- Page 1 EtherWORKS Turbo EISA User Information Order Number: EK-DE425-OM. A01 Revision/Update Information: This is a new manual. Digital Equipment Corporation Maynard, Massachusetts...
- Page 2 FCC ID: AO9-DE425 FCC NOTICE: This device complies with Part 15 of the FCC Rules. Operation is subject to the following conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
- Page 3 First Edition, November 1994 Digital Equipment Corporation makes no representations that the use of its products in the manner described in this publication will not infringe on existing or future patent rights, nor do the descriptions contained in this publication imply the granting of licenses to make, use, or sell equipment or software in accordance with the description.
-
Page 5: Table Of Contents
Contents About This Manual ......1 Introduction Features ........1–1 2 Configuration EISA Configuration Utility . - Page 6 B–7 C International Technical Support Figures EtherWORKS Turbo EISA Product Kit . . . 3–1 Removing the System Unit Outside Cover ......
- Page 7 3–5 Connecting to the Ethernet Network ..3–13 B–1 RJ-45 Connector (Front View) ..B–7 Tables Turbo EISA Adapter Parameters ..2–1 2–2 3–1...
-
Page 9: About This Manual
About This Manual The EtherWORKS Turbo EISA adapter is a computer option adapter that enables you to integrate various EISA-compatible computers into local area network (LAN) environments that use IEEE 802.3 and Ethernet protocols. The EtherWORKS Turbo EISA adapter is also referred to as Turbo EISA adapter or adapter in this manual. -
Page 10: Manual Conventions
Product Kit Contents The product kit includes the items shown in Figure 1. Verify that you have the following components before proceeding: • EtherWORKS Turbo EISA adapter • 3½ inch distribution diskette • Anti-static packaging bag •... -
Page 11: Etherworks Turbo Eisa Product Kit
Figure 1 EtherWORKS Turbo EISA Product Kit LJ-03707-TI0A... -
Page 13: Introduction
Introduction This chapter describes the EtherWORKS Turbo EISA adapter and briefly summarizes its features. The Turbo EISA adapter enables you to integrate EISA-compatible computers into a network using ThinWire, AUI, or twisted-pair Ethernet cables. After you install the adapter in your computer, you can use various network software products to integrate the computer into a local area network (LAN) environment. - Page 14 • Supports ThinWire, AUI, and twisted-pair Ethernet connections • Provides a comprehensive set of device drivers for the most popular network operating environments. Novell NetWare Microsoft Windows NT (Intel and Alpha) Microsoft Windows Microsoft Windows for Workgroups Digital PATHWORKS IBM LAN Manager SCO Unix OS/2 1–2...
-
Page 15: Configuration
Configuration This chapter describes how to prepare your system’s configuration to accept the EtherWORKS Turbo EISA adapter prior to installing the adapter in your system. The configuration file (!DEC4250.CFG), contained on the distribution diskette included in the Turbo EISA kit, must be used with your system EISA Configuration Utility (ECU). -
Page 16: Eisa Configuration Utility
EISA Configuration Utility The ECU is used to select system- and adapter-specific parameters to help ensure proper system operation when adding a new adapter to your system. Refer to your computer documentation for information on how to install an adapter using your system ECU. Note If there is an adapter installed in your system that has not been configured by the ECU, an IRQ or memory conflict could... -
Page 17: Accessing The Configuration Utility
Turbo EISA distribution diskette containing the configuration file (!DEC4250.CFG) into drive A. 5. Select the Digital EtherWORKS Turbo EISA (DE425-xx) option. 6. When prompted for the ECU diskette, remove the Turbo EISA diskette and insert the system ECU diskette again. -
Page 18: Changing The Adapter Settings
Changing the Adapter Settings This section describes how to change the Turbo EISA adapter settings using the following ECU menu options. Note An asterisk in the following examples indicates the default settings. Interrupt Mode The Turbo EISA adapter can use IRQ5, IRQ9, IRQ10, or IRQ11. The ECU will select the first available IRQ. -
Page 19: Dma Mode-Burst Length
DMA Mode—Burst Length This menu option indicates the maximum number of longwords to be transferred in a single DMA transaction. The more longwords transferred, the higher the Turbo EISA adapter’s performance; therefore, select the default (16 Longwords) whenever possible. The available number of longwords that can be transferred during a single DMA transaction are as follows: (*) 16 Longwords ( ) 8 Longwords... -
Page 20: Network Mode/Cable Type
When Rcv/Txm DMA arbitration is selected, the receive process has priority over the transmit process. When Round Robin arbitration is selected, there is an equal sharing of the DMA request between the receive and transmit processes. The available bus arbitration selections are as follows: (*) Rcv/Txm ( ) Round Robin Network Mode/Cable Type... - Page 21 Note Selecting AUI ThinWire or AUI thickwire will enable the AUI port and prompt the ECU to display the proper AUI jumper position. After making your selection, use the ECU to view the AUI jumper position and record this information. Before installing the Turbo EISA adapter in your system, manually set the AUI jumper setting on the adapter to match the ECU setting (see Figure 3–2).
-
Page 23: Adapter Installation And Diagnostics
Adapter Installation and Diagnostics The steps to install the EtherWORKS Turbo EISA adapter are as follows: 1. Prepare the Turbo EISA adapter for installation. 2. Prepare your computer’s configuration using the the !DE4250.CFG configuration file and your system EISA Configuration Utility (ECU). -
Page 24: Preparing The Computer
Preparing the Computer Use the following procedure to prepare your computer for a typical installation of the Turbo EISA adapter. Refer to your computer documentation for specific installation information. 1. Set all power switches (system and peripherals) to the off position. 2. -
Page 25: Removing The System Unit Outside Cover
Figure 3–1 Removing the System Unit Outside Cover LJ-03708-TI0 3–3... -
Page 26: Preparing The Adapter
Installing the Adapter section of this chapter. When not using a 10Base-T twisted-pair interface, the AUI jumper ( , Figure 3–2) on the EtherWORKS Turbo EISA adapter determines which media interface, 10Base2 ThinWire or AUI, will be used. The default AUI setting is for a ThinWire network. -
Page 27: Configuring Media Interface
Figure 3–2 Configuring Media Interface AUI Thickwire ThinWire LJ-03706-TI0 3–5... -
Page 28: Installing The Adapter
Installing the Adapter To install the Turbo EISA adapter in your computer, use the following procedure: 1. Set all power switches (system and peripherals) to the off position. 2. Unplug the power cord from the wall socket, then disconnect the cord from the system unit. -
Page 29: Removing The Slot Cover
Figure 3–3 Removing the Slot Cover L J - 0 0 4 6 2 - T I 0 3–7... -
Page 30: Installing The Etherworks Turbo Eisa Adapter
Figure 3–4 Installing the EtherWORKS Turbo EISA Adapter L J - 0 2 5 9 0 - T I 0 B 3–8... -
Page 31: Diagnostics
The NICDIAG Diagnostic utility prevents diagnostics from running if it detects an active EtherWORKS Turbo EISA adapter. The adapter is considered active if a network device driver is loaded. If necessary, remove the statement that loads the device driver in the CONFIG.SYS or other files and cold boot the computer to deactivate... - Page 32 4. Select the Configuration option, then press to display the Enter current Turbo EISA adapter configuration. These parameters are for viewing only, and cannot be changed. 5. Select the Diagnostics option, then press to run the Enter diagnostics. When the diagnostics are complete, the screen displays the diagnostic result code and lets you know whether the adapter diagnostics passed or failed.
-
Page 33: Connecting To A Network
Connecting to a Network Use one of the following procedures to connect your system to the network. Connecting to a ThinWire Ethernet Network To connect the Turbo EISA adapter to a ThinWire network: 1. Attach the ThinWire cable(s) to a T-connector (included in your Turbo EISA kit). -
Page 34: Connecting To An Aui Ethernet Network
3. Slide the latch assembly downward to lock the connector in place (see in Figure 3–5). Note Do not connect more than one Ethernet cable to the EtherWORKS Turbo EISA adapter at the same time (see in Figure 3–5). 3–12... -
Page 35: Connecting To The Ethernet Network
Figure 3–5 Connecting to the Ethernet Network ThinWire Twisted-Pair ThickWire ThickWire S c a l e d 7 5 % S c a le d 7 5 % L J - 0 3 7 3 8 - T I 0 A 3–13... -
Page 37: Device Driver Information
Device Driver Information The EtherWORKS Turbo EISA distribution diskette files, README.TXT and RELEASE.NOT, contain device driver software and installation information. The diskette also contains configuration information for PATHWORKS, LAN Manager-based, Windows NT, and NetWare network operating systems (NOS). • Refer to the README.TXT file located in the diskette’s root... -
Page 38: Obtaining The Latest Etherworks Turbo Eisa Driver Files
Obtaining the Latest EtherWORKS Turbo EISA Driver Files The device driver software diskette included in your EtherWORKS Turbo EISA kit could become outdated as operating system software evolves. To obtain the latest versions of the driver files from the Internet, CompuServe, and the DECpc Bulletin Board Service, use the following procedures. - Page 39 • DECpc Bulletin Board Service: 1. Using a modem (parameters 2400, 8, n, 1), connect to the DECpc Bulletin Board Service in the U.S. by dialing 508-496-8800. 2. Follow the menu-driven instructions on your screen to download the driver files. 4–3...
-
Page 41: A Problem Solving
Problem Solving This appendix describes problems you could encounter when installing the EtherWORKS Turbo EISA adapter and suggests possible causes and solutions. Fault Isolation By Symptom Table A–1 describes how to isolate faults by the symptoms that are occurring. Table A–1 Fault Isolation By Symptom... - Page 42 Table A–1 (Cont.) Fault Isolation By Symptom Symptom Possible Cause Recommended Action The system is The adapter is preventing Disconnect the on, but nothing the CPU from operating ThinWire or twisted- happens. The correctly. pair cable from the keyboard does not adapter.
- Page 43 Table A–1 (Cont.) Fault Isolation By Symptom Symptom Possible Cause Recommended Action The system is on, The network cables are Check and secure all but the network loose. cables. does not start. A conflict exists with another adapter in the system: The IRQ settings are Check the ECU setup...
-
Page 44: Diagnostic Test Errors
Table A–1 (Cont.) Fault Isolation By Symptom Symptom Possible Cause Recommended Action Network device has twisted- Enable twisted-pair link pair link integrity disabled on the network device, or does not support link if supported. integrity. Twisted-pair cable is Replace twisted-pair defective. -
Page 45: Diagnostic Test Error Codes
Table A–2 Diagnostic Test Error Codes Error Message Recommended Actions Err 1, Memory allocation error Insufficient memory for diagnostics; release some memory. If the problem persists, contact your system administrator. Err 2, Registers W/R error Ensure adapter is seated firmly in the bus slot, or try another available bus slot. - Page 46 Table A–2 (Cont.) Diagnostic Test Error Codes Error Message Recommended Actions Err 10, EthWRKS babbler, can’t transmit These messages indicate network- Err 11, Transmit time-out error related test failures. If the driver Err 12, Receive time-out error was installed before running Err 13, Receive data failure diagnostics, disable the driver Err 14, RDES0: receive error detected...
- Page 47 Table A–2 (Cont.) Diagnostic Test Error Codes Error Message Recommended Actions Err 33, Internal loopback test error These messages indicate an IRQ Err 34, 10Base-T internal loopback test conflict (when two adapters want error to use same interrupt line). Run ECU to reconfigure adapter to another IRQ line.
- Page 48 Table A–2 (Cont.) Diagnostic Test Error Codes Error Message Recommended Actions Err 37, Interrupt mask test error This message indicates an IRQ conflict (when two adapters want to use the same interrupt line). Run the ECU to reconfigure the adapter to another IRQ line. If the problem persists, the adapter could be defective.
-
Page 49: B General Information
General Information This appendix provides general system specifications and cabling requirements for the EtherWORKS Turbo EISA adapter. Physical Description The Turbo EISA adapter is an EISA form-factor printed circuit board that uses the full 32-bit bus data path interface. The adapter measures 7.325 inches (184.785 mm) x 4.420 inches (112.268 mm),... -
Page 50: Leds
LEDs During normal system power-up, both the amber and green LEDs will light and remain on. Once the network software and driver is loaded, or the Turbo EISA adapter’s diagnostics are executing, the LEDs reflect status described in Table B–1. Table B–1 describes the Turbo EISA adapter LEDs. -
Page 51: Twisted-Pair Link
Twisted-Pair Link When the network or diagnostic software is running, and Twisted-pair or Twisted-pair Full Duplex mode is selected, the twisted-pair link LED turns on if receive data or twisted-pair link pulses are detected. If no receive data or twisted-pair link pulses are detected within 150 milliseconds, the twisted-pair link LED turns off, indicating twisted-pair link fail status. -
Page 52: Operating Environment
Table B–2 Electrical Parameters Power DC Amps (+5.0 V) DC Amps (+12.0 V) Cable Type Jumper Maximum Maximum Maximum Twisted-pair ThinWire 12.4 W 2.0 A 0.2 A 10.0 W 2.0 A ThinWire ThinWire 12.4 W 2.0 A 0.2 A 16.0 W 2.0 A 0.5 A When using twisted-pair cable, the AUI jumper position affects the amount of power... -
Page 53: Cabling Requirements
Cabling Requirements You are required to use one of the following cable types or the equivalent to connect your Turbo EISA adapter to the network. When referring to the following Digital part numbers, the xx stands for cable length in meters. •... - Page 54 For further information about network configuration, planning, and cabling, refer to the following: • DECconnect System Planning and Configuration Guide (PN EK-DECSY-CG) • OPEN DECconnect Applications Guide (PN EC-G2570-42) B–6...
-
Page 55: Card Connector Pinning (Rj-45)
Card Connector Pinning (RJ-45) If you are using your Turbo EISA adapter to connect 10Base-T twisted-pair networks, the connector has the following pin signals (see Figure B–1). Pin Number Signal Name Transmit + Transmit - Receive + NC (no connection) NC (no connection) Receive - NC (no connection) -
Page 57: C International Technical Support
International Technical Support Table C–1 lists the international telephone numbers to call for technical support for the EtherWORKS Turbo EISA adapter. Table C–1 International Support Telephone Numbers Country Telephone Number United States 1-800-354-9000 Australia 31-2-5615252 Austria 0222-86630-555 Belgium 02-7297744 Canada (English) - Page 58 Table C–1 (Cont.) International Support Telephone Numbers Country Telephone Number Mexico 520140810017 Netherlands 030-832888 Northern Ireland 0232 381381 Norway 02-256300 Philippines 623-810-5156 Portugal (Lisbon) 01-3877051 Portugal (Oporto) 02-6068805 Republic of Ireland 01-381216 Singapore 330-6225 Spain (Madrid) 34-(9)1-5834257 Spain (Barcelona) 34-(9)3-4012222 Sweden 08-988835 Thailand...
