- Page 2 WELCOME Welcome to Sytech! Thank you for purchasing the new Professional Acoustic System SY-XTR53BT Neon Blast 180. Please read this manual carefully before operating your product and pay close attention to the precautions which are mentioned below. Store this user manual in a safe place for future reference.
- Page 3 The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance. To prevent risk of fire or electric shock, avoid overloading wall outlets, extension cords, or Integral convenience receptacles.
- Page 4 Servicing and repairs • Refer all servicing to qualified service personnel. • Servicing is required when the apparatus has been damaged in any ways: such as liquid has been spilled or objects have fallen into the apparatus; The apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.
- Page 5 This product has no user serviceable parts. Do not try to repair this product yourself. Only qualified service personnel should perform the service. Contact Sytech technical service for a proper inspection and repair NEVER let anyone, especially children, insert anything into the holes, slots or any other openings in the unit’s casing as this could...
- Page 6 TOP PANEL 1. Mic 1 input jack: 6.3 mm microphone connector. 2. Mic 2 input jack: 6.3 mm microphone connector. 3. Aux input jack: 3.5 mm aux audio connector. 4. Micro SD slot: Insert Micro SD (Max 32 GB) 5. USB 2.0 port: Insert USB drive (Max 32 GB) 6.
- Page 7 Long press for: Repeat one track, repeat all tracks. 11. Menu: Selector for main volume, mic volume, treble and bass. 12. Previous: Press to return to the previous song in MP3 mode or to the previous FM station in FM mode. 13.
- Page 8 6. Bass +/-: Adjust the bass sound. 7. Mic Volume +/-: Adjust the microphone volume. 8. Play / Pause: Play & Pause button under MP3 and Bluetooth® mode. Auto scan under FM mode. 9. Standby: Press the Standby button to put your speaker in sleeping mode. Press again to turn on the speaker.
- Page 9 WITHIN 6 WEEKS, THE BATTERY WILL LOSE ITS CAPACITY AND WILL DIE OFF. UNDER THIS CIRCUMSTANCE, THE WARRANTY OF THE BATTERY WILL NOT BE COVERED BY SYTECH TECHNICAL CENTER. “ TURNING ON YOUR SPEAKER 1. Press the Power On/Off button (19) on the top control panel of the speaker to turn on the unit.
- Page 10 Input modes: Follow the below instructions to switch between Bluetooth®, FM radio, AUX and USB or Micro SD input modes. 1. Press the “MODE” button (15) on the main unit or on the remote control (3) repeatedly to cycle between Bluetooth®, FM radio, and AUX input modes.
- Page 11 2. Enable the Bluetooth® function on your smartphone, tablet or any other Bluetooth® device which you wish to connect to your speaker and search for “SY-XTR53BT”. Once found, select it to pair your external device to the speaker. The “...
- Page 12 “ would be still. 6. Connect your mobile device to Bluetooth® and search for SY-XTR53BT - speaker (A). Once found, click on it to pair your mobile to speaker (A). 7. Playback your favorite tracks and enjoy True wireless Stereo sound.
- Page 13 FUNCTIONS AND CONTROLS Once your speaker is connected to an external device via Bluetooth®, you can use the controls located on the top panel of the speaker or from the remote control. : Playback or pause the track. : Skip to the next track. : Skip to the previous track.
- Page 14 RECORDING FUNCTION 1. Plug in a microphone to the Mic 1 input. 2. Insert a USB prendrive or a Micro SD card into the corresponding port. 3. Press the MODE button and select USB/Micro SD mode. 4. If the USB pendrive or Micro SD card is plugged into the speaker for the first time, the system will automatically create a new folder named “RECORD”...
- Page 15 TROUBLESHOOTING Problem Reason Solution No Power Power cable is not Make sure the plug connected to the is connected. wall socket. Switch on the power. Power is not switched on. Battery is Connect the DC adaptor and charge the battery. No sound Increase the volume.
- Page 16 ENVIRONMENT AND COMPLIANCE Please consider our environment. Do not dispose of the appliance in your normal domestic waste. This product is subject to the European guideline 2012/19/EU. Dispose of the appliance through an approved disposal center or at your community waste facility. Observe the currently applicable regulations.
- Page 17 Unit dimension: (Width x Depth x Height): 30,8 x 29,5 x 63,8 cm. • Weight: 6.5 Kg. Above specifications are the specifications of SY-XTR53BT “Neon Blast” and are for reference purpose only. Due to continuous product development, specifications may be subject to change without prior notification.
- Page 18 Tel: 91 8865320 Fax: 91 8864285 CIF: B84254763 Manufacturing country: China Description: Party speaker Neon Blast 180 Sytech® SY-XTR53BT complies with the following Directive: RED Standard: Directive 2014/53/EU ROHS Standard: Directive 2015/863/EU Restriction of Hazardous Substances Signed: Ajeet Nebhwani Utamchandani Sole Administrator...
