- Page 1 Manual FlexATX 250W FA-250 82+...
-
Page 2: Table Of Contents
Important information ........................3 Introduction ..........................3 Scope of delivery ........................3 General information ........................ 3 Safety ..............................4 Intended use ........................... 4 2.1.1 Environment ......................4 2.1.2 Disposal ........................4 General instructions ....................... 4 Danger and protection ......................4 Technical data ........................... -
Page 3: Important Information
Important Informationen Introduction Thank you for buying an Argus Power Supply. This power supply is equipped with latest technology and supports all modern processors. Argus power supplies meets RoHS II as well as the EU directive 2009/125/EC. To join this power supply for a long time we recommend to read this manual carefully and espacially paying attention for the security advices. -
Page 4: Safety
Safety Intended use 2.1.1 Environment This product is only for indoor use and mounting in computer cases. Don´t use and store it inside humid rooms or near water. Don´t use it close to source of heat. The additional heat could lead to overheating and fire. -
Page 5: Technical Data
Leave service or cleaning only authorized qualified personnel. Technical data Efficiency This power supply has an efficiency of at least 82% at 20%, 50% and 100% load. Input 3.2.1 Input voltage Input: 100-240V, 50/60Hz 3.2.2 Power Factor Active PFC > 0,95 at 100% load Output 3.3.1 Performance... -
Page 6: Quantity Of Secondary Connectors
Voltage Min. Norm. Max. 5,5 V 6,3 V 7,0 V 3,3V 3,76V 4,1V 4,5V +12V 13,4 V 15.0 V 16,0 V OCP – Over Current Protection The power supply shuts down when more than 120-160% total load. SCP – Short Circuit Protection The power supply shuts down at short circuit in +3,3V, +5V, +12V, -12V rail. -
Page 7: Secondary Connectors
Secondary connectors All connectors are standardized and made against reverse connection. In case of difficulties during connection, please make sure to use the right connector or rotate the connector by 180°. P1 ATX-Mainboard connector 20+4-pin Signal Signal +3,3V +3,3V DC +3,3V -12V DC +5V DC... -
Page 8: Sata Connector 15-Pin
SATA connector 15-pin Signal Pin # +3.3VDC +3.3VDC +3.3VDC Masse Masse Masse +5VDC +5VDC +5VDC Masse Masse Masse +12VDC +12VDC +12VDC Mounting and first use Take out the power supply and check the package content for completeness or damages. In case of missing parts or external damages, please contact your local dealer for replacement. -
Page 9: Faq
Fehlersuche Error Possible reason Help The power supply runs shortly Short circuit on Mainboard, Check all connectors for right and stops. HDD, FDD or CD-ROM connection Eliminate short circuit or change components Power supply won´t start Secondary connectors not Check all connectors for right connected connection Main-Switch on power supply is... -
Page 10: Disposal
In case of data loss Inter-Tech will only be liable at wanton negligence or deliberate intention or, in all other cases, only for the recovery of data from a continous, daily backup. Inter-Tech does not assume liability for all other matters. - Page 11 Manual FlexATX FA-250 82+ 11 of 12 05.04.2017...
- Page 12 www.inter-tech.de...
