary, protect it against dust with a porous spark plug bore.
  • Page 167 8. Remove the battery and fully charge it. (See page 9-53.) 10-3...

  • Page 168: Specifications

    EBU25964 SPECIFICATIONS Weight: EBU38810 Curb weight: 306.0 kg (675 lb) (B5KK) 313.0 kg (690 lb) (B6KA) The 4-digit model type code can be confirmed by 318.0 kg (701 lb) (B5KJ) 323.0 kg (712 lb) (B5KN, B5KS, B5KV) checking the model label. (See page 1-1.) Loading: Maximum loading limit: Dimensions:...
  • Page 169 2.10 L (2.22 US qt, 1.85 Imp.qt) Lubrication system: Final gear oil: Wet sump Type: Engine oil: Yamaha Friction Modified Plus Shaft Drive Oil (Part No.: Recommended brand: ACC-SHAFT-PL-32) Quantity: 0.52 L (0.55 US qt, 0.46 Imp.qt) Differential gear oil:...
  • Page 170 Quantity: Drivetrain: 0.21 L (0.23 US qt, 0.19 Imp.qt) Primary reduction ratio: Coolant quantity: 1.000 Radiator (including all routes): Secondary reduction ratio: 1.99 L (2.10 US qt, 1.75 Imp.qt) 9.545 (41/21 x 24/18 x 20/15 x 33/12) Coolant reservoir (up to the maximum level mark): Final drive: 0.24 L (0.25 US qt, 0.21 Imp.qt) Shaft...
  • Page 171 Tire air pressure (measured on cold tires): Rear: 45.0 kPa (0.450 kgf/cm², 6.5 psi) Recommended (For Oceania): Front wheel: Front: 35.0 kPa (0.350 kgf/cm², 5.0 psi) Rim size: Rear: 12 x 6.0 AT 30.0 kPa (0.300 kgf/cm², 4.4 psi) Rear wheel: Minimum (For Oceania): Rim size: Front:...
  • Page 172 Shock absorber: Reverse indicator light: Hydraulic damper Wheel travel: Coolant temperature warning light: 230 mm (9.1 in) Electrical system: Park indicator light: System voltage: Four-wheel-drive indicator light: 12 V 1.7 W (YFM700FWB) Ignition system: Engine trouble warning light: Charging system: High-range indicator light: AC magneto LED (YFM700FWBD, YFM70KPAL)
  • Page 173 Fuel injection system fuse: EBU38670 15.0 A Four-wheel-drive motor fuse: CO2 emissions levels statement (for Europe) 10.0 A (YFM700FWBD, YFM70KPAL) This CO2 measurement results from testing over a Radiator fan motor fuse: fixed test cycle under laboratory conditions a(n) 20.0 A (parent) engine representative of the engine type EPS fuse: 40.0 A (YFM700FWBD, YFM70KPAL)

  • Page 174: Consumer Information

    EBU26004 CONSUMER INFORMATION Your Yamaha engine was designed and tested to EBU38690 Emissions Certification label (for Eu- give an optimal blend of performance without ex- rope) cessive emissions. Therefore, do not attempt to This engine conforms to the Non-Road Mobile...
  • Page 175 INDEX Accessories and loading ..........7-5 Differential gear lock, indicators (YFM700FWBD / Accessories, DC jack ........... 5-28 YFM70KPAL) ............... 5-5 Air filter element, cleaning ........... 9-36 Differential gear oil ..........6-3, 9-26 Axle boots ..............9-47 Drive lever 2WD/4WD (YFM700FWB) ......5-17 Drive select lever ............
  • Page 176 Headlight bulb, replacing ..........9-59 Parking on a slope ............7-5 High beam indicator light ..........5-3 Part locations ..............4-1 High-range indicator light (YFM700FWBD / YFM70KPAL) ...............5-2 Rear brake, adjusting the lever, pedal free play ..9-44 Horn switch ..............5-13 Rear knuckle pivots, lubricating ........9-51 Reverse indicator light ...........
  • Page 177 V-belt case drain plug ..........9-40 Vehicle identification number ........1-1 Wheel hub bearings, checking ........9-50 Wheel, installing ............9-64 Wheel, removing ............9-64 Yamalube ..............9-23 13-3...
  • Page 178 EBU26173 WARNING Improper ATV use can result in SEVERE INJURY or DEATH. NEVER USE ALWAYS USE NEVER USE NEVER CARRY AN APPROVED PASSENGERS WITH DRUGS ON PAVED HELMET AND OR ALCOHOL ROADS PROTECTIVE GEAR NEVER ALWAYS operate: • without proper training or instruction. •...

This manual is also suitable for:

Yfm700fwbdYfm700fwbYfm70kpal

Table of Contents
