Defender DOOM ATTACK GK-215 Operation Manual

OPERATION MANUAL
Mechanical gaming keyboard
ИНСТРУКЦИЯ ПОЛЬЗОВАТЕЛЯ
Механическая игровая клавиатура
DOOM ATTACK GK-215
EN Mechanical gaming keyboard
OPERATION MANUAL
1. Wired mode connection.
Please plug in the cable to the keyboard with Type C connector and with PC
or Notebook with USB connector.
Then switch the bottom switch to "wired" mode.
2. Bluetooth mode connection.
Move the bottom switch to "BT " symbol first for wireless connection mode.
Supports connecting up to 3 devices via Bluetooth.
Press following keys combinations for 3 seconds into pairing status
FN+Z - for first device
FN+X - for second device
FN+C - for third device
Then find the name of keyboard "DoomAttack" in the list of available devices
for connection.
To reconnect to the device short press FN + Z/ X/ C for first / second and third
devices accordingly.
Bluetooth channel has versions 3.0 and 5.0.
3. Wireless 2.4Ghz connection.
Move the bottom switch to "BT " symbol first for wireless connection mode.
Then press FN+V for 3 seconds to enter pairing status via 2.4G mode.
After that plug the USB 2.4Ghz connector into the PC or Notebook USB
interface to complete the pairing.
The keyboard is connected via a 2.4Ghz channel.
For reconnect to the device short press FN+V.
4. Resetting the keyboard settings.
Press FN+Space 3 seconds bar to restore the factory settings.
5. Keys Combinations
FN+ESC = ` FN+U = Print Screen
FN+O = Pause FN+Home = Insert
FN+H = Play/Pause FN+L = Mute
FN+'" = Volume + FN+J = Previous
FN+N = Tab+WIN FN+M = Computer
FN+.> = Home FN+P = change the Windows/MacOS systems
FN + W = Switching WASD keys to arrows mode
FN+WIN_L = Lock Win
FN+↓ = Brightness of the backlight -
FN+↑ = Brightness of the backlight+
FN+← = Speed of the backlight-
FN+→ = Speed of the backlight+
FN+Shift_R = Change the backlight mode. 20 backlight modes.
Fn+[{ = Change the backlight direction
Fn+]} = Change the backlight color
Fn+/? = Turn off the backlight
Fn+BackSpace = Check the battery status: Press Fn+Back Space, the backlight
will be off, and keys 1 to 0 will light up to display the power ratio. The battery
level check function is only available in wireless mode connection.
Battery indicator
1. Low battery: space bar will flash red light
2. Charging: space bar will have steady red light for 30s
3. Fully charged: press FN+BackSpace in wireless mode to check if is fully
charged - all keys from 1 to 0 should light up.
EN Mechanical gaming keyboard
OPERATION MANUAL
Declaration of Conformity
Operation of device (devices) may be affected by strong static, electrical or high-frequency
fields (radio installations, mobile telephones, microwaves, electrostatic discharges)/ If
occurs, Try increasing the distance from the devices causing the interface.
Disposal of batteries, electrical and electronic equipment
This sign on the product, its batteries or package indicates that the product
cannot be disposed together with domestic waste. It should be delivered to an
appropriate batteries, electrical and electronic equipment collecting and
recycling company.
Terms and conditions of safe and efficient use of the product
Usage precautions:
1. Use the product for its intended purpose only.
2. Do not disassemble. This product does not contain parts that are entitled to self-
sufficient repair. On the question of maintenance and replacement of a failed item apply
to a dealer or Defender authorized service center. While receiving the product make sure
that it is unbroken and there are no freely moving objects inside the product.
3. Keep away from children under the age of 3. May contain small parts.
4. Keep away from humidity. Never immerse the product in liquids.
5. Keep away from vibrations and mechanical stresses, which can cause mechanical
damaging of the product. In case of mechanical damage, no warranties are provided.
6. Do not use in the presence of visual damage. Do not use when the product is obviously
defective.
7. Do not use the product at temperatures below and above recommended temperatures
(see the operation manual), under the conditions of humidity evaporation, as well as in
hostile environment.
8. Do not put into the mouth.
9. Do not use the product for industrial, medical or manufacturing purposes.
10. In case when shipment of the product was conducted in subzero temperatures, then
before operating, the product should be kept in a warm placement (+16-25°C or 60-77°F)
within 3 hours.
FN+I = Scroll Lock 11. Turn off the device each time, when it is not planned to use it for extended period of
time.
FN+Del = End
12. Do not use the device while driving the vehicle, if it is diverted attention, and in other
FN+;: = Volume -
cases when the law obliges you to turn off the device.
FN+K = Next
Product specifications and features can be found on the packaging and on defender-
FN+,< = Mail
global.com
Importer: Defender Technology OÜ, Betooni str 11, 11415, Tallinn, Estonia.
Manufacturer: Zodic Technology Co., Ltd. Address: Building 301, Lushi Industrial Building,
Zone 28, Dalang Community, Xin'an Street, Bao'an District, Shenzhen, China.
Unlimited shelf life. Service life is 2 years. Date of manufacture: see on the package
Manufacturer keeps the right to change package contents and specifications indicated in
this manual. The latest and detailed operation manual is available at www.defender-
global.com
Date of manufacture: see on the package. Made in China.
Warranty service is not effected in the following situations:
1. Expiration of the warranty period (warranty period is settled from the date of sale to the
end user).
2. Incorrect filling in of the warranty card.
3. Incorrect plug in to power grid.
4. Breach to safety of guarantee seals, fixing joint assemblies of the case; presence of
elements of opening on outside and inside parts of the product.
5. If the product designed for household use was used for professional purposes.
6. Damage due to penetration of foreign objects, substances, liquids or insects inside the
product.
7. Damage due to breach to normal work of supply network – 220V +/- 10%. (except of
automatic voltage regulators)
8. If the product was opened and repaired by a person unauthorized for that by the dealer.
9. Incorrect operation or careless handling.
10. Damage to the product due to natural disasters.
11. Presence of elements indicating mechanical damage (fall, hit).
12. Disability of connected devices of other producers.
