- Page 1 CIRCULATING AIR SOURCE HEAT PUMP INSTALLATION& OPERATION MANUAL Installation&Operation Manual AIR SOURCE HEAT PUMP WATER HEATER (CIRCULATING)
-
Page 2: Table Of Contents
CIRCULATING AIR SOURCE HEAT PUMP Installation & Operation Manual Contents I. Must-read for Users ..........................3 II. Appearance ............................... 4 III. Specifications ............................5 IV. Functions ..............................6 1. System operating principles ....................... 6 2. Heating mode ..........................6 3. Heating capacity ..........................6 4. -
Page 3: Must-Read For Users
● When the equipment is available for commissioning upon installation, call TICA’s hotline to request equipment commissioning service. The equipment is usable only after a commissioning test is done. TICA assumes no liabilities for any losses arising from unauthorized access to the equipment. -
Page 4: Appearance
CIRCULATING AIR SOURCE HEAT PUMP Caution: Failure to observe this Manual may cause fire, losses, personal injury or even be fatal. Warning: The power supply of this equipment must be reliably grounded before use. Within close proximity of the air source heat pump water heater, there must be a well-functioning floor drain. -
Page 5: Specifications
CIRCULATING AIR SOURCE HEAT PUMP III. Specifications GB/T 21362, GB 29541 Standards: Model TCAH100FC TCAH50FC Nominal heating capacity (kW) 38.5 18.6 Rated power input (kW) 8.75 4.24 COP (W/W) 4.40 4.39 Nominal water output (L/h) Rated water flow(m³/h) Water resistance（kPa） Power Supply 380V 3N~50Hz 380V 3N~50Hz... -
Page 6: Functions
The TICA air source heat pump water heater can achieve fast automatic defrosting through the unit control system. And the unit operation rate can reach more than 90%. -
Page 7: Variable Operating Condition Curve
CIRCULATING AIR SOURCE HEAT PUMP temperature decreases. In places where the ambient temperature in winter may be below 10°C, an auxiliary heat source that could provide certain heating capacity shall be equipped to improve the heating capacity of the system and ensure that the system can supply hot water properly and reliably. - Page 8 CIRCULATING AIR SOURCE HEAT PUMP 8.2 TCAH100FC variable operating condition curve...
-
Page 9: Installation Instructions
CIRCULATING AIR SOURCE HEAT PUMP V. Installation Instructions Notes:* Upon receiving the unit, check whether the unit model is correct, accessories complete and the appearances of the unit intact. If you find any damages or you have other problems, please immediately call your salesman. * Before installation, make sure that the unit power is consistent with its electricity meter capacity and power cords. - Page 10 CIRCULATING AIR SOURCE HEAT PUMP 1) Arrange in a vertical and side-by-side manner, as shown in Figure 5.1. Figure 5.1 Vertical and side-by-side arrangement 2) Arrange in a horizontal and side-by-side manner, as shown in Figure 5.2. Figure 5.2 Horizontal and side-by-side arrangement ...
-
Page 11: Unit Handling
CIRCULATING AIR SOURCE HEAT PUMP shall not be less than 13,000 m /h; for TCAH50FC, the air circulation volume shall not be less than 7000 m The height from the unit bottom to the ground or floor shall be greater than the local maximum snow depth and the possible water depth. -
Page 12: Pipeline Connection
Each system of TICA air source heat pump water heater can connect up to 16 heat pump units in parallel. Fig. 5.3 is suitable for timing water use. Firstly, the water temperature is heated to a set temperature, and then the water is recharged after use. -
Page 13: Pipeline Selection
CIRCULATING AIR SOURCE HEAT PUMP Figure 5.3 Air-source heat pump hot water system(for timing water use) Figure 5.4 Air-source heat pump hot water system(for unscheduled water use) 6. Pipeline selection When multiple units are connected in parallel, it is recommended to select the main water inlet pipe, main water outlet pipe diameters according to Table 5.1. -
Page 14: Water Line Insulation Requirement
CIRCULATING AIR SOURCE HEAT PUMP Table 5.1 Main water inlet & outlet pipe Number of Units in Main Water Inlet Pipe Main Water Outlet Pipe Parallel TCAH100FC TCAH50FC TCAH100FC TCAH50FC DN40 DN32 DN40 DN32 DN65 DN50 DN65 DN50 DN80 DN65 DN80 DN65 DN100... -
Page 15: Model Selection Of Water Pump
CIRCULATING AIR SOURCE HEAT PUMP Insulating layer thickness (mm) 8. Model selection of water pump There is the circulating pump for the unit, and the water pump model selection shall satisfy requirements in the following table. Table 5.5 Water pump model selection requirements for hot water system Types of Water Flow Pressure Drop at Water... -
Page 16: Installation Of Water Tank
CIRCULATING AIR SOURCE HEAT PUMP size of tank temperature sensor. Local view of domestic hot water inlet and tank temperature sensor connector Local view of blind pipe size of tank temperature sensor Domestic hot water feed inlet height Inside tank Outside tank Height of blind pipe of tank temperature sensor Height of heat pump circulating pipe... -
Page 17: Installation Of Water Level Switch
CIRCULATING AIR SOURCE HEAT PUMP The installation positions of water tank and unit are recommended as follows: Install as shown in Figure 5.10 (the hot water storage tank is installed at the same height as the heat pump unit). Hot water outlet pipe Hot water storage tank Circulating water... -
Page 18: Water Quality Requirements
CIRCULATING AIR SOURCE HEAT PUMP Notes: The water level switch can only be used to control the start and stop logic of unit and may not display the actual water level of the water tank. Avoid hitting the water level switch. When the product is dropped from a height of 1.2 m or a higher place, it may be damaged.The installation position of water level switch shall be close to the tank access port for the convenience of overhaul, and shall be away from the water inlet side of water tank to avoid shock from water entrance. -
Page 19: Electrical Connection
CIRCULATING AIR SOURCE HEAT PUMP 13. Electrical connection Notes: The water heater unit shall use the special power supply whose voltage complies with the rated voltage. The power supply circuit of the water heater unit must have a grounding wire, and the power supply ground wire must be reliably connected with the valid external earth wire. -
Page 20: Sequence Number Setting Of Heat Pump Unit
(3) Requirements for power control cabinet During the site installation of TICA air source heat pump water heater, a power control cabinet must be provided for the unit and all electric devices of the system. The power control cabinet needs to provide power supply for all heat pump units and circulating pumps in the system. - Page 21 CIRCULATING AIR SOURCE HEAT PUMP setting method is described as follows. It is recommended to paste salve unit ID markings on the unit after setting. Figure 5.9 DIP switch Model Bit for Electric The way Electric master/slave Unit Water Model heater TCAH Slave unit ID...
-
Page 22: Trial Operation
CIRCULATING AIR SOURCE HEAT PUMP available. Bit 6 indicates the installation mode of electric heater: "0" means that the electric heater is installed in the water tank; and "1" means that the electric heater is installed in the pipe. Bit 7-8 is for the way of charging water selection,00 indicates charging water depends on water level,01 indicates charging water timing,10 indicates charging water depends on setting temperature. -
Page 23: Operation And Application Of Wired Controller
This document is prepared to help users understand the operating procedures of the wired controller interface of TICA air source heat pump water heater. It includes the description of the changes in all user-defined settings, and some operating procedures of professional service personnel certified by TICA. -
Page 24: Overall Outline Drawing Of Wired Controller
CIRCULATING AIR SOURCE HEAT PUMP 2. Overall outline drawing of wired controller 3. Pattern display description... - Page 25 CIRCULATING AIR SOURCE HEAT PUMP Circulating mode icon; Defrosting mode icon; Anti-freezing mode Mode display area icon; Auxiliary heater mode icon; Fault prompt icon. Master & slave Displays master and slave units 1 to 16; Query icon ; unit No. Parameter setting icon.
-
Page 26: Button Operation Instructions
CIRCULATING AIR SOURCE HEAT PUMP 4. Button operation instructions Buttons ① & ② ① Up button; ② Down button: adjusts values up or down. Button ③ On/Off button: turns on/off the wired controller. Auxiliary Electric Heater Control button: turns on/off the auxiliary electric heater Button ④... -
Page 27: Wired Controller Operating Instructions
CIRCULATING AIR SOURCE HEAT PUMP Buttons ⑬ and ⑮ ⑬ Page Up button; ⑮ Page Down button: they can be used for page turning. Button ⑭ Timer button: sets timing and changes system time . 5. Wired controller operating instructions (1) Temperature settings: they can only be valid under default state (i.e. - Page 28 CIRCULATING AIR SOURCE HEAT PUMP Figure 6.1 LCD display image during parameter query Note: Comparison table of query parameters Display Notes Discharge temperature Tp temperature value Water tank temperature Tt temperature value Reserved Water outlet temperature To temperature value Ambient temperature Ta temperature value Return air temperature Th temperature value...
- Page 29 CIRCULATING AIR SOURCE HEAT PUMP state (i.e. non-query state and set state), press the "fault query" button to inquire faults (see detailed error codes in the error code list). Press the "Fault Query" If multiple slave units fail, After finishing the query, button to inquiry faults press the "Master &...
- Page 30 CIRCULATING AIR SOURCE HEAT PUMP 3. The timing function supports timed power-on (or timed power-off) separately. When you only want to set the timed power-on, set the hour and minute of the timed power-off to "--" and then confirm; when you only want to set the timed power-off, set the hour and minute of the timed power-on to "--"...
- Page 31 CIRCULATING AIR SOURCE HEAT PUMP Figure 6.4 LCD drawing of timing function enabling (6) Time setting: when the display time of wired controller deviates from the standard time, it can be reset when the wired controller is in the default state. Press and hold the "Timer"...
-
Page 32: Servicing And Maintenance
● For any abnormalities or alarms occurring during operation, note to call TICA's hotline or report them to your local service agency. And never attempt to repair them on your own. - Page 33 CIRCULATING AIR SOURCE HEAT PUMP Install the inlet and outlet pipes in the correct direction. On the water inlet pipes, water filters should be installed. In addition, these filters need to be cleaned periodically, lest water-side heat exchanger may be clogged, hence causing damages to the unit.
-
Page 34: Handling Of Common Faults
Do not use unqualified refrigerant, refrigerant substitute or refrigerant additive. Incorrect using method or using unqualified refrigerant, refrigerant substitute or refrigerant additive will lead to unit damage and various safety hazards. Please select qualified refrigerant or call TICA hotline to purchase qualified refrigerant. All the technicians operating refrigerant must have... - Page 35 CIRCULATING AIR SOURCE HEAT PUMP fault Water temperature senor fault in the water tank (only the master unit displays) Water outlet temperature sensor failure Direct-heating water inlet temperature sensor fault 1. Temperature sensor gets Circulating water inlet loose wires 1. Check its wiring and tighten them temperature sensor fault 2.
- Page 36 CIRCULATING AIR SOURCE HEAT PUMP prompt 2. The water level switch wring 2. Check the water level switch wiring gets loose and tighten it 3. The water level switch is wired 3. Check whether the water switch is wrongly wired as the wiring drawing 4.
- Page 37 CIRCULATING AIR SOURCE HEAT PUMP damaged The ambient 1. The ambient temperature is 1. Confirm whether the ambient temperature is too low lower than -10°C temperature is lower than -10°C and the heat pump is 2. The ambient temperature 2. Replace the damaged ambient limited to start up sensor of unit is damaged temperature sensor...
- Page 38 CIRCULATING AIR SOURCE HEAT PUMP 1. The water system is poorly insulated and the heat release is 1. Strengthen the system pipeline large. insulation. The unit heating 2. The heat release of the heat 2. Check whether the air inlet or outlet capacity is low exchanger at the air side is poor.
-
Page 39: Appendix
CIRCULATING AIR SOURCE HEAT PUMP IX. Appendix 1. Unit circuit diagram Electrical principle diagram of TCAH100FC Electrical principle diagram of TCAH50FC... -
Page 40: Wiring Diagram Of Single Unit
CIRCULATING AIR SOURCE HEAT PUMP 2. Wiring diagram of single unit Wiring diagram of single TCAH50FC/TCAH100FC unit 3. Wiring diagram of multiple parallel units Wiring diagram of multiple parallel units of TCAH50C/100FC Remarks: (1) The control output points for the auxiliary electric heater, circulating pump and booster pump in the figure can only be used as control signal ports;... - Page 41 CIRCULATING AIR SOURCE HEAT PUMP AC220V - 50Hz; (2) Users can only connect the passive switches to the control input points for the water level switch, remote switch and water pressure switch in the figure. (3) The unit comes with the communication line between the master unit and wired controller; the communication lines between the master unit and slave unit or between the master unit and slave unit need to be prepared by the users.
- Page 42 CIRCULATING AIR SOURCE HEAT PUMP TIСA PRO LLC 141014, Russia, Moscow oblast, Mytishchi, Very Voloshinoy Ulitsa, office 705 and 805 Tel.: +7(495)822-29-00 E-mail: info@tica.ru www.tica.ru...
