- Page 1 USER MANUAL UNDERCANOPY 120W LED...
-
Page 2: Product Contents
. PRODUCT CONTENTS Warning! Please read the following information carefully before installing and using. Check and comply with your local law and restrictions for additional safety require- ments of installation and operation. Make sure your AC power source conforms to the electrical requirement of this light. This light is suitable for operation in ambient not exceeding 95°F/40°C. -
Page 3: Key Features
- Seamless end to end connection with up to 17 lights - Scatter light output for better uniformity and penetration - 0-10V dimming with RJ11 connection, compatible with Flexstar Zeus controller - IP66 water proof and dust proof - ETL, DLC, CE, FCC certified... -
Page 4: Product Information
4. PRODUCT INFORMATION . SPECTRUM μmol/s/nm TECHNICAL SPECIFICATIONS Model UCL 120W Weight 5.73lb / 2.6kg Thermal PPE (μmol/J) up to 2.9 Passive Management Operation PPF (μmol/s) Up to 340 95°F/35°C Max Temperature Input Power 120W Light Distribution 120° Input Voltage 120V 240V 277V... -
Page 5: Installation
DIMENSIONS 3.3’’(8.5cm) 45.6’’(115.7cm) 5. INSTALLATION Please read the follow information before starting to install. Installation of this horticulture LED light shall be performed by qualified person with experience. To mount the light fixture properly, start by identifying an appropriate support structure for the fixture to mount on. - Page 6 Under Canopy Mounting Above Canopy Mounting Please check the maximum number of the lights connected to the same AC outlet (showed as below) before starting to install. 120Vac 240Vac 277Vac Current per fixture 1.0A 0.5A 0.43A Max. # of lights connected...
- Page 7 . UNDER CANOPY INSTALLATION Choose an appropriate position with a flat surface for setting up the lights. Use buckets (not included) or stands (sold separately) as the base to put the lights on. Ensure the base is solid. Use clips (sold separately) to mount on the square tubing. Bucket Base Prepare the enough amount of buckets or container pots with appropriate size.
- Page 8 Support With Stands Clip the two stands onto one light as the diagram showed below. Adjust the stands’ position about 6”-8” from the ends of each light to hold the light stably. Follow the steps in 5.3 to connect the multiple lights. Mounting on Square Tubing Prepare the square tubing and adjust to an appropriate height.
- Page 9 ABOVE CANOPY INSTALLATION For the application of downward lighting above the canopy, there are 2 options to mount the light fixtures: hanging with wire hooks or mounting with clips. Hanging With Wire Hooks Set up the wire hooks (sold separately) onto the bracket and install the hooks into the slots on either side of the light.
- Page 10 LIGHT CONNECTION (1) Set the first light at a proper position following the steps in 5.1 or 5.2. Ensure the male ports of the lights face outside to connect to the power cord later. 1st light AC input Female Port Male Port (2) Connect the 2nd light to the 1st light by plug the male port of the 2nd light into the female port of the 1st light (seamless connection).
- Page 11 (3) Repeat Step 2 to connect remaining lights. Keep the whole line of lights straight if use the seamless connection. Note: Ensure the numbers of light connected is not exceed the maximum number of daisy chain under certain input AC input voltage. First Light Last Light (4) Use the extension cord to connect between different lines of lights if needed.
- Page 12 (6) Plug the power cord with RJ11 cable into the male port of the 1st light. Screw the cap to tighten the connection. (7) Plug the RJ11 cable to the RJ11 end connector or a compatible controller. Note: If the RJ11 end connector or a compatible controller is not connected, the light will not be turned on normally! ZEUS X2 Smart Controller...
- Page 13 CONTROL CONNECTION Up to 160 pcs of the Flexstar Undercanopy 120W LED lights can be connected with daisy-chain and controlled by a Flexstar ZEUS Controller (sold seperately). Following the instructions in 5.3 to connect all the lights in each line (connect to the same AC outlet).
-
Page 14: Other Information
CONNECTING THE LED FIXTURES TO THE MAINS - Ensure the input power is off before connecting. - Plug the power cords of each light line into nearby AC outlets of the Mains according to the local rules, safety regulations and electrical codes. - Ensure the power cords is not coild or touching any hot surfaces. -
Page 15: Warranty
7. WARRANTY The company warrants the mechanical and electronic components of this product and guarantees the materials and workmanship free of defects if used under normal operating conditions, for a period of five (5) years from the original date of the purchase. If you find that there are any defects with this product that relate to either the workmanship or the materials but are not due to improper use or user error, the company shall, at its discretion, either replace or repair the product using the appropriate new or reconditioned... - Page 16 UNDERCANOPY 120W LED...
