LG S80QR (SPQ8-S) Manual

Installing and Using the Product

Please read this manual carefully before operating your set and retain it for future reference.

Replacement of Battery

1. Sound bar
2. Remote Control Receiver / Status Display
3. Rear Speakers / Wireless Receiver
4. Wireless Subwoofer - Install it close to the sound bar.

5. External Device - (Blu-ray player, game console, etc.)
6. Attaching the ferrite core (optional)

• Wind the wireless receiver' s speaker cables twice around the ferrite core.

1. Connect the sound bar to your TV via an optical cable or an HDMI cable.
2. If you are using an external device (ex. Blu-ray player, game console, etc.), connect it to the sound bar via an HDMI cable.
3. Connect to power in the following order: wireless subwoofer wireless receiver sound bar. Then, turn on the sound bar. When the connection is automatically established with the sound bar, the LEDs on the wireless subwoofer and the wireless receiver will light up in green.
4. Using the product with your TV
   1. Press theFunction button repeatedly until "OPT/HDMI ARC" appears on the status display.
   2. On your TV's settings, set the output speaker to [HDMI ARC], [Optical], or [External Speaker].
   3. When the TV is properly connected to the product, "OPT", "ARC", or "E-ARC" will appear on the status display with a sound.
      You can enjoy the sound by connecting LG WOWCAST (Sold separately, WTP3) to the sound bar wirelessly.
   4. When the product is connected to your smartphone viaBluetooth, you can see the status display change from "PAIRED" "Connected Bluetooth device name" "BT".
5. Connecting the product to your smartphone via Wi-Fi
   1. Connect your smartphone to Wi-Fi.
   2. Install the LG Sound Bar app on Google Play or the App Store.
   3. Run the LG Sound Bar app and follow the instructions.
   4. The product will connect to your smartphone and you can control the product with LG Sound Bar app.
6. Connecting the product to your smartphone via Bluetooth
   1. Tap theSettings button on your smartphone and select Bluetooth. Turn on the Bluetooth function. ( Off > On)
   2. Press theBluetooth pair button. After a moment, you will see "BT READY" on the status display.
   3. Find and tap "LG_Speaker_S80QR_XXXX" or the name you registered on the Google Home app.

If you see a red LED on the back of the wireless subwoofer or on the front of the wireless receiver, it means that the sound bar is not connected to the speakers. If this is the case, connect them in the following order.

1. Press the Power button on the sound bar to turn it off.
2. Press the PAIRING button on the back of the disconnected wireless subwoofer or wireless receiver. Check if each LED blinks green.
   • If you still see a red LED on the back of the wireless subwoofer, press and hold the button on the back of the subwoofer again.
3. Press the Power button on the sound bar to turn it on.
4. When the connection is established, you will see a green LED light on the back of the wireless subwoofer or on the front of the wireless receiver light up in green.
   Keep the sound bar, the subwoofer and wireless receiver away from the device (ex. wireless router, microwave oven, etc.) over 1 m (3.3 ft) to prevent wireless interference.
   • Some speakers may not make sound depend on the input source. Select CINEMA sound mode to listen through all speakers.

Specification

Power requirements

• Refer to the main label.

Power consumption

• Refer to the main label.

Sound bar dimensions (W x H x D): Approx. 1000.0 mm x 63.0 mm x 135.0 mm (39.4 inch x 2.5 inch x 5.3 inch) Wireless receiver dimensions (W x H x D): Approx. 175.0 mm x 61.0 mm x 175.0 mm (6.9 inch x 2.4 inch x 6.9 inch) Bus Power Supply (USB): 5 V 500 mA

Open Source Software Notice Information
To obtain the source code that is contained in this product, under GPL, LGPL, MPL, and other open source licenses that have the obligation to disclose source code, and to access all referred license terms, copyright notices and other relevant documents, please visit https://opensource.lge.com.
LG Electronics will also provide open source code to you on CD-ROM for a charge covering the cost of performing such distribution (such as the cost of media, shipping, and handling) upon email request to opensource@lge.com.
This offer is valid to anyone in receipt of this information for a period of three years after our last shipment of this product.
