- Page 1 MANUAL...
-
Page 2: Table Of Contents
Table of contents 1. Introduction…….………………………………………………………………………………………………………………………………………………….……………………………. 4 2. Signs and symbols …………………………………………………………………………………………………………………………………………………………………………….. 5 3. Safety…….…………………………………………………………………………………………………………………………………………………………………………………………. 6 3.1 Intended use ……………………………………..…………………………………………………………………………………………………………………………………………. 6 3.2 General information …………………………………………………………………………………………………………………………………………………………………….. 6 3.3 Danger and protection …………………….…………………………………………………………………………………………………………………………………………… 7 4. Technical data ………..……………………………………………………………………………………………………………………………………………………………………….. 8 4.1 General data …………..……………………………………………………………………………………………………………………………………………………………………. 8 4.2 Output ………………………………………………………………………………………………………………………………………………………………………………………….. -
Page 3: Introduction
1. Introduction Thank you for buying an SAMA power supply. You chose a high-quality and high-efficient power supply which is made from selected components and subjected to a strict quality management system. This ensures best performance and reliability. The power supply has a high efficiency which respects the environmental and lowers the cost of power. This is documented by the 80+ Platinum certification of the independent web site PlugLoadSolutions made by CLEAResult, the biggest North American provider of energy efficiency programs and services. -
Page 4: Signs And Symbols
2. Signs and symbols Symbols Meaning Handling and effects of safety instructions. Allusion to dangerous situation which can cause injury or death if not prohibited. Allusion to dangerous situation which can cause fire. Allusion to property damages and general information. Manual SAMA XP-Series Page 5... -
Page 5: Safety
3. Safety Intended use This device is made only for indoor use and for mounting in computer cases. Don´t use and store the device inside humid rooms or near water. Don´t use it close to source of heat. The additional heat could lead to overheating and fire. General information Please read this manual carefully before installing or using this product. -
Page 6: Danger And Protection
Danger and protection Don´t stick any items into the power supply (electric strike). Don´t pull the plug by pulling at the cable. Don´t use any patched or damaged cable or plug. Don´t place the device close to source of heat. In case of strange noise or smell pull the power cord out of the socket. -
Page 7: Technical Data
4. Technical data General data Standard Intel ATX 12V 3.0 Input voltage 100 – 240 V~ AC, 50-60Hz Input current XPH850A 115V – 10A / 230V – 8A XPH1000A 115V – 15A / 230V – 8A XPH1200A 115V – 15A / 230V – 8A Active Power factor >... -
Page 8: Output
Output Max. Total 3,3V Combined -12V 5Vsb 3,3V + 5V XPH850A 850W 100W 70.8A 0.4A XPH1000A 1000W 100W 83.3A 0.4A XPH1200A 1200W 100W 100A 0.4A Safety OPP Over-Power-Protection Power supply will shut down if the output is more than 130% of the nominal output. -
Page 9: Efficiency
Efficiency 230V~ Load 100% XPH850A 850W 92,70 % 93,60 % 91,90 % XPH1000A 1000W 92,70 % 93,70 % 92,20 % XPH1200A 1200W 92,90 % 93,90 % 92,00 % Efficiency 115V~ Load 100% XPH850A 850W 88,72% 91,66 % 93,22 % 92,04 % XPH1000A 1000W 89,21 %... -
Page 10: Connectors
5. Connectors All connectors are standardized and made against reverse connection. In case of difficulties during connection, please make sure to use the right connector or rotate the connector by 180°. Don´t try to insert a connector forcibly. Quantity EPS/ P4 SATA 12HPWR PCIe... -
Page 11: Pin Configuration
Pin configuration 5.2.1 P1 ATX-Mainboard connector 20+4 pin Pins 11/ 12/ 23/ 24 are made as separate jacks. Signal Signal +3,3V +3,3V DC It can be swung away in case of using older +3,3V -12V DC Mainboards. +5V DC PS_ON Don´t mix the separate jack with the P4 +5V DC connector. - Page 12 5.2.3 IDE connector 4 pin Signal +12V DC +5V DC 5.2.4 FDD connector 4 pin Signal Signal +5V DC +12V DC +12V DC +12V DC +12V DC +12V DC 5.2.5 PCI-Express connector 6+2 pin Some graphic adapter need only a 6pin plug for connection.
- Page 13 5.2.6 SATA connector 15 pin Signal Pin # +3.3VDC +3.3VDC +3.3VDC Masse Masse Masse +5VDC +5VDC +5VDC Masse Masse Masse +12VDC +12VDC +12VDC 5.2.7 12VHPWR connector 12+4 pin Signal Signal Signal CARD_PWR_Stable +12V CARD_CBL_PRES# +12V SENSE0 +12V +12V +12V +12V Please note: This connector is made up to 600W output only! To avoid possible fire make sure that the jack is completely pluged into the socket.
-
Page 14: Assembling And Initial Operation
6. Assembling and initial operation Take out the power supply and check the package content for completeness or damages. Please contact your local dealer for replacement in case of missing or damaged parts. Please keep the original package for shipping in case of warranty claim. Please connect the power supply to the grid after connecting all other devices. -
Page 15: Fan Control
Switch on the power supply at the backside of the power supply. Your computer is ready now When power-on the power supply it is in a Stand-By mode to start the computer by pressing the power button at the case front. To separate the computer totally from the electric grid power –off the power supply directly. -
Page 16: Maintenance
Error Possible reason(s) Help Check if power cord is connected to power supply and Power cord is not connected electric grid. Change power cord against an approved new power Power cord defective cord. Power socket defective Let authorized experts check the socket. Please unplug power cord generally when working inside the computer case. -
Page 17: Disposal
You can remove this dust with compressed air by yourself. To do this, unplug the power supply from mains supply, dismount the power supply in reversed way as described before and blow the dust with compressed air through the fan grid out of the housing. Do not use a wet or moist rag to remove dust. -
Page 18: Warranty Terms
11. Warranty terms In spite of best efforts and quality controls a device can have a fault. But because the SAMA XP-series is made by highest quality standard we extend the legal warranty terms to totally 3 years up from purchase date at proper use. - Page 19 In case of data loss Inter-Tech will only be liable at wanton negligence or deliberate intention or, in all other cases, only for the recovery of data from a continuous, daily backup. Inter-Tech does not assume liability for all other matters.
- Page 20 Inter-Tech Elektronik Handels GmbH - Hainhäuser Weg 93 - D-30855 Langenhagen - vertrieb@inter-tech.de...
