- Page 1 MettaX Digital (Shenzhen) Co., Ltd. Installation User Manual MC904 1 / 14...
- Page 2 MettaX Digital (Shenzhen) Co., Ltd. Contents Introduction .............................3 1. Product Specifications ........................4 2. Definition of Accessories and Interfaces ..................7 2.1 Inspection of Products and Accessories ................7 2.2 Panel Introduction ........................8 2.3 Interface Definition ........................8 3. Installation Instructions ........................9 3.1 SD Card &...
- Page 3 MettaX Digital (Shenzhen) Co., Ltd. Introduction The device is an intelligent terminal product that combines various advanced features such as GPS / BDS positioning monitoring, local SD card recording, 4G remote real-time video surveillance, IP-Camera, DMS / ADAS / BSD, and more. It seamlessly integrates real-time monitoring, production operation management, command dispatch, and other functionalities.
- Page 4 MettaX Digital (Shenzhen) Co., Ltd. electronic products and the requirements of vehicles and other connected equipment. 3) The installation and construction shall comply with the specifications, which can refer to the relevant national or local standards. 4) Please check the connected power supply voltage, which should fall within the range of 9V - 36V.
- Page 5 MettaX Digital (Shenzhen) Co., Ltd. Channels Segmentation Video Standard PAL Standard, NTSC Standard Video Compression H.264 / H.265 Compressed Format Format Single Channel, Support Multiple Channels Preview, Support Manual Preview Function / Event Triggered Full Screen Display Function Options: 1080P / 720P / D1 / HD1 / CIF...
- Page 6 MettaX Digital (Shenzhen) Co., Ltd. Multi Function Control Panel can be Connected (Support 12V Power-supply and RS232 Communication) Built-in 4G Wireless Transmission Function, TDD - LTE, FDD - LTE Wireless Transmission Wi-Fi: Wireless 802.11b / g / n Communication Module...
- Page 7 MettaX Digital (Shenzhen) Co., Ltd. Temperature -20℃ ~ +70℃ Work Environment Humidity 8% ~ 90% Security Password Two Level Management of User Password and Administrator Management Access Password JT/T808-2011, JT/T808-2019 Platform Protocol JT/T1076-2016, JT/T1078-2016 Appearance Size 120mm*120mm*46mm Net Weight 450g 2.
- Page 8 MettaX Digital (Shenzhen) Co., Ltd. BDS / GPS Antenna 1pcs 2pcs Remote Control 1pcs Mounting Screw 4pcs AV-IN (4-PIN) 1pcs 2.2 Panel Introduction Chart 1. Front Chart 2. Back 2.3 Interface Definition 8 / 14...
- Page 9 MettaX Digital (Shenzhen) Co., Ltd. This paper mainly introduces the definition of power supply, I / O, audio and video interfaces, as follows: 1) Definition of Power Interface Chart 3. 2) I / O Interface Definitions Chart 4. 3) Definition of Audio and Video Interface...
- Page 10 MettaX Digital (Shenzhen) Co., Ltd. card interfaces are visible once they are opened. SD Card and SIM Card Installation: Insert the SD card into the SD card slot with the connecting finger upward and the SIM card into the SIM card slot. Then lock on the cover.
- Page 11 MettaX Digital (Shenzhen) Co., Ltd. vertical windshield, it should be installed at the position a little below the center. 4) The ADAS camera is an analog camera, which does not support hot swap. You need to connect the cable before powering on the main device. If the main device already powered,...
- Page 12 MettaX Digital (Shenzhen) Co., Ltd. and the driver's face. ③The DMS camera must remain level horizontally and should not be tilted. While meeting the above conditions, the angle deviation from the driver's face should be minimized. Ideally, the camera should face the driver directly.
- Page 13 MettaX Digital (Shenzhen) Co., Ltd. 1) Put the upgrade software into SD card / U disk. 2) Insert SD card / U disk with upgrade file. 3) Enter the system menu "System Information" to view the application program and MCU version number.
- Page 14 MettaX Digital (Shenzhen) Co., Ltd. respectively. Arrow keys, up, down, left, right, cursor direction movement keys. Enter Enter the menu Return Return key: Return to the previous sub menu. Cancel Delete characters [0-9] key: in the setting state, the number input key is used to select numbers.
