- Page 1 AF-X2 AF-X2 Floor Scrubber operation instructions...
- Page 2 AF-X2 Content Chapter 1 Description 1.1 Content and Purpose ............... 5 1.2 General Instructions ................ 5 1.3 Safety requirements for batteries ............ 6 1.4 General safety regulations ...............7 Chapter 2 Use of the Machine ..............8 2.1 Buttons/Panels of the Machine ............8 2.2 The operation process of the machine ..........
- Page 3 AF-X2 Warranty ....................20...
- Page 4 AF-X2 Parts ①Recovery tank cover ④Universal wheel ②Brush ③Tires ⑤Anti-collision wheel ⑥Universal wheel ⑧Sewage pipe ⑦Armrest ⑨Suction handle ⑩Brush plate lift pedal ⑪Suction pipe ⑫Squeegee ⑬Fresh water inlet ⑭Suction motor ⑮Sewage inlet Performance parameters Maintenan Liquid-fil Type Wire-drawing Category Maintenan...
- Page 5 AF-X2 Chapter 1 Description 1.1 Content and Purpose The following content points out potentially dangerous situations, please read these instructions carefully and take necessary precautions. The essence of this machine operator's manual is to prevent injuries, and most accidents are caused at work by not heeding basic safety rules.
- Page 6 AF-X2 ● Please keep loose clothing, hair, fingers and other body parts away from the machine's air vents and any moving parts. ●When the machine stops, remember to turn off the power. ●Do not use the machine where the inclination exceeds the rated value of the machine.
- Page 7 AF-X2 ●Do not connect or remove the battery when the key switch is in the ON position. ●Before removing or installing batteries, first disconnect the negative (-) battery wire, and then disconnect the positive (+) battery wire. When rewiring, be sure to pay attention to the polarity of the battery, as wrong connection will damage electrical components.
- Page 8 AF-X2 Chapter 2 Use of the Machine 2.1 Buttons/Panels of the Machine 2.1.1 The core control keys of the machine ●①Power/Voltmeter (the display device can display the current battery voltage, please charge when the voltage is lower than 21V). ●②Power switch...
- Page 9 AF-X2 ●Open the cover of the water tank before using the machine, pour clean water into the water tank, pay attention to the water quality, and prevent the waterway from being blocked. ●When the machine is used to clean the epoxy floor, it is necessary...
- Page 10 AF-X2 Pull the handle down and put down the water absorption swaying tail bracket. Step 2: Thread the Absorbent Fixing Screw through the Tripod. Step 3: Install the sewage suction pipe. The squeegee has been debugged at the factory and can be used...
- Page 11 AF-X2 Step 3: Turn on the main power switch, Step 4: Tighten the handlebars and keep driving at a constant speed. start the brush switch button and the water absorption motor switch button; Stop of the machine ●Close the brush switch button first;...
- Page 12 AF-X2 ●After each work is completed, please flush the sewage tank in time to keep the machine well maintained. ●After the operation in winter, please drain the clean water tank in time to avoid freezing and affect the reuse. Sewage tank discharge sewage ●Turn off the main power to ensure that the machine stops;...
- Page 13 AF-X2 Chapter 3 Routine Maintenance and Disassembly and Replacement of Wearing Parts 3.1 Periodic Inspection Intervals（h） Regular maintenance and inspection Battery level detection Motor carbon brush inspection Whether the main brush is wired, the silk is entangled Check for debris in the tank...
- Page 14 AF-X2 Note: When installing, make sure the flange is aligned with the brush plate button holes. ●Replacement of the dial: The dial can be purchased through our company's operating platform. Body replacement is to place the cleaning pad on the bottom of the dial and make it fit with the dial solid and neat fit.
- Page 15 AF-X2 ●Put down the squeegee through the handle; after rotating the plastic handle in the opposite direction, take out the squeegee assembly. ●Unscrew the squeegee assembly nut, remove the bottom plate of the squeegee assembly, and remove the front and rear rubber strips of the squeegee.
- Page 16 AF-X2 The power system of this washing machine is powered by two 12V maintenance-free lead-acid batteries in series, and the system voltage is 24V. ●When the machine works for a period of time, the battery power drops, and when the last bar of the power display meter is flashing, it means that the power is insufficient and needs to be charged in time;...
- Page 17 AF-X2 ●Removal of suction motor: The suction motor is fixed at the bottom of the clean water tank. Before removing: 1. First empty the machine with clean water, turn off the main power switch, and keep the machine powered off;...
- Page 18 AF-X2 3.7 Disassembly of the float cage In the daily use of the machine, because the floating ball cage exists in the sewage tank, and when the sewage is too full, the floating ball will be sucked at the air outlet by the suction of the suction motor, and the customer needs regular maintenance.
- Page 19 AF-X2 Fan not working Suction motor noise is too loud Please contact the service center Suction motor burned out Replace the suction motor Carbon brush wear Please contact the service center Little or no water Clogged water tank drain valve or...
- Page 20 AF-X2 Maintenance operation Every Every Every Every Every handover 100h 200h 500h Brush Disc Height Adjustment Check Whether the brush plate is wired or entangled Squeegee Cleaning Complete Inspection Tank cover seal inspection Screw and nut tightening inspection Check the wear of the brush disc...
- Page 21 AF-X2 Fault description Warranty Conditions 1. Within the day when the user purchases this product, the motor is guaranteed for one year (more than 7 days from the date of purchase, no replacement, only warranty); 2. Before using the equipment, you must understand the instructions and safety instructions;...
