Summary of Contents for GiBiDi DCF180
- Page 1 DCF180 - (AU02250) Synchronized photocells INSTRUCTIONS FOR INSTALLATIONS...
- Page 2 DCF180 180° FIG. 1 FIG. 2 12/24 NO/NC 0 Vac-dc 12/24 Vac-dc 12 Vac-dc 12/24 Vac-dc 24 Vac-dc FIG. 3 12Vac 24Vac...
-
Page 3: Technical Specifications
TECHNICAL SPECIFICATIONS Model/Item DCF180 / AU02250 Range 30 m (12 m, external) Signal Impulse signal, unmodulated Infrared frequency 2 Khz 1A 24V Relay power Receiver power 12/24 V DC/AC Absorption Transmitter / Receiver 35mA Operating temperature -20 ÷ +60 °C Thank you for choosing GI.BI.DI. -
Page 4: Installation
EN 301 489-1 V2.2.0; EN 301 489-3 V2.1.1; EN 300 220-2 V3.2.1; EN 62479:2010; EN 60950-1:2014; This declaration of conformity is issued under the sole responsibility of the manufacturer. Date: 03/04/17 The legal Representative Michele Prandi EU manufacturer declaration: The EU declaration is available at: http://conformity.gibidi.com... - Page 5 GI.BI.DI. S.r.l. Via Abetone Brennero, 177/B 46025 Poggio Rusco (MN) - ITALY Tel. +39.0386.52.20.11 Fax +39.0386.52.20.31 info@gibidi.com Numero Verde: 800.290156 w w w . g i b i d i . c o m...
