HM20/HM15/HM10-H
Inverter User Manual
﹙V240814﹚
ESYsunhome CO.,LTD
Website: www.esysunhome.com
TEL: +86 (0)755 8522 9087
Email: info@esysunhome.com
ADD. : Building 6, No. 5-2, inner ring road,
Shanxia community, Pinghu street,
Longgang District, Shenzhen GD, China 518000
Made in China
ESYsunhome CO.,LTD
Advertisement
Table of Contents
Related Manuals for ESY Sunhome HM20
Summary of Contents for ESY Sunhome HM20
- Page 1 HM20/HM15/HM10-H Inverter User Manual ﹙V240814﹚ ESYsunhome CO.,LTD Website: www.esysunhome.com TEL: +86 (0)755 8522 9087 Email: info@esysunhome.com ADD. : Building 6, No. 5-2, inner ring road, Shanxia community, Pinghu street, Longgang District, Shenzhen GD, China 518000 Made in China ESYsunhome CO.,LTD...
-
Page 2: Table Of Contents
Contents 1 Company Overview 2 Precautions 2.1 General Statement 2.2 Safe Transportation and Storage 2.3 Important Safety Information 2.4 Installer Requirements 2.5 Safety Symbols Description 3 Product Introduction 3.1 Inverter Parameters 3.2 Dimensions 3.3 Inverter Port Descriptions 3.4 Distribution Box Port Descriptions 3.5 Battery Port Descriptions 3.6 System Model Overview 3.7 Application Scenarios... -
Page 3: Company Overview
Battery Management Systems (BMS). 5.1.4 Inverter Installation Trusted by global giants such as Huawei, Dell, and Toshiba, ESY SUNHOME is renowned for its innovative solutions. 5.1.5 Angle Iron Installation Supported by advanced AI functionalities, protection systems and a highly skilled R&D team, the company’s 5.1.6 Battery Tower Installation... -
Page 4: Precautions
Doing so may result in serious damage to the product and load. The content in this manual will undergo periodic review and updates as needed. ESY SUNHOME reserves the right to make improvements or changes to the products and procedures described in this manual at any time Danger! without prior notice. -
Page 5: Installer Requirements
450 Vd.c. MODEL: ESY SUNHOME HM15 HM15: Model, indicating that the inverter specification is 15 kW. Grid charging HM20: Model, indicating that the inverter specification is 20 kW. MODEL: ESY SUNHOME HM20 150 Vd.c. ~ 600 Vd.c. Battery voltage range Max.charging power... -
Page 6: Dimensions
3.2 Dimensions Backup load output rating Max. output current 14.4 Aa.c. @ 400 Va.c. 21.7 A a.c. @ 400 Va.c. 28.9 Aa.c. @ 400 Va.c. 22 mm THDV ≤ 3%（linear load） 660 mm 270 mm Overload capacity 105%, 60 s/120%, 30 s Switching time ≤... -
Page 7: Distribution Box Port Descriptions
3.4 Distribution Box Port Descriptions Schematic of the GP29Z Connector (10KWH+H Distributor Box) PACK- PACK- PACK+ PACK- PACK+ PACK+ CAN1-L CAN1-H CAN1-H DI3+ CAN1-L Schematic of the GP29T Connector (10KWH+H Distributor Box/10KWH+H Battery) PACK- PACK- PACK+ PACK+ Description of Distribution Box Wiring Ports Description Mark 485A... -
Page 8: Battery Port Descriptions
3.5 Battery Port Descriptions Schematic of the GP29T Connector (10KWH+H Distributor Box/10KWH+H Battery) PACK- PACK- PACK+ PACK+ 485A CAN-L 485B Activation- CAN-H Activation+ 485A 485B Activation- CAN-H Activation+ CAN1-H CAN1-H CAN-L CAN1-L CAN1-L Description of Battery Wiring Ports Description Purpose GP29Z ﹙10KWH+H Battery﹚... - Page 9 Overview of Different System Models: HM10-H-20 HM15-20 HM20-20 HM10-H-60 HM15-60 HM20-60 HM10-H-30 HM15-30 HM20-30 HM10-H-70 HM15-70 HM20-70 HM15-40 HM20-40 HM10-H-80 HM15-80 HM20-80 HM10-H-40 HM10-H-50 HM15-50 HM20-50 HM10-H-90 HM15-90 HM20-90...
-
Page 10: Application Scenarios
3.7 Application Scenarios 3.7.5 Micro Grid Storage System Micro Grid-Storage System (with PV inverter) 3.7.1 Used as A Photovoltaic (PV) Inverter PV 1 HM-20 PV 1 HM-20 inverter Electricity Meter Grid Electricity Meter Grid CT 1 PV 2 CT 1 PV 2 Emergency Loads Loads... -
Page 11: Preparation Before Installation
Connector 4.1.1 Packing List of Inverter Item Specifications Quantity Diagram Connector Removal Inverter HM20/HM15/HM10-H Used for Load/Generator/Grid port connector Tool Insulated Cord VP-D4B-CHSM4 external terminal casing, PV+ Connector End Terminal E4012, gray, used for load/generator port connector including metal terminal 4mm²... -
Page 12: Packing List Of Distribution Box & Base
Smart Dongle Waterproof Silicone, black, matte, WiFi IoT Max (Optional) Gasket 104.5x50.3x10.6 mm Smart electricity DTSD3366M-4-W1-A, Base 10KWH+H Battery Base Meter CT*6pcs, (Optional) 1-to-3*2pcs adapters CTs Components CT*3 with cable and RJ45 terminal Base Mounting Screws M4*10 mm (Optional) 4.1.3 Packing List of Battery Suitable for floor-mounted installation. -
Page 13: Packing List Of Cover
Inner diameter φ5 mm²; Expansion Screw Outer diameter φ12 mm², Bracket Base 660 mm×170 mm×45 mm Gaskets SUS304 gasket Bracket Screws M6×169, SUS304 4.1.4 Packing List of Cover Bracket Base M5*12, SUS304 Screws Suitable for multiple sets of battery energy storage system in parallel, and suitable for floor-mounted installation. Item Specifications Quantity... -
Page 14: Selection Of The Installation Environment
4.2 Selection of the Installation Environment ≤60℃ ≥60 ℃ ≤55℃ ≥ 55℃ ≥-20 ℃ ≤-20 ℃ ≥-20 ℃ ≤-20 ℃ ＞95% ＞95% ≤95% ≤95% Condensation Condensation The ambient temperature range is -25 ℃ to 60 ℃, when the inverter is installed without batteries, and -20 ℃～ To ensure proper heat dissipation, please install it in a For stability, the product should be installed on solid 55 ℃... -
Page 15: Selection Of Floor Mounting Location
4.3.2 Selection of Floor Mounting Location Applicable scenarios: When the inverter is used in the energy storage system. 50 mm Wall Thickness ≥50 mm 90° ＞90° ＜90° ＞90° 90° ＜90° For vertical installation, ensure there is no forward or backward tilting. The wall thickness should not be less than 50 mm. -
Page 16: Preparation Of Installation Tools
5 Installation 4.4 Preparation of Installation Tools 5.1 Floor-Mounted Installation 5.1.1 Base Installation Tools and accessories required for this step: Packing List of Battery Battery Packing List of 10KWH+H Battery Base, Waterproof Gasket (for Connector), Distribution Box Base Mounting Screws Tools Phillips Screwdriver PH1, Measuring Tape, Level Power Drill Open-end... -
Page 17: Batteries Installation
5.1.3 Distribution Box Installation Warning! Before completing the system installation, please check that the distribution box switch is in the "OFF" position. Note For uneven ground, please consider utilizing base foot accessories. 5.1.2 Batteries Installation Tools and accessories required for this step: Packing List of Battery Batteries, Waterproof Gasket (for Connector), Handlebar Screws Tools... -
Page 18: Inverter Installation
Handlebar Screws, Waterproof Gasket (for Connector) with screws, expansion screw Distribution Box gasket Packing List of Inverter HM10-H/HM15/HM20 Inverter Tools Open-end Wrench S=7 mm Waterproof Gasket Step 3: Drill the holes at the marked positions with Step 4: Thread the expansion tube screws through... - Page 19 Warning! For the battery towers without stacked inverter, the distribution box covers shall be installed. 300 mm~600 mm 10KWH+H Distribution box cover Step 3: Securely place the cover on the distribution Step 4: Remove the waterproof covers from the box, and tighten the handlebar screws on both sides “parallel +”...
-
Page 20: Wall-Mounted Installation
5.2 Wall-Mounted Installation Tools and accessories required for this step: Click Packing List of Inverter Inverter Packing List of Wall All Accessories Front Mounting Accessories Tools Power Drill φM6, Hammer, Phillips Screwdriver PH1, Marker Click Rear ⑨ ⑩ ⑦ ⑧ Step 7: Install the communication cable for parallel Step 8: Connect the parallel communication cables to connection of the distribution box as shown in the... - Page 21 Step 2: Drill the angle iron holes with the power drill, Step 3: Assemble the triangular brackets with bracket Step 6: Secure the rear panel to the heat sink of the Step 7: Place the inverter on the triangular bracket and hammer the expansion bolts into the holes.
-
Page 22: Wiring
6 Wiring 6.2 Load Connection Tools and accessories required for this step: 6.1 Grounding Connection Packing List of Inverter Load Output Terminal, Insulated Cord End Terminal 4 mm², Connector Removal Tool Tools Phillips Screwdriver PH1, Cable Cutting Pliers (wire cutter), Diagonal Pliers, Tools and accessories required for this step: Ferrule Crimping Pliers, Stripping Pliers Packing list of inverter... -
Page 23: Generator (Gen) Connection
6.3 Generator (GEN) Connection Tools and accessories required for this step: PV SWITCH Packing List of Inverter Generator Port Connector, Insulated Cord End Terminal 4 mm², Connector Removal Tool Tools Phillips Screwdriver PH1, Cable Cutting Pliers (wire cutter), Diagonal Pliers, PV1- PV1+ PV1-... -
Page 24: Pv Connection
PV SWITCH PV1- PV1+ PV1- PV1+ PV2- PV2+ Click GRID Click LOAD WIFI PARALLEL IN PARALLEL OUT CT/METER Step 1: Select an appropriate cable and use stripping Step 2: Use the connector removal tool to disassemble Step 4: Plug the connector head into the connector Step 5: Thread the connector through the slit of the pliers to remove the insulation. -
Page 25: Com Connection
Please confirm that all PV modules are of the same type and installation angle. Warning! Warning! Please select the correct COM port pin according to the actual installation scenario. Please verify that the input voltage and current range of the PV modules aligned with the parameter requirements of ESY SUNHOME. -
Page 26: Rj45 Port Connection
Tools and accessories required for this step: Packing List of Inverter COM Port Nylon Screw Plug, COM Port Connector, Insulated Cord End Terminal 0.75 mm². Tools Ferrule Crimping Pliers, Stripping Pliers, Cable Cutting Pliers (wire cutter) PV SWITCH Cable Multi-Strand Communication Cable, Core 0.5-0.75 mm², Cable Diameter 4-6 mm. PV1- PV1+ The CAT5e network cable is recommended. -
Page 27: Meter Connection (Optional)
6.8 Meter Connection (Optional) 10 mm Warning! When using the meter, ensure to use the CT and 1-to-3 adapter provided in the meter package. The CT components equipped with RJ45 terminals are not compatible with this meter. 6.8.1 Meter Port Descriptions Port No. -
Page 28: Ct Installation
PV inverter CT Grid CT 10 mm 5 (blue and white) 4 (blue) 5 (blue and white) 4 (blue) Step 3: Attach one end of the communication cable Step 4: Connect the #4 (blue) wire to Port B of the Step 6: Plug the CT terminals into the 1-to-3 adapter. -
Page 29: Drm Connection
6.11 Communication Dongle Connection (Optional) WiFi/Bluetooth Port Connector Pin Definitions PV SWITCH PV1- PV1+ Data Communication A PV1- PV1+ PV2- PV2+ Data Communication B 7 System Operation GRID 7.1 Power On LOAD Warning! WIFI PARALLEL IN PARALLEL OUT Please double-check that the installation to ensure it is correct and reliable before powering on. CT/METER Click Warning! -
Page 30: Power Off
7.2 Power Off When powering off, please adhere to the following steps: PV SWITCH PV1- PV1+ PV1- PV1+ PV2- PV2+ Generator GRID LOAD GRID Circuit Breaker WIFI PV Inverter Step 3: Turn on the PV switch on the inverter. Step 4: Switch the grid breaker to power on. BACKUP Circuit Breaker Step 1: Turn off the backup load. -
Page 31: Precautions
8 LED Display Description 8.1 Inverter LED Display Step 5: Turn off the DC Switch on the distribution box. Step 6: Double-click the button on the distribution box to shut down the battery. Warning! After shutdown, please wait for at least 5 minutes before performing any other maintenance operations on the all-in-one equipment. -
Page 32: Distribution Box Led Display
8.2.1 Status LED Display Descriptions When the indicator at the bottom of the light bar is OFF and the top three indicators are ON, it means that the equipment has an alarm or fault. If the equipment is faulty, please promptly seek assistance from professional LED Display Descriptions personnel to resolve the issue.
