Raptor 1000
PCI video graphics adapter, software configurable resolutions up to 1920 x 1080, 12 MB frame
buffer, includes DB-13-W3 to 4BNC video cable, operating system specific device driver software
and manuals.
Raptor OpenWindows for Solaris
Raptor X Servers for Digital UNIX
Frame Buffer Size
Color Lookup Table
Bits Per Pixel
Dynamic Color Plane Groups
Drawing Processor
PCI Interface
Video Interface
Video Sync
Video Connector
Temperature Rating
Humidity Rating
Power Rating
Physical
Raptor 1000 Technical Specifications
Software Available
Loadable drivers for Sun PCI systems running Solaris 2.6, 7 or 8.
Loadable drivers for the Digital/Compaq Alpha workstations running Tru64
UNIX, 4.0f, 5.0, 5.1.
Specifications
12 MB
1024 entries
8, 16 or 24 (software configurable)
24
Number Nine PCI graphics accelerator
33 MHz, 32-bit, Revision 2.1
Red, green and blue at RS-343 levels (50 ohm)
Separate sync at TTL levels (75 ohm)
DB-13-W3
10 degrees to 50 degrees C (operating)
-10 degrees to 70 degrees C (non-operating)
10% to 90% (non-condensing)
Less than 15 watts
12.283 inches x 4.2 inches (PCI long format)
