DCP501
DCP501 User Guide
Addendum 495993-001
This addendum updates information in your DCP501 User Guide. Please reference these
changes when using the User Guide. We apologize for any inconvenience that these updates
may have caused you.
Introduction
Disc Information
Page 5 — In the list of CD-ROM and DVD formats, change the first item and add the second
item shown below:
DVD+R/DVD-RAM (The DCP501 can play DVD-R format).
SACD (SuperAudio CD)
Page 5 — Remove VSD from the list of unsupported disc formats.
DCP501 Display
Page 9 — Change items 5, 9, and 10 to read as follows:
5
9
10
Page 10 — Change item 18 to read as follows:
18
Operating the Remote Control
Page 18 — Change item 34 to read as follows:
34
INFO
On indicates Dolby 3 Channel Stereo is the currently selected audio mode.
On indicates standard 2 Channel Stereo is the currently selected audio mode.
Tuner: On indicates the tuned signal received is strong.
Flashing indicates a weak FM signal.
Tuner: On indicates the tuned FM signal received is transmitting in stereo.
DVD: REPEAT turns on to indicate Disc Repeat, and flashes TITLE or
CHAPTER to indicate Title or Chapter Repeat.
CD: REPEAT turns on to indicate Disc Repeat, and flashes TRACK to indicate
Track Repeat.
CATV source: CATV Application controlled.
DVD/CD source: Display DVD/CD Info Banners.
DCP501 User Guide Addendum

Advertisement

loading
Need help?

Need help?

Do you have a question about the DCP501 and is the answer not in the manual?

Questions and answers

Summary of Contents for Motorola DCP501

  • Page 1 DCP501 DCP501 User Guide Addendum 495993-001 This addendum updates information in your DCP501 User Guide. Please reference these changes when using the User Guide. We apologize for any inconvenience that these updates may have caused you. Introduction Disc Information Page 5 — In the list of CD-ROM and DVD formats, change the first item and add the second item shown below: DVD+R/DVD-RAM (The DCP501 can play DVD-R format).
  • Page 2 DCP501 Installation Audio Connections for Your VCR Page 38 — use the drawing below in place of the one found in your user guide for connecting a mono VCR to the DCP501. Figure 19 Mono VCR audio connections DCP501 MODEL NO.: DCP 501 À...
  • Page 3 You can connect an alternate audio/video source such as another DVD player by following the diagram. If you wish to use the digital audio output from a DVD player to the DCP501, you must assign either the Optical1 or Coaxial digital audio input to the corresponding DCP501 video input source by using the INPUT SETUP screens.
  • Page 4 Page 73 —Change the first paragraph to read as follows: The DCP501 does not have record capability, but it allows you to watch one source like a DVD while recording a cable TV channel on a VCR or PVR. This is known as the CATV RECORD feature.
  • Page 5 The DCP501 has many sound effects that can be selected and stored. When the SOURCE CATV cable TV providers may be using analog or Dolby Digital audio. The DCP501 allows you to select and store a favorite sound effect for each. On any other SOURCE...
  • Page 6 After finishing your changes in the DVD Setup, exit the menus. Press PLAY PAUSE on the front panel or the play button (►) on the DCP501 remote control to continue playing your DVD from where you left off. Do not press STOP...
  • Page 7 Turn down the volume a little and switch the DCP501 off and then switch the DCP501 back on and the DCP501 should now work as normal. If O V E R L O A D is still displayed, turn the volume down some more.
  • Page 8 Motorola and the stylized M logo are registered in the US Patent and Trademark Office. All other product or service marks are the property of their respective owners. Copyright © 2002 by Motorola, Inc. Dolby Digital, Dolby Surround and the double-D symbol are registered trademarks of Dolby Laboratories; Dolby Digital is manufactured under license from Dolby Laboratories.
