Getting Started
Helpline
We hope these instructions help you to enjoy your new buggy.
If at any time you are unsure about the safe use of this product please call our helpline before using it on 01234 344 230
Note for Nipper Double owners
Please be aware that many of the images in this manual show the Nipper Single, however the instructions are the same and apply to both models, unless otherwise specified.
Useful Information
Like us on Facebook to keep up to date with all the latest news and offers.
facebook.com/outnaboutuk
twitter.com/outnaboutuk
instagram.com/outnabout_official
Inside the box
Instructions
Frame Assembly
Lift the auto lock catch with one hand and pull on the front end with the other hand.
The stroller will fold into the upright position. Make sure the plastic catches are out all the way (45 °) to ensure the buggy can unfold properly.
Lock both plastic catches onto the lower frame.
Fitting the wheels
Remove the axle rod protector.
Grasp rear wheel in one hand. Slide wheel axle into frame until it clicks into place. Check that the wheel is properly inserted by pulling it firmly. The wheel should not pull out if fitted correctly.
Repeat this for the other rear wheel.
With stroller upright on it's rear wheels tip it back so that the handlebar is down on the ground. (Take care not to damage the handlebar foam).
Attach the front wheel by loosening the quick release lever far enough to allow the axle to slide into the front forks. Then hand tighten the cone nut until almost tight, flip the quick release lever backwards into the closed position - which locks the wheel in place. Pull on the wheel to make sure it is firmly locked in the forks.
Locking Front Wheel
The front wheel can be locked into a fixed position or allowed to swivel.
To fix the wheel - turn the knob under the footplate until it engages into the slot.
To allow the wheel to swivel - pull out the knob and turn through 90° so that the pin is resting on the boss.
Apply the brakes
The red brake foot-pedal is located in the centre of the rear axel.
To engage brake, step down lightly on the red paddle of the foot-brake that is nearest to you.
To release brakes place your foot on the whole of the red foot-brake and push the furthest paddle down.
Never leave the buggy without first applying the breakes.
Fitting the seat liner
Unfasten all of the harness connectors and clips. Slide off the shoulder harness pads.
The horizontal strap on backrest can be used to alter the height of the shoulder straps. For younger children the harness should be fed under this strap as shown.
Place padded seat liner on the seat area. Feed the individual harness straps through the corresponding slits in the pad and slide harness pads back on.
There are two sets of Velcro strips on the pad and buggy, this ensures the pad will be held securely in place.
Place child in seat and ensure crotch strap is between the child's legs.
Proper Use of Harness
- Place child in seat and make sure crotch strap is between the child's legs.
- Place shoulder straps over child's shoulders.
- Engage the clips into central buckle on the crotch strap. Adjust the harness as necessary to ensure a good fit.
Avoid serious injury from falling or sliding out. Always use the crotch strap in combination with the waist belt and make sure it is properly adjusted.
Sun canopy
The sun canopy can be adjusted by simply pulling it into the desired position.
The extra sun visor is located under the rim of the hood, and can be pulled out when required. The visor has a cover that can be unzipped and rolled up to reveal the mesh ventilation panel
The canopy has a peek-a-boo window to make it easy to check on your little one. To keep the window open, roll the hood curtain and secure with the elastic loop and toggle.
Adjustable Handle
Press the locking buttons on the inside of the handle hinge with your thumbs and rotate the handle to find a comfortable height.
Reclining seat
The recline position of the seat(s) on your stroller can be adjusted using the strap on back of seat unit. To recline the seat squeeze the clasp and pull it down the straps.
To adjust the recline position simply change the length of the strap using the clasp.
When using the buggy in the reclined position, always adjust crotch and shoulder straps on the harness to ensure a good fit.
Bumper Bar
The bumper bar.
The bumper bar fits to the buggy housing on the chassis as shown above. Insert the metal prong on the bumper bar into the chassis.
Repeat for the other side. Pull on the bumper bar to ensure that it has locked securely.
To remove the bumper bar, slide the release button up and pull the bumper bar out of the housing. Repeat the process for the other side.
Back ventilation cover
The rear panel of the buggy has a ventilated window which can be easily covered when required.
To cover the meshed window firstly pull out the cover fabric from the pocket located above the mesh.
Then pull down the zips either side of the fabric and join the velcro strips along the bottom to create an all round seal.
Folding the stroller
Push buggy forward to align front wheel into the forward position as shown above.
Apply the brake before starting to fold.
To unlock the latches from the frame, pull down and outwards on the release pins.
Make sure to pull the latches out all the way to ensure the buggy can fold properly.
Always remove child from stroller before folding. Children should be kept clear of moving parts whilst folding or unfolding your stroller.
Take hold of the handle located at the back of the seat and pull upwards.
For Nipper double take hold of both the handles located at the back of the seats and pull upwards together. The buggy will automatically begin to fold.
As the frame folds, turn the front wheel sideways so it allows the buggy to be folded further. Lower the buggy to lay down on the floor.
The catch will automatically engage to secure the buggy in a folded position.
Check catch is engaged before lifting or carrying pram/stroller'.
For easy transportation the fold handle can be used to pull the buggy along in the folded position.
To release the rear wheels lift the red axle release button and pull the wheel free from the frame. Repeat for the other rear wheel.
The front wheel can be released by loosening the wheels quick release lever far enough to allow the axle to slide off the front forks.
Care & Maintenance
- Periodically check the stroller to ensure that it is in good operating condition.
- Check all fixings to make sure they are secure.
- Check the condition of the wheels and oil with a silicone spray if necessary.
- Do not use the stroller if any screws, nuts, bolts are missing or if any component is damaged.
To clean seat and canopy:
If light cleaning is required, use a soft cloth with warm water and mild soap then air dry. Do not put in the washing machine. Do not put in the dryer. DO NOT BLEACH.
To clean frame
Wipe using a soft cloth with warm water and mild soap. Air dry. DO NOT USE polish, abrasives or corrosive products. Lubricate moving parts with a silicone spray if necessary.
Tyre
Make regular checks of the tyre pressure. Do not over inflate tyres – 25 PSI will provide a comfortable ride for your child.
Accessories
available for your buggy
Foot Muff
Polar fleece lining with a shower-proof front. The front panel can be removed to leave a comfy seat liner. Snug and practical. Available in fabric colours to match all Out'n'About pushchairs.
Carrycot
The carrycot connects easily to the frame with a click. Includes a quilted lining, mattress and apron to give your newborn a comfy cosy ride. Sizes available to fit Nipper Single and Nipper Double in a choice of colours to match your Out'n'About pushchair.
Changing Bag
Co-ordinates with your pushchair and offers all the practicality needed when out with your baby. Bag attaches neatly to your buggy using the handy popper fasteners. Easy access compartments help keep baby's travel essentials organised. Includes a changing mat conveniently stored in the front pocket.
Storage Basket
Easy to pop on and off your buggy when extra storage is needed. Available in sizes to match your buggy
Rain Cover
Available in sizes to match your buggy
UV Cover
Available in sizes to match your buggy
Newborn Support
Used in conjunction with the low-lie position of the reclining seat this gives extra support to babies in the first couple of months. Available in colours to match your buggy.
Mini Tyre Pump
Attaches easily to all Out'n'About pushchairs. Ensures you'll never be out of air in the middle of nowhere. Comes complete with fixing kit.
Custom Buggy Bag
Available for both single and double models, this bag will make your buggy extremely easy to handle and keep it safe when travelling as well as ensuring your car boot stays mud free. Out 'n' About buggy bags are custom made for a perfect fit, complete with hand and shoulder straps.
Tyre Sealant
Inner tube puncture repair sealant. Available in tube or bandage strip form.
Universal Travel System Adapters
Suitable for use with all single Outnabout pushchairs. The adapter is compatible with a range of carseats including Maxi Cosi, BeSafe & Cybex. Please check model compatibility with your retailer.
For car seats used in conjunction with a chassis, this vehicle does not replace a cot or a bed. Should your child need to sleep, then it should be replaced in a suitable pram body, cot or bed.
EVA Wheels
The EVA wheel is a lightweight and durable alternative when using your Nipper pushchair around town. Low maintenance wheels, ideal for the city parent. Simple to fit, with the quick release function as standard.
SAFETY NOTES
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE. Your child's safety may be affected if you do not follow these instructions.
A child's safety is your responsibility.
Follow the manufacturer's instructions. Failure to follow these warnings and assembly instructions could result in serious injury or death.
General Safety
- To avoid injury or death, always apply the brakes whenever the pram/ stroller is stationary/parked.
- Always engage brakes when you stop or when you let go of the handle.
- Never leave the child unattended.
- Ensure that all the locking devices are engaged before use.
- To avoid injury ensure that the child is kept away when unfolding and folding this product.
- Always use the restraint system (Secure the child in the harness at all times).
- Check that the pram body or seat unit or car seat attachment devices are correctly engaged before use.
- Please use the most reclined position for new born babies.
- The parking device shall be engaged when placing and removing the children.
- Advice that care be taken if the pram/stroller is used on stairs or escalators.
- Children should be supervised at all times whilst using this stroller.
- Secure the child in the harness at all times.
- Always check that the stroller is correctly assembled and that all locking devices are engaged before use.
- Do not carry extra children or bags on this stroller.
- Make sure children are clear of any moving parts if you adjust the pram/stroller, otherwise they may be injured.
- Immediately discard any plastic wrapping. Keep away from children to avoid suffocation.
- Never allow children to fold, assemble or disassemble the stroller.
- Never place child in stroller on their back with their head forward and feet rearward.
- Avoid serious injury from falling or sliding out. Always use seat belt.
- Never use stroller if it becomes damaged.
- Do not use accessories other than those approved by the manufacturer or distributor.
- Always use wrist strap.
- Accessories or parcels placed in or on the stroller may cause it to become unstable. Any load attached to the handle affects the stability of the pushchair.
- Child may slip into leg openings and strangle. Never use in a reclined carriage position unless T-shield and shoulder strap placement has been readjusted to the seat's new position.
- Overloading, incorrect folding and the use of non–approved accessories may damage or break this vehicle.
- Check that the seat unit attachment devices are correctly engaged before use.
Intended use
- This pushchair must only be used for the number of children for which it has been designed. Single is for one child, double is for two children.
- Do not let the child play with this product.
- This product is not suitable for running or skating.
- Each seat weight from birth up to 22kgs.
- Never allow children to give rides to others.
- Maximum weight for objects placed in the back pouch is 2.2 lbs or 1kg on the Nipper Single & Nipper Sport or 2.2lbs or 1kg per pouch on the Nipper Double & Nipper Sport Double. Excessive weight may cause a hazardous, unstable condition.
Service:
- This vehicle requires regular maintenance by the user.
- Do not use replacement parts other than those supplied by the manufacturer or distributor.
- Regularly check that this stroller is in good operating condition and that all fasteners and nuts are secure.
Do not use the pram/stroller near an open fire or exposed flame.
