- Page 1 AF-X1 Floor Scrubber operation instructions...
- Page 2 AF-X1 Content 1.0 Operation safety guidance .....3 2.0 Safety requirements for batteries ..5 3.0 Features and Parameters ...... 6 4.0 Routine maintenance and replacement of wearing parts ..........7...
- Page 3 AF-X1...
-
Page 4: Operation Safety Guidance
AF-X1 1.0 Operation safety guidance Please read this manual carefully before operating the machine. General safety reference in machine preparation, operation and maintenance. This book describes in detail the accident prevention rules that must be observed during use. The manufacturer is not responsible for any accidents caused by failure to comply with these rules! This manual is also an important accessory of the machine. - Page 5 AF-X1 ● Batteries of different specifications and brands have matching chargers. Using a charger that does not match may damage the battery or even cause the battery to burst. Be sure to pay great attention to it! The maintenance of the machine must be carried out by professionals in the special maintenance department.
-
Page 6: Safety Requirements For Batteries
AF-X1 2.0 Safety requirements for batteries ●It is necessary to avoid the battery being in a low voltage state, and it should be charged as soon as possible. ●To avoid leakage of electricity, please keep the battery dry and clean, especially to remove contaminants such as metal dust. -
Page 7: Features And Parameters
AF-X1 3.0 Features and Parameters Serial number Item Unit Number Cleaning efficiency 1350 ㎡/h Brush width Squeegee width Brush speed Brush motor power Suction motor power Clean/sewage tank 15/20 Battery capacity V/AH 12V32Ah*2 Operating hours 1.5~2 Total Weight Product Size... -
Page 8: Routine Maintenance And Replacement Of Wearing Parts
AF-X1 4.0 Routine maintenance and replacement of wearing parts Preparing before working According to the soiled state of the ground, select the clearing agent and the concentration of the clearing agent: In general, you only need 2 cups of cleaning solution in a disposable water cup (disposable water cups are commonly used, in order to protect the environment, please minimize the amount of detergent, please use a neutral low-foaming detergent). - Page 9 AF-X1 according to the scrubbing conditions, and move the water volume adjustment handle up and down. Control the flow of water to clean the ground. It can also reduce the consumption of clean water (detergent). Start the switch, brush the motor. The solenoid valve opens and the machine starts to work.
- Page 10 AF-X1 are basically aligned At this time, press the start button of the brush plate motor on the control panel, and the brush plate will be automatically installed as the motor rotates. You can start the operation immediately, or you can install it manually. It is recommended for unskilled employees to manually install and remove the brush.
- Page 11 AF-X1 ① Wipe the outside of the washing machine with a dry cloth; empty the sewage in the sewage tank and clean it. ② Raise the brush plate and squeegee; park the scrubber in a surrounding environment with no flammable gas, liquid, chemicals, no open flame, dry and ventilated, and flat ground, and store it.
- Page 12 AF-X1 Inspection Certificate Number： Model Motor Accessories Power Switch Shell cable Suction Control Fuselage Function Manual Package Warranty Card Number： Name Tell Mailing address Bill Purchase time number Fuselage Product number number Replacement Date parts Fault description: Warranty conditions: Warranty Conditions 1.
- Page 13 AF-X1 5. The buyer can go to the designated point of the seller for maintenance with the invoice, or send the machine back to our company for repair (the round-trip shipping fee and the insurance fee should be paid by themselves).
