- Page 1 SERVICE MANUAL ELECTRIC FIREPLACE MODEL NO.: RFH-3001LC / RFH-3601LC RFH-4201LC / RFH-5001LC RFH-6001LC / RFH-7401LC NOTE: This is one of the basic models. The shape and specifications of fireplace are subject to change.
-
Page 2: Troubleshooting
Troubleshooting Power supply control board of the fireplace: Note: You can check the corresponding wires according to the picture below. (Fig.1) Anode and Common Heater Cathode Switch Terminal Fan Terminal Terminal I & II Heater Terminal Terminal Fig.1 Rear Light Motor Remote Control Transformer... - Page 3 3. The fireplace does not work (The power indicator is on while the remote control and the control panel functions do not work). ①Turn off the main power switch and restart it (Fig.2)(Fig.3). If the unit still does not work, replace the mainboard with a new one. Fig.3 Fig.2 The main power switch is off.
- Page 4 8. The base LED light is off. ①The light wires are loose or the light terminal(Fig.1) is damaged. Check and replace the light terminal. ②The socket on the far right side of the light bar is loose. Please use the electric iron to repair, otherwise replace it with a new one.
- Page 5 ②If there is a continuous sound of motor, it should be the motor failure. Replace it with a new one. ③If there are foreign objects in the fan, remove them, and adjust the fan by turning the wheel in the direction of the arrow as shown in the picture below. (Fig.6) Fig.6 12.
- Page 6 ①Check if the wires of heater I, II and the common heater terminal(Fig.1) are loose. ②Replace the fan assembly. 15. When the fireplace was plugged in, the circuit breaker at the electrical outlet tripped. After resetting the circuit breaker, the machine cannot be turned on.
- Page 7 Thank you for purchasing this product! If you have any questions about the product, such as missing parts, damaged products, product assembling, and operation, please contact us via Amazon Message or customer service number: 213-4467172 or 661-4358826. IMPORTANT Please call our customer service department for any consulting: 213-4467172 661-4358826 (8:30am - 5:30pm P.S.T.)
