Summary of Contents for ALL-O-MATIC BLDC-PRO

  • Page 2 BLDC PRO SLIDER MANUAL Table of Contents SAFETY AND INTRODUCTION........................1 Important Safety Instructions ..............................2 UL 325 Class Types and Obstruction Sensing Systems ......................5 Operator Specifications ................................7 INSTALLATION ............................... 9 SL-45DC PRO Concrete Pad..............................10 SL-90DC PRO Concrete Pad..............................11 SL-100DC PRO Concrete Pad..............................
  • Page 3 BLDC PRO SLIDER MANUAL Safety and Introduction...
  • Page 4 BLDC PRO SLIDER MANUAL Important Safety Instructions WARNING TO REDUCE THE RISK OF INJURY READ AND FOLLOW ALL INSTALLATION INSTRUCTIONS. DO NOT START INSTALLATION UNTIL YOU HAVE READ AND UNDERSTAND THESE DIRECTIONS. IF THERE IS SOMETHING YOU DO NOT UNDERSTAND, PLEASE CALL US. NEVER let children operate or play with gate controls.
  • Page 5 BLDC PRO SLIDER MANUAL INSTALL THE GATE OPERATOR ONLY WHEN YOU HAVE READ THE FOLLOWING Before Gate Operator Installation 1. Confirm that the gate operator being installed is appropriate for the application. 2. Confirm that the gate is designed and built according to the current published industry standards.
  • Page 6 BLDC PRO SLIDER MANUAL Gate Operator Installation 1. Operator must be disconnected from the power source before attempting any installation of accessories. 2. Install gate operator according to the installation instructions in this manual. 3. Adjust the operator clutch or load sensing device to the minimum force setting that will allow for reliable gate operation.
  • Page 7 Each class must have two monitored entrapment protection devices in each entrapment zone to sense and react to obstructions within two seconds. All-O-Matic’s gate operators conform to the most rigid Class One. UL 325 Class Types 1. CLASS ONE: RESIDENTIAL A vehicular gate operator intended for use in garages or parking areas associated with a residence of one to four single families.
  • Page 8 BLDC PRO SLIDER MANUAL The Six Types of Obstruction Sensing Systems 1. TYPE A Inherent entrapment protection system. This system must sense and initiate the reverse of the gate within two seconds of contact with a solid object. 2. TYPE B1 Non-contact sensor (photoelectric sensor or equivalent).
  • Page 9 BLDC PRO SLIDER MANUAL Operator Specifications SL-45DC PRO SL-90DC PRO Maximum Gate Weight 800 pounds 1,600 pounds Maximum Gate Length 30 feet 50 feet Warranty 5 year residential 7 year residential 5 year commercial Motor 24 VDC brushless with planetary gearbox 24 VDC brushless 1/2 HP motor 12”...
  • Page 10 BLDC PRO SLIDER MANUAL SL-100DC PRO SL-150DC PRO Maximum Gate Weight 2,000 pounds 1/2 HP: 3,000 pounds 1 HP: 4,000 pounds Maximum Gate Length 50 feet 60 feet Warranty 7 year residential 7 year residential 5 year commercial 5 year commercial Motor 24 VDC brushless 1/2 HP motor 24 VDC brushless 1/2 and 1 HP motor...
  • Page 11 BLDC PRO SLIDER MANUAL Installation...
  • Page 12 BLDC PRO SLIDER MANUAL SL-45DC PRO Concrete Pad TOP VIEW FRONT VIEW...
  • Page 13 BLDC PRO SLIDER MANUAL SL-90DC PRO Concrete Pad TOP VIEW FRONT VIEW...
  • Page 14 BLDC PRO SLIDER MANUAL SL-100DC PRO Concrete Pad TOP VIEW FRONT VIEW...
  • Page 15 BLDC PRO SLIDER MANUAL SL-150DC PRO Concrete Pad TOP VIEW FRONT VIEW...
  • Page 16 BLDC PRO SLIDER MANUAL Front Mount Installation FRONT VIEW OVERHEAD VIEW...
  • Page 17 BLDC PRO SLIDER MANUAL SL-45DC PRO SL-90DC PRO SL-100DC PRO SL-150DC PRO...
  • Page 18 BLDC PRO SLIDER MANUAL Rear Mount Installation FRONT VIEW OVERHEAD VIEW CHAIN CONNECTION TO GATE...
  • Page 19 BLDC PRO SLIDER MANUAL AC Power Electrical Wiring OPERATORS MUST BE PROPERLY GROUNDED! 1. All gate operators MUST be properly grounded. This minimizes or prevents damage due to electrical charge, such as a near lightning strike or an electrical static discharge. 2.
  • Page 20 BLDC PRO SLIDER MANUAL NOTE: When applying 230V to the operator, make sure voltage switch is flipped to 230V. Power Connection 115VAC 50 / 60Hz 230VAC 50 / 60Hz Single Phase Line 1 115V HOT 230V Line 1 Line 2 115V NEUTRAL 230V Line 2 GROUND...
  • Page 21 BLDC PRO SLIDER MANUAL Wire Size Chart Use below table to select the correct power wire size for the power run. It is important to use the correct size wire, as it is crucial to avoid voltage drops. MAX WIRE FEET @ 120 VOLTS, 1 PHASE, 2% MAX VOLTAGE DROP Volt –...
  • Page 22 BLDC PRO SLIDER MANUAL Gate Opening Direction and Travel Adjustment Opening Direction Setting 1. Use OPEN L/R dipswitch (#8) to change the opening direction of the operator. 2. The direction of the gate opening is determined standing behind the gate operator.
  • Page 23 BLDC PRO SLIDER MANUAL Limit Travel Adjustment Locate the limit switches (limit switches will be in the limit box on SL-150DC PRO) and follow the steps below: 1. Turn the power OFF on the operator. 2. Push the limit lock plate down (on the SL-45 DC, SL-90 DC, and SL-100 DC) or outwards (on the SL-150 DC).
  • Page 24 BLDC PRO SLIDER MANUAL Board Features...
  • Page 25 BLDC PRO SLIDER MANUAL Dip-Switch Functions TIMER: TIMER switch “ON” activates the automatic close timer. See page 21 for details. RADIO: RADIO switch “ON” allows the radio override the automatic close timer. See page 21 for details. OSC: OSC switch “ON” allows the radio receiver to stop and reverse the gate in any direction.
  • Page 26 BLDC PRO SLIDER MANUAL Auto Close Time Setting and Radio Receiver Wiring Auto Close Timer Settings TIMER ON: Automatic timer to close can be set from 1 to 120 seconds (two minutes). TIMER OFF: Gate operation is “push button to open, push button to close.”...
  • Page 27 BLDC PRO SLIDER MANUAL Radio Receiver Wiring There are two types of receivers: three-wire and four-wire: Three-wire receivers can mount on the radio receiver terminal strip located outside of the control box. For four-wire receivers, connect the relay contact wires to terminals 1 (COMMON) and 2 (RELAY / RADIO) on the receiver terminal strip located outside of the control box (one wire on each terminal).
  • Page 28 BLDC PRO SLIDER MANUAL Electronic Reversing Device (ERD) Adjustment ALL-BLDC PRO boards are equipped with an Electronic Reversing Device (ERD), which will cause the gate to reverse direction when it comes in contact with an obstruction. The amount of force required to reverse the gate’s direction depends on the ERD force setting.
  • Page 29 BLDC PRO SLIDER MANUAL SL-150DC PRO Clutch Adjustment The SL-150DC PRO gearbox is equipped with an internal clutch to protect the operator when gate is reversed in mid-cycle. The clutch comes from the factory set at 60 pounds. of torque. In some applications, where the gates are heavier than normal, the clutch may require some adjustment to increase the amount of torque.
  • Page 30 BLDC PRO SLIDER MANUAL Primary / Secondary Connection Before linking primary / secondary communication, take the following steps: 1. Adjust the ERDs and limit switches (refer to ERD and limit switch adjustment pages for details) on each operator as stand-alone machines. 2.
  • Page 31 BLDC PRO SLIDER MANUAL Hard Wired Setup 1. To link the two units hard wired, press and hold the DOWN button. As DOWN button is pressed, press and release the RESET (do not release the DOWN button yet). LCD will display WIRED MODE.
  • Page 32 BLDC PRO SLIDER MANUAL Programmable Relay Entering LCD Display Menu To wake up the display, press OK button twice. The message shown on image will be displayed. Press < left button to start English menu. From there, you can press OK button while cursor is on SETTINGS option.
  • Page 33 BLDC PRO SLIDER MANUAL Delay Settings ALL-BLDC PRO control boards includes a delay option for open or close cycles. This delay option is most commonly used on swing gate applications. To activate this delay, navigate to the menu setting LEAF DELAY. To get there, go into English menu, go into SETTINGS, then scroll down to LEAF DELAY, press OK.
  • Page 34 BLDC PRO SLIDER MANUAL Accessory Installation...
  • Page 35 BLDC PRO SLIDER MANUAL Entrapment Protection Installation 1. A minimum of two monitored entrapment protection devices are REQUIRED for each entrapment zone. 2. An entrapment zone is a location or point of contact where a person can become entrapped between a moving gate and a rigid object. 3.
  • Page 36 BLDC PRO SLIDER MANUAL Monitored Entrapment Protection Device Wiring OVERHEAD VIEW Wiring Entrapment Device to DC Board...
  • Page 37 BLDC PRO SLIDER MANUAL ALL-BLDC PRO offers the 10K termination alternate option. Connect 10K sensor contacts to COMMON and MON-OPEN or MON-CLOSE as shown below. Additionally, AUX INPUT 1 and 2 can be used to wire additional entrapment protection devices (10K or N.C.
  • Page 38 BLDC PRO SLIDER MANUAL Third Party Monitored Entrapment Protection Device Connections 1. There are two types of sensors that can be connected to the gate operator for UL 325 monitored entrapment compliance: non-contact sensors (photo eye) and contact sensors (edge sensors). 2.
  • Page 39 BLDC PRO SLIDER MANUAL MON-CLOSE (LED will indicate when an obstruction is detected or device is not present.) This input is only for the monitored entrapment protection device for the close direction. When the gate is closing, it will open to the fully open position if an obstruction is sensed and resets the automatic close timer.
  • Page 40 BLDC PRO SLIDER MANUAL Alternate Monitored Entrapment Protection Device Wiring ENFORCER E-960-D90GQ / ENFORCER ALLEN BRADLEY E-931-S33RRGQ / E-931-S50RRGQ E-936-S45RRGQ GRU-24 Contact Board Terminal Wire Board Terminal Wire Boards Terminal N.C. MON_CLOSE OR BLACK MON_COSE OR BLACK MON_CLOSE OR MON_OPEN MON_OPEN MON_OPEN COMMON...
  • Page 41 BLDC PRO SLIDER MANUAL MILLER EDGE RBAND TRANSMITTER SOLUTIONS (6 WIRES FOR 1 EDGE / IGAZE RE KIT WEL-200 8 WIRES FOR 2 EDGES) BOARD BOARD BOARD SWITCH CONTACT TERMINAL CONTACT TERMINAL SWITCH CONTACT TERMINAL SW1 – ON ALL OFF N.C.1 MON_CLOSE RELAY...
  • Page 42 BLDC PRO SLIDER MANUAL Loop Layout 1. Below is a typical loop layout. When connecting to an All-O-Matic circuit board, use the following: SAFETY LOOP: Normally Closed (N.C.) contacts. EXIT LOOP: Normally Open (N.O.) contacts. (See next page for LPR-2 loop rack wiring.) 2.
  • Page 43 BLDC PRO SLIDER MANUAL Plug-In Detector Installation 1. The SL-90DC PRO, SL-100DC PRO and SL-150DC PRO models come equipped with the pre-wired LPR-2 loop rack for safety and exit plug in loop detectors, making installation quick and efficient. 2. Hardwired loop detectors with harnesses can also be installed. The circuit board has 12 VDC and 24 VDC terminals to power the detector of your choice.
  • Page 44 BLDC PRO SLIDER MANUAL Loop Rack DC Board Wire Color +12VDC COMMON BLACK EXIT LOOP EXIT LOOP GREEN PHAN PHAN LOOP BROWN SAFETY SAFETY LOOP WHITE IMPORTANT: Dip switch SW3 on PRIME-VD1 must be set when installing the detector in order for it to work properly. Use chart to set the output of the detector either FAIL-SECURE (N.O.) or FAIL-SAFE (N.C.).
  • Page 45 BLDC PRO SLIDER MANUAL Accessory Wiring The ALL-BLDC PRO controller has auxiliary +12VDC and +24VDC terminals that provide up to 750mAmps on +12VDC and 750mAmps on +24VDC to power accessories. If the total current draw of the accessories exceeds the rated current for any of the +12VDC or +24VDC terminals, a separate power supply (transformer) is required.
  • Page 46 BLDC PRO SLIDER MANUAL ALL-BLDC PRO controller has a built-in delay of 0.5 seconds. Some locks may require longer delay to fully release. See auxiliary relay and delay page for details on setting a leaf delay and give the lock more time to release.
  • Page 47 For a solar installation, upgrade the batteries according to usage. When the application requires more than 80 watts of solar power, an external charge controller regulator is necessary. See next page for external solar system. For information on solar applications (solar panel sizes, battery size, etc.), please call All-O-Matic.
  • Page 48 When using an external solar package, connect batteries straight into the BATTERY input. The batteries will need to be upgraded to meet application requirements. See wiring below. For information on solar applications (solar panel sizes, battery size, etc.), please call All-O-Matic. IMPORTANT:...
  • Page 49 BLDC PRO SLIDER MANUAL LED Diagnostics P/S LINK: ON when primary / secondary communication is active. RADIO: ON when the RADIO input is activated (closed circuit to common.) EXIT LOOP: ON when the EXIT input is activated (closed circuit to common.) PHANTOM LOOP: ON when the PHANTOM LOOP input is activated (closed circuit to common.)
  • Page 50 When calling ALL-O-MATIC for technical support, please have the name of the lights that are ON in the control board. This will speed up the process to get the gate...
  • Page 51 BLDC PRO SLIDER MANUAL Technical Tips Operator Symptom Solutions (Diagnose) Opening or Closing LEDs If AC PWR_LED is blinking, replace the fuse at bottom right corner of the board. After replacing the fuse and before a signal is given, inspect the gate and make sure it’s not bound are on, but gate does not up and that the limit switches are set correctly.
  • Page 52 BLDC PRO SLIDER MANUAL AUX INPUT 1 and 2 Programming AUX INPUT 1 and 2 can be programmed to do different functions. Below are the options. AUX INPUT 1 1. EMERGENCY OPEN (FACTORY DEFAULT) Devices connected to the input in this function will open the gate and will override MON_OPEN devices.
  • Page 53 BLDC PRO SLIDER MANUAL AUX INPUT 2 1. EMERGENCY CLOSE (FACTORY DEFAULT) Devices connected to the input in this function will close the gate and will override MON_CLOSE devices. Use N.O. contact. 2. PARTIAL OPEN (SET PARTIAL OPEN IN %) Devices connected to this input in this function will open the gate partially to set opening %.
  • Page 54 BLDC PRO SLIDER MANUAL...
  • Page 55 BLDC PRO SLIDER MANUAL LCD Settings and Diagnostics THESE INSTRUCTIONS WILL TAKE YOU THROUGH THE ALL-BLDC PRO BOARD LCD DISPLAY MENU. To wake up the display press the OK button a couple of times until you see the options for <ENG and ESP.>.
  • Page 56 BLDC PRO SLIDER MANUAL iii. The threshold is the most responsive (sensitive). b. ERD OPEN ERD (this can be accessed directly with quick access OPEN ERD button): • This is for adjusting Opening ERD force. CLOSE ERD (this can be accessed directly with quick access CLOSE ERD button): •...
  • Page 57 BLDC PRO SLIDER MANUAL 7. AUXILIARY RELAY Below are the options of relay activation: a. OFF (INACTIVE)* b. PRE-WARN SIGNAL This is similar to the PRE-WARN ALARM function. c. MOVING SIGNAL This function turns ON the auxiliary relay while the gate is moving. d.
  • Page 58 BLDC PRO SLIDER MANUAL 9. SERVICE CYCLE This will provide a planned service call based on run cycles. a. SERVICE CYCLE Program the number of cycles the gate needs to run before the next preventive maintenance service call; When programmed, the board will start the count down. When it gets to zero, it will start beeping to alert the end user it’s time to call for service;...
  • Page 59 BLDC PRO SLIDER MANUAL 13. WIRELESS SETUP When wireless PRIMARY / SECONDARY is used and there are other operators nearby using the same communication, it will be necessary for the different systems to have unique channels. This is where channels can be changed. There are eight channels to choose from. a.
  • Page 60 BLDC PRO SLIDER MANUAL 4. LAST EVENT This displays the last event that was recorded. a. 50. (LAST LOGGED EVENT NAME) b. XX/XX/XX 00:00PM (LAST EVENT TIME AND DATE) 5. EVENT LOG This provides the event log; it can store up to 50 special events. a.
  • Page 61 BLDC PRO SLIDER MANUAL Emergency Release Instructions...
  • Page 62 BLDC PRO SLIDER MANUAL Emergency Release for SL-45DC PRO Procedures to Manually Open the SL-45DC PRO 1. Remove operator cover. 2. Turn both AC and DC switches OFF. 3. Push gate open.
  • Page 63 BLDC PRO SLIDER MANUAL Emergency Release for SL-90DC PRO, SL-100DC PRO, and SL-150DC PRO Procedures to Manually Open the SL-90DC PRO, SL-100DC PRO, and SL-150DC PRO 1. Step on foot pedal and move to the side to latch pedal in down position 2.
  • Page 64 BLDC PRO SLIDER MANUAL Accessories and Parts Breakdown...
  • Page 65 BLDC PRO SLIDER MANUAL Padlock Tabs 1. Lock tabs are provided in the hardware bag for the SL-45 DC only. 2. Remove bolt and install lock tabs for cover to secure with a pad lock. 3. Lock kits are available for purchase for the SL-90 DC, SL-100 DC, SL-100FP DC, and SL-150 DC.
  • Page 66 BLDC PRO SLIDER MANUAL SL-45DC PRO Blowout Drawing...
  • Page 67 BLDC PRO SLIDER MANUAL SL-45DC PRO Blowout Drawing...
  • Page 68 BLDC PRO SLIDER MANUAL SL-90DC PRO Blowout Drawing...
  • Page 69 BLDC PRO SLIDER MANUAL SL-90DC PRO Blowout Drawing...
  • Page 70 BLDC PRO SLIDER MANUAL SL-100DC PRO Blowout Drawing...
  • Page 71 BLDC PRO SLIDER MANUAL SL-100DC PRO Blowout Drawing...
  • Page 72 BLDC PRO SLIDER MANUAL SL-150DC PRO Blowout Drawing...
  • Page 73 BLDC PRO SLIDER MANUAL SL-150DC PRO Blowout Drawing...
  • Page 74 BLDC SLIDER MANUAL Warranty and Customer Record...
  • Page 75 Labor charges for dealer service or replacement are the responsibility of the owner. These warranties are in lieu of all other warranties either expressed or implied, and ALL-O-MATIC INC shall not be liable for consequential damage. All implied warranties of merchantability and or fitness for a particular purpose are hereby disclaimed and excluded.
