GiBiDi DCF180D Instructions For Installations

Digital photocells

Download this manual

DCF

DCF180D - (AU02010)

Digital photocells

INSTRUCTIONS FOR INSTALLATIONS

Need help?

Do you have a question about the DCF180D and is the answer not in the manual?

Page 1 DCF180D - (AU02010) Digital photocells INSTRUCTIONS FOR INSTALLATIONS...
Page 2 DCF180D 180° FIG. 1 12/24 NO/NC TEST NOT USED 12/24 Vac-dc DIP4 OFF 12/24 Vac-dc 1 2 3 4 1 2 3 4 1 2 3 4 1 2 3 4 L1 SIGNAL QUALITY pause pause pause pause pause pause...
Page 3 FIG. 2 Potenza segnale DIP4 OFF Power signal 12/24 Vac-dc 1 2 3 4 1 2 3 4 12/24 Vac-dc SYNC FIG. 3...
Page 4: Technical Specifications
TECHNICAL SPECIFICATIONS Model/Item DCF180D / AU02010 Range 30 m (12 m, external) Signal Impulse signal, unmodulated Infrared frequency 100 Hz - 1 Khz Relay power 1A 24V Power supply 12/24 V DC/AC Absorption TX / RX 35mA÷ 40mA Operating temperature -20 ÷...
Page 5: Installation
FUNCTIONING The DCF180D photocell can be installed in groups, without interference between the photocells. Each transmitter and receiver has a 4-way dip switch which assigns a different number to each pair of photocells. (see Table)
Page 6 EN 301 489-1 V2.2.0; EN 301 489-3 V2.1.1; EN 300 220-2 V3.2.1; EN 62479:2010; EN 60950-1:2014; This declaration of conformity is issued under the sole responsibility of the manufacturer. Date: 03/04/20 The legal Representative Michele Prandi EU manufacturer declaration: The EU declaration is available at: http://conformity.gibidi.com...
Page 7 GI.BI.DI. S.r.l. Via Abetone Brennero, 177/B 46025 Poggio Rusco (MN) - ITALY Tel. +39.0386.52.20.11 Fax +39.0386.52.20.31 E-mail: info@gibidi.com Numero Verde: 800.290156...
