Summary of Contents for Sytech SY-XTR10
-
Page 2: Safety Precautions
Read this manual carefully before using this item and its components. They contain instructions on how to use this product in a safe and effective manner. SYTECH cannot be responsible for problems resulting from failure to observe the instructions in this manual. -
Page 3: Charging The Speaker
Heat. Do not locate the appliance in the vicinity of a heat surface or in direct sunlight. Accessories. Use only supplied accessories Battery. Avoid overcharging. The battery could overheat. Replace battery. The built-in rechargeable battery is not replaceable. Do not remove or replace the battery, do not throw in the trash or in the fire. -
Page 4: Remote Control Functions
Warning: If the battery is under voltage, please charge it completely within 48 hours. If the speaker has been left unused for a long time, please let the battery fully charge before using it again, otherwise it will cause damage to the battery! During the process of playback, keep the unit away from high temperature environments, high magnetic fields and high frequencies. -
Page 5: Functions And Connections
Under normal circumstances, the remote control should be aimed directly at the receiving window of the unit from about 6 meters and within a 30° angle. When operating the remote control, aim the remote control at the receiving window of the unit and ensure that there are no obstacles between the remote control and the unit. -
Page 6: Rear Panel
REAR PANEL 1. Guitar input 2. Mic input 3. Mic Volume 4. Echo adjustment 5. USB port 6. TF card slot 7. Charging indicator light 8. DC input (13.5V/1A) 9. Power switch 10. Aux in 11. Mic input 3.5mm Guitar Guitar Jack: Connect your guitar through the jack at the back of the unit as shown above. -
Page 7: Wireless Microphone
Wireless Microphone (This picture is for reference purposes only!) Open the battery compartment, insert the batteries and ensure that the polarities are correct. Switch ON the power switch on the microphone or ear microphone transmitters. If the power indicator light does not light up, check that the battery has been inserted correctly. Adjust the microphone volume knob on the speaker When singing, if you need to suspend the wireless microphones, please switch to mute state (center) on the microphone, and if you want to stop using the microphone, please switch to... -
Page 8: Main Technical Specifications
Please ensure the BT devices you wish to connect has the Bluetooth function enabled and visible. Start the scan function from your device and search for “SY-XTR10”. Once you have found the device, press on it and connect the speaker with the device. -
Page 9: Troubleshooting
• 2 ways speakers: 6.5” Woofer, 2 x 1.5” tweeter • MIC Frequency: 256,1Mhz • Above specifications are the specifications of SY-XTR10 “Monster Beat” and are for reference purpose only. • Due to continuous product development, specifications may be subject to change without prior notification. -
Page 10: Declaration Of Conformity
Camarma de Esteruelas, 28816 Madrid Tel: 902 430 967 Fax: 91 8864285 NIF: B83254763 Manufacturing country: China Description: Trolley Speaker Sytech® SY-XTR10 complies with the following directives: EMC Standard: Directive 2014/30/EU R&TTE Standard: Directive 2014/53/EU ROHS Standard: Directive 2011/65/EU Restriction of Hazardous Substances... - Page 11 Applications of the standards: EN60950-1:2006+A11:2009+A1:2010+A12:2011+A2:2013 EN62479:2010 EN301 489-1 V1.9.2 (2011-09) EN301 489-17 V2.2.1 (2012-09) EN300 328 V1.9.1 (2015-02) EN62479:2010 EN60065:2014 EN55013:2013 EN61000-3-2:2014, EN61000-3-3:2013 EN55020:2007+A11:2011 EN61000-4-2:2009, EN61000-4-3:2006+A1:2008+A2:2010 EN61000-4-4:2012 Signed: Ajeet Nebhwani Utamchandani Sole Administrator...
