- Page 1 User manual Integrated burner EQBW40AS...
- Page 2 WE’RE THINKING OF YOU CONTENTS Thank you for purchasing an Electrolux appliance. General warnings You’ve chosen a product that brings with it decades Electrolux Integrated burner product description of professional experience and innovation. Ingenious Gas specifications and stylish, it has been designed with you in mind.
- Page 3 Read the following carefully to avoid damage or injury. manual. If the leak persists, turn off the gas supply and call Electrolux Service Centre or a Licensed Gas Fitter. NOTE! You must read these warnings carefully before installing or using the appliance. If you need assistance, contact your Customer Care Department.
- Page 4 INTEGRATEd BURNER Slimline lid Gas connection point Weatherproof cover EQB40ACBL...
- Page 5 Pivoting lid safety leg Lid mounting bracket Trivet Burner caps Burner crown Burner control...
- Page 6 GAS SPECIFICATIONS GAS CONNECTION dETAIL Gas type Natural gas Universal LPG maximum gas 13.5 mJ/h 11 mJ/h consumption Injector orifice 1.80mm 0.95mm diameter (mm) Number of injectors Regulator pressure 1.00 kPa 2.75 kPa NOTEs: • This appliance MUST be installed and serviced only by a qualified licensed person.
- Page 7 NATURAL GAS INSTALLATION 5. Fit to mains • Connect the bayonet end to mains Preparing the unit for Natural Gas connection to mains For Natural Gas connection, a bayonet connection point should be installed by a licensed gas fitter prior to installing the unit. 6. Ensure routing of gas supply hose prevents the hose from contacting hot surfaces of burner base or burner box.
- Page 8 • T urn off the valve and re-tighten the joint. Repeat the to an unregulated supply, ensure supply pressure at the leak test. barbecue is 2.75kPa. Electrolux strongly recommends that a manual shut off valve be installed in the gas supply • I f the leak persists, turn off the gas at the isolation line in an accessible position so that the gas supply can valves and contact a licensed gas fitter to correct.
- Page 9 3. Replace natural gas injector (1.80mm hole) with ULPG injector (0.95mm hole). Brass injector 4. Replace burner crown, burner caps and trivet, ensuring burner is seated correctly. 5. Fit LPG regulator and hose assembly to gas inlet and connect to gas bottle. See page 10 for gas bottle safety information.
- Page 10 GAS BOTTLE SAFETY INFORmATION INSTALLATION WARNINGS • T his appliance once converted to use Universal LPG is WArNING! designed to use a 9kg (20 lbs) gas cylinder. • T his appliance shall only be used in an above ground, • T he gas cylinder must be made and marked in open air situation with natural ventilation without accordance with specifications for LPG cylinders. stagnant areas, where gas leakage and products of • I t is recommended to turn off the cylinder valve when combustion are rapidly dispersed by wind or natural...
- Page 11 INSTALLATION INSTRUCTIONS Choosing a location • T his appliance must not be installed on any combustible material. • T he vertical clearance above the cooking surface to any combustible materials must be at least 600mm. • T his appliance must be installed accordance with Australian Standards AS 4557 and AS 5601 and in accordance with local authority. • W hen using LPG in an enclosure, ventilation must be provided.
- Page 12 GAS REQUIREmENTS Natural Gas requirements • T he enclosure must be constructed so that access can be gained to the Natural Gas regulator at all times. • F or Natural Gas the gas supply is required to be connected to 1.2m flexible hose supplied and therefore must be located within this distance. • T he flexible hose has a quick connect gas coupling. he corresponding mating fitting will be required at the gas supply end.
- Page 13 LOCATING INTEGRATEd BURNER CONNECTING WITH ELECTROLUx AdJACENT TO INTEGRATEd BARBECUE INTEGRATEd BARBECUE If the integrated burner is located adjacent to the built in barbecue and the units are to be connected to the same outlet or cylinder, the gas line must branch off prior to the regulator.
- Page 14 SETTING UP THE BURNER BURNER OPERATION Control functions Before lighting the burner: Setting up the burner module in mounting enclosure • Check that all hoses and gas fittings are tight. • A fter the enclosure has been constructed as • Remove or pivot lid to open. described, position the assembled burner module into the cut-out hole. NOTE The lid is designed as a cover for weather protection.
- Page 15 PIvOTING LId SAFETY LEG To ensure that the user remembers to turn off the gas before closing the lid, a pivoting safety leg has been fitted. Pivoting safety leg When closing the lid the safety leg will pivot forward and rest against the trim surface to prevent the lid closing.
- Page 16 You will • T his appliance contains aluminium fittings. Do not use find these cleaners at Electrolux spare parts outlets. caustic based cleaners Burners • D o not use steam cleaners as this may cause moisture build up on electrical components.
- Page 17 Possible remedy To order any of the following accessories, or for more cause information on any other suitable accessories for this product, please contact the Electrolux Customer Service Centre. Barbecue No gas Check isolation valve is ON won’t light Accessory...
- Page 18 NOTES...
- Page 19 Australia or New Zealand. failure and for compensation for any other reasonably foreseeable loss or 3. During the Warranty Period Electrolux or its ASC will, at no extra charge damage. You are also entitled to have the Appliance repaired or replaced...
- Page 20 “Oh! How did you know? That’s exactly what I wanted!” That’s the kind of feeling that the designers at Electrolux seek to evoke in everyone who chooses or uses one of our products. We devote time, knowledge, and a great deal of thought to anticipating and creating the kind of appliances that our customers really need and want.
