User Manual: Kangertech Subox Mini Kit
Charging the Battery
The Kanger Subox Mini requires one 18650 battery. Battery is not included. The Kanger Subox
Mini allows a battery to be charged internally through the USB charging port. Alternatively the
battery can be removed and charged in a charging dock rated for the 18650 battery.
Required Equipment
• One 18650 Battery (Not included)
• USB charging cable (Included)
To use the USB Charger, follow these instructions.
Figure 9. USB Charging
Refer to the image on Figure 9
• Plug the micro USB into the
charging port of the box mod.
• Plug the AC adapter into a wall
outlet.
• Unit will cease charging when the
battery is fully charged.
