Defender Storm Grip GK-188 Operation Manual

OPERATION MANUAL
Wireless Gaming Keyboard
ИНСТРУКЦИЯ ПОЛЬЗОВАТЕЛЯ
Беспроводная игровая клавиатура
Storm Grip GK-188
EN Wireless Gaming Keyboard
OPERATION MANUAL
1. Bluetooth mode connection.
Turn the left switch to "ON" position.
Supports connecting up to 2 devices via Bluetooth.
Please move the right switch to position BT1 for the first device or BT2 for
the second device.
Then press ESC and while continuing to hold it, press the key "Q" to
enter the pairing status.
After that find the name of keyboard "Storm Grip-1" in the list of
available devices for connection for the first device and "Storm Grip-2"
for the second device accordingly.
To reconnect to the device, follow all the steps above.
Bluetooth channel has version 5.1
2. Wireless 2.4Ghz connection.
Turn the left switch to "ON" position.
Then please move the right switch to "2.4G" position.
After that plug the USB 2.4Ghz connector into the computer USB interface
to complete the pairing.
The keyboard is connected via a 2.4Ghz channel.
For reconnection to the device, follow all the steps above.
3. Resetting the keyboard settings.
Press FN+Esc for 3 seconds to restore the factory connection settings.
Doesn't work for backlight settings.
4. Keys Combinations.
FN + F1~F12 = multimedia functions
FN+WIN = Lock Win
FN + ↓ = Brightness of the backlight -
FN + ↑ = Brightness of the backlight+
FN + ← = Speed of the backlight-
FN + → = Speed of the backlight+
FN + INS = Change the backlight mode
FN + TAB = Switch from Win to iOs mode
FN + Q= Enter byte speed adjustment
EN Wireless Gaming Keyboard
OPERATION MANUAL
Declaration of Conformity
Operation of device (devices) may be affected by strong static, electrical or high-frequency
fields (radio installations, mobile telephones, microwaves, electrostatic discharges)/ If
occurs, Try increasing the distance from the devices causing the interface.
Disposal of batteries, electrical and electronic equipment
This sign on the product, its batteries or package indicates that the product
cannot be disposed together with domestic waste. It should be delivered to an
appropriate batteries, electrical and electronic equipment collecting and
recycling company.
Terms and conditions of safe and efficient use of the product
Usage precautions:
1. Use the product for its intended purpose only.
2. Do not disassemble. This product does not contain parts that are entitled to self-
sufficient repair. On the question of maintenance and replacement of a failed item apply
to a dealer or Defender authorized service center. While receiving the product make sure
that it is unbroken and there are no freely moving objects inside the product.
3. Keep away from children under the age of 3. May contain small parts.
4. Keep away from humidity. Never immerse the product in liquids.
5. Keep away from vibrations and mechanical stresses, which can cause mechanical
damaging of the product. In case of mechanical damage, no warranties are provided.
6. Do not use in the presence of visual damage. Do not use when the product is obviously
defective.
7. Do not use the product at temperatures below and above recommended temperatures
(see the operation manual), under the conditions of humidity evaporation, as well as in
hostile environment.
8. Do not put into the mouth.
9. Do not use the product for industrial, medical or manufacturing purposes.
10. In case when shipment of the product was conducted in subzero temperatures, then
before operating, the product should be kept in a warm placement (+16-25°C or 60-77°F)
within 3 hours.
11. Turn off the device each time, when it is not planned to use it for extended period of
time.
12. Do not use the device while driving the vehicle, if it is diverted attention, and in other
cases when the law obliges you to turn off the device.
Product specifications and features can be found on the packaging and on defender-
global.com
Importer: Defender Technology OÜ, Betooni str 11, 11415, Tallinn, Estonia.
Manufacturer: Zodic Technology Co., Ltd. Address: Building 301, Lushi Industrial Building,
Zone 28, Dalang Community, Xin'an Street, Bao'an District, Shenzhen, China.
Unlimited shelf life. Service life is 2 years. Date of manufacture: see on the package
Manufacturer keeps the right to change package contents and specifications indicated in
this manual. The latest and detailed operation manual is available at www.defender-
global.com
Date of manufacture: see on the package. Made in China.
Warranty service is not effected in the following situations:
1. Expiration of the warranty period (warranty period is settled from the date of sale to the
end user).
2. Incorrect filling in of the warranty card.
3. Incorrect plug in to power grid.
4. Breach to safety of guarantee seals, fixing joint assemblies of the case; presence of
elements of opening on outside and inside parts of the product.
5. If the product designed for household use was used for professional purposes.
6. Damage due to penetration of foreign objects, substances, liquids or insects inside the
product.
7. Damage due to breach to normal work of supply network – 220V +/- 10%. (except of
automatic voltage regulators)
8. If the product was opened and repaired by a person unauthorized for that by the dealer.
9. Incorrect operation or careless handling.
10. Damage to the product due to natural disasters.
11. Presence of elements indicating mechanical damage (fall, hit).
12. Disability of connected devices of other producers.
